Nakamichi 9" Wireless CarPlay Android Auto VW Crafter 2007-2016 Head Unit

Modernize your Volkswagen Crafter van with wireless smartphone integration and Android 13 capability.

Product Overview

The Nakamichi NA9VWCRAFTER20072016 transforms your Volkswagen Crafter's factory infotainment into a comprehensive Android 13 multimedia system with wireless Apple CarPlay and Android Auto integration. This vehicle-specific 9-inch IPS touchscreen head unit is engineered exclusively for VW Crafter commercial vans from 2007-2016, replacing the factory display with a plug-and-play solution that includes the matching fascia panel for seamless dashboard integration. Running Android 13 (NK 13.0) with 4GB RAM and 64GB internal storage, the system delivers smooth performance across navigation, media playback, and app multitasking while providing ample space for offline maps, music libraries, and Android apps from the Google Play Store. Beyond smartphone mirroring, the system includes built-in GPS with preloaded navigation data, WiFi connectivity, FM radio with RDS supporting 18 presets, and Bluetooth 5.0 for hands-free calling and wireless audio streaming. The 4×50W amplifier drives factory Crafter speakers or upgraded components, while 4V pre-outputs provide clean signal to external amplifiers. Factory steering wheel controls are retained via CAN bus integration, maintaining convenient thumb access to audio controls during commercial operations or long-distance driving. This complete replacement solution maintains your Crafter's functional cabin appearance while delivering the connected features modern commercial drivers need for efficient route planning and communication.

Key Specifications

• 9-inch IPS touchscreen display with 1280×720 resolution and 500nit brightness
• Android 13 operating system (NK 13.0)
• 4GB RAM with 64GB internal storage
• Wireless Apple CarPlay and Android Auto (wired for some Android devices)
• Built-in GPS with preloaded navigation data, updateable via Google Play Store
• WiFi connectivity for internet access and app functionality
• Bluetooth 5.0+EDR (2.4GHz, 5m range)
• FM radio tuner: 87.5-108.0MHz with RDS, 18 FM presets
• AM radio: 522-1620kHz, 12 AM presets (note: AM reception may be limited)
• 4×50W maximum amplifier output to 4-8Ω speakers
• 4V/10kΩ pre-outputs with ≤600Ω impedance for external amplifiers
• Reversing camera input and front camera/auxiliary video input
• Dual USB interfaces: 4-pin for PhoneLink, 6-pin for media playback
• Factory steering wheel control compatibility via CAN bus integration
• External microphone included for enhanced hands-free clarity
• Video format support: H264, MP4, AVI, MKV, FLV
• Audio format support: MP3, APE, AAC, FLAC
• 10.5-16V operating voltage range (14.4V nominal)
• Includes Crafter-specific fascia panel for 2007-2016 models
• Compatible exclusively with Volkswagen Crafter 2007-2016

Features & Benefits

Crafter-Specific Engineering – Designed exclusively for Volkswagen Crafter commercial vans from 2007-2016 with included fascia panel that matches your factory dash perfectly. Plug-and-play harnesses connect to existing wiring without cutting or splicing, maintaining the durability standards VW engineered for commercial vehicle operations.

Wireless CarPlay for Commercial Efficiency – Connect your iPhone wirelessly and access Apple Maps, hands-free calling, Messages, and Siri through the 9-inch display without cable clutter. The system remembers your device and connects automatically when you start your Crafter, essential for tradespeople and delivery drivers managing multiple stops throughout the day.

Android Auto for Fleet Operations – Pair compatible Android phones wirelessly (some models require wired connection) to mirror Google Maps, hands-free calling, and messaging apps on the touchscreen. Voice commands handle navigation and communication while maintaining focus on traffic and delivery schedules during commercial operations.

Latest Android 13 System – The upgraded NK 13.0 operating system provides enhanced security protocols, improved app compatibility, and refined performance over previous Android versions. Access Google Play Store to download fleet management apps, job tracking software, and navigation solutions while the system manages updates automatically over WiFi.

Expanded 64GB Storage – Double the internal storage of earlier models accommodates extensive offline map data for regional delivery routes, multiple navigation apps for comprehensive coverage, job site documentation, and various Android applications running simultaneously without storage constraints during workdays.

Built-In GPS Navigation – Preloaded GPS data provides offline navigation capability when mobile coverage drops on regional routes, industrial areas, or remote job sites where Crafter vans frequently operate. Download alternative navigation apps from Google Play Store or run multiple navigation solutions for route optimization and delivery efficiency.

High-Brightness Commercial Display – The 1280×720 resolution IPS panel with 500nit brightness maintains excellent visibility in direct Australian sunlight, essential for Crafter drivers navigating loading docks, construction sites, and outdoor delivery locations. The capacitive touchscreen responds reliably even with work gloves on for practical daily use.

Enhanced Pre-Output Signal – The 4V pre-output voltage delivers twice the signal strength of standard 2V units, reducing noise interference when driving external amplifiers. This clean signal improves audio quality in upgraded systems, useful for Crafter operators spending extended hours behind the wheel.

Factory Control Retention – CAN bus integration maintains functionality of factory Volkswagen Crafter steering wheel controls, letting you adjust volume, answer calls, and manage audio using existing buttons. This integration preserves the efficient workflow commercial drivers need when managing calls and navigation simultaneously.

Complete Installation Package – Includes Crafter-specific fascia panel, main wiring harness, RCA cables, camera cable, speaker cables, external microphone, GPS antenna, USB cables, and user manual. Everything required for installation is provided, though professional fitting is recommended for optimal integration with factory systems.

Technical Specs

• Display: 9" IPS touchscreen, 1280×720 resolution, 500nit brightness
• System: Android 13 (NK 13.0)
• Memory: 4GB RAM, 64GB internal storage
• Smartphone Integration: Wireless Apple CarPlay, Android Auto (wireless/wired depending on device)
• GPS: Built-in with preloaded data, updateable via Google Play Store
• Connectivity: WiFi
• Bluetooth: Version 5.0+EDR, 2.4GHz frequency, 5m range
• Radio Tuner: FM 87.5-108.0MHz with RDS (18 FM presets), AM 522-1620kHz (12 AM presets, limited reception)
• Audio Output: 4 channels × 50W maximum, 4-8Ω speaker impedance
• Pre-Outputs: 4V/10kΩ, ≤600Ω impedance (front left/right, rear left/right, subwoofer)
• Video Inputs: Reversing camera, front camera/auxiliary
• USB Interfaces: 4-pin (PhoneLink), 6-pin (media playback)
• USB Charging: 5V±0.25V/1A
• Video Formats: H264, MP4, AVI, MKV, FLV
• Audio Formats: MP3, APE, AAC, FLAC
• Power: 14.4V nominal (10.5-16V operating range)
• CAN Bus: Factory steering wheel control integration
• Microphone: External microphone included
• Antenna: GPS antenna included
• Fascia: VW Crafter 2007-2016 specific panel included

Compatible Vehicle:

• Volkswagen Crafter: 2007-2016 (first-generation, all wheelbase and roof height variants)

Package Includes:

• 1× Nakamichi head unit with Crafter-specific fascia panel
• 1× Main wiring harness
• 1× RCA cable
• 1× Camera cable
• 1× Rear left/right speaker cable
• 1× External microphone
• 1× GPS antenna
• 1× User manual
• 2× USB cables

Frequently Asked Questions

Is this specifically designed for my Volkswagen Crafter?

Yes, this unit is engineered exclusively for Volkswagen Crafter commercial vans from 2007-2016 (first-generation models). The included fascia panel and wiring harness are configured for Crafter-specific integration. Contact us with your exact Crafter year and a photo of your current dash to confirm harness compatibility before purchase.

Why is AM radio reception limited?

Due to the Crafter's commercial vehicle construction and antenna placement, AM radio reception may be weaker than FM reception. FM radio operates normally with full RDS functionality and 18 presets. For primary radio listening, FM provides reliable reception, while smartphone connectivity offers additional audio source options including streaming services and podcasts.

Is CarPlay and Android Auto wireless or wired?

Apple CarPlay is wireless for all iPhones. Android Auto is wireless for most modern Android devices, but some specific phone brands may require wired USB connection via the included 4-pin PhoneLink cable. Both connection methods are fully supported through the dual USB interface.

Can I install fleet management or job tracking apps?

Yes, the full Android 13 system provides access to Google Play Store. The 64GB internal storage accommodates navigation apps, fleet management software, job tracking applications, and communication tools. Download apps relevant to your commercial operations directly to the unit for integrated workflow management.

Will my steering wheel controls continue to work?

Yes, CAN bus integration maintains factory Volkswagen Crafter steering wheel control functionality. The system communicates directly with your vehicle's control protocols, allowing continued use of volume, track skip, and call management buttons without requiring additional adapters.

Compatible With / Goes Well With

• VW Crafter 2007-2016 factory steering wheel control systems
• Aftermarket reversing cameras with composite video output (essential for commercial operations)
• External amplifiers via 4V RCA pre-outputs
• Component speakers and coaxial speakers (4Ω to 8Ω)
• Subwoofer systems via dedicated pre-output
• GPS antenna extension cables for optimal signal placement
• Front-facing dash cameras via auxiliary video input (recommended for commercial insurance)
• Android Auto-compatible fleet management apps
• Job tracking and scheduling applications from Google Play Store
• Professional installation services for commercial vehicle integration
