Victron Energy CYR010230430 12/24V-230A Cyrix-Li-Charge Battery Charger

Victron Energy 12/24V-230A Cyrix-Li-Charge Battery Charger: The Battery Charger From Victron Have Been Designed to Be a True Worldwide Product

The Cyrix-Li-Charge will disengage immediately whenever its control input becomes free floating, signalling cell over voltage or cell over temperature. In general a cell over voltage alarm will reset shortly after charging has been stopped. The Cyrix will then reconnect the charger after a delay 3 seconds. After 2 attempts to reengage with 3 seconds delay, the delay increases to 10 minutes. Whenever battery voltage is less than 13,5 V (resp. 27 V or 54 V), the Cyrix will disengage with a delay of 1 hour. Note 1: In case of zero discharge current, or a small discharge current, the Cyrix will not disengage shortly after the charger has been switched off and/or disconnected, because battery voltage will remain higher than 13,5 V. Note 2: If, after the Cyrix has disengaged, the output of the battery charger immediately increases to 13,7 V or more, the Cyrix will reengage, with 3 seconds delay.

Victron Energy CYR010230430 Specifications:

• Continuous current and breaking capacity at 12V: 230 A
• Breaking capacity at 48V: 80 A
• LED Status Indication: Yes
• Control Cable: Included (length 1 meter)
• Connect Voltage: 13,7 V / 27,4 V / 54,8 V
• Current consumption when open: <4 mA
• Protection category: IP54
