Nakamichi 9" Wireless CarPlay Android Auto Universal Toyota Head Unit

Upgrade 19 different Toyota models with wireless smartphone integration and Android 13 capability.

Product Overview

The Nakamichi NA9TOYOTAUNIVERSAL transforms your Toyota's factory infotainment into a comprehensive Android 13 multimedia system with wireless Apple CarPlay and Android Auto integration across 19 compatible Toyota models spanning nearly two decades of production. This vehicle-specific 9-inch IPS touchscreen head unit replaces factory displays in popular Toyota vehicles from 1999-2014, including Hilux, Landcruiser, Prado, Camry, Corolla, RAV-4, Hiace, and many others. Running Android 13 (NK 13.0) with 4GB RAM and 64GB internal storage, the system delivers smooth performance across navigation, media playback, and app multitasking while providing ample space for offline maps, music libraries, and Android apps from the Google Play Store. Beyond smartphone mirroring, the NA9TOYOTAUNIVERSAL includes built-in GPS with preloaded navigation data, WiFi connectivity, comprehensive AM/FM radio with RDS supporting 18 FM and 12 AM presets, and Bluetooth 5.0 for hands-free calling and wireless audio streaming. The 4×50W amplifier drives factory Toyota speakers or upgraded components, while 4V pre-outputs provide clean signal to external amplifiers for premium audio builds. Factory steering wheel controls are retained via CAN bus integration, and the system supports aftermarket reversing cameras directly. Each unit ships with a vehicle-specific fascia panel and harness configuration tailored to your Toyota model, maintaining factory appearance while delivering modern connected features.

Key Specifications

• 9-inch IPS touchscreen display with 1280×720 resolution and 500nit brightness
• Android 13 operating system (NK 13.0)
• 4GB RAM with 64GB internal storage
• Wireless Apple CarPlay and Android Auto (wired for some Android devices)
• Built-in GPS with preloaded navigation data, updateable via Google Play Store
• WiFi connectivity for internet access and app functionality
• Bluetooth 5.0+EDR (2.4GHz, 5m range)
• AM/FM radio tuner: FM 87.5-108.0MHz, AM 522-1620kHz with 18 FM/12 AM presets
• 4×50W maximum amplifier output to 4-8Ω speakers
• 4V/10kΩ pre-outputs with ≤600Ω impedance for external amplifiers
• Reversing camera input and front camera/auxiliary video input
• Dual USB interfaces: 4-pin for PhoneLink, 6-pin for media playback
• Factory steering wheel control compatibility via CAN bus integration
• External microphone included for enhanced hands-free clarity
• Video format support: H264, MP4, AVI, MKV, FLV
• Audio format support: MP3, APE, AAC, FLAC
• 10.5-16V operating voltage range (14.4V nominal)
• Includes vehicle-specific fascia panel for compatible Toyota models
• Compatible with 19 Toyota models from 1999-2014

Features & Benefits

Universal Toyota Compatibility – Engineered to fit 19 different Toyota models across 15 years of production, from 1999 Echo to 2014 Yaris. The included vehicle-specific fascia panel and tailored wiring harness ensure proper fitment across diverse Toyota platforms including passenger cars (Corolla, Camry, Yaris), SUVs (RAV-4, Kluger, Prado), and commercial vehicles (Hilux, Hiace).

Wireless CarPlay Freedom – Connect your iPhone wirelessly and access Apple Maps, Spotify, Messages, and Siri through the 9-inch display without cable clutter. The system remembers your device and connects automatically when you start your Toyota, keeping your charging port available for other devices during daily commutes or outback touring.

Android Auto Convenience – Pair compatible Android phones wirelessly (some models require wired connection) to mirror Google Maps, YouTube Music, WhatsApp, and Google Assistant on the touchscreen. Voice commands handle navigation and messaging while your hands remain on the wheel navigating varied Australian conditions.

Latest Android 13 System – The upgraded NK 13.0 operating system provides enhanced security protocols, improved app compatibility, and refined performance over previous Android versions. Access Google Play Store to download navigation apps, streaming services, and entertainment options while the system manages updates automatically over WiFi.

Expanded 64GB Storage – Double the internal storage of earlier models accommodates extensive offline map data for regional touring, large music libraries with lossless audio files, multiple navigation apps for comprehensive coverage, and various Android applications running simultaneously without storage limitations.

Built-In GPS Navigation – Preloaded GPS data provides offline navigation capability when mobile coverage drops on remote highways, outback tracks, or touring routes where Toyota 4WDs excel. Download alternative navigation apps from Google Play Store, update maps over WiFi, or run multiple navigation solutions for redundancy.

High-Brightness IPS Display – The 1280×720 resolution IPS panel with 500nit brightness maintains excellent visibility in direct Australian sunlight, essential for Toyota owners navigating diverse conditions from coastal highways to inland routes. Wide viewing angles ensure passengers can see navigation details, and the capacitive touchscreen responds intuitively.

Enhanced Pre-Output Signal – The 4V pre-output voltage delivers twice the signal strength of standard 2V units, reducing noise interference when driving external amplifiers. This clean signal improves sound quality in upgraded audio systems, ideal for Toyota enthusiasts building custom audio configurations.

Factory Control Retention – CAN bus integration maintains functionality of factory Toyota steering wheel controls across compatible models, letting you adjust volume, skip tracks, and manage calls using existing buttons. The system adapts to Toyota's control protocols without requiring additional adapters in most applications.

Complete Installation Package – Includes Toyota model-specific fascia panel, main wiring harness, RCA cables, camera cable, speaker cables, external microphone, GPS antenna, USB cables, and user manual. Everything required for installation is provided, though professional fitting is recommended for optimal integration with factory systems.

Technical Specs

• Display: 9" IPS touchscreen, 1280×720 resolution, 500nit brightness
• System: Android 13 (NK 13.0)
• Memory: 4GB RAM, 64GB internal storage
• Smartphone Integration: Wireless Apple CarPlay, Android Auto (wireless/wired depending on device)
• GPS: Built-in with preloaded data, updateable via Google Play Store
• Connectivity: WiFi
• Bluetooth: Version 5.0+EDR, 2.4GHz frequency, 5m range
• Radio Tuner: FM 87.5-108.0MHz, AM 522-1620kHz, RDS support, 18 FM/12 AM presets
• Audio Output: 4 channels × 50W maximum, 4-8Ω speaker impedance
• Pre-Outputs: 4V/10kΩ, ≤600Ω impedance (front left/right, rear left/right, subwoofer)
• Video Inputs: Reversing camera, front camera/auxiliary
• USB Interfaces: 4-pin (PhoneLink), 6-pin (media playback)
• USB Charging: 5V±0.25V/1A
• Video Formats: H264, MP4, AVI, MKV, FLV
• Audio Formats: MP3, APE, AAC, FLAC
• Power: 14.4V nominal (10.5-16V operating range)
• CAN Bus: Factory steering wheel control integration
• Microphone: External microphone included
• Antenna: GPS antenna included
• Fascia: Toyota model-specific panel included

Compatible Toyota Models:

• 86 (ZN6): 2012+
• Avensis Verso: 2000-2009
• Camry: 2002-2006
• Celica: 1999-2005
• Corolla: 2002-2013
• Echo: 1999-2005
• Estima/Tarago: 2000-2006, 2006-2014
• FJ Cruiser: 2011+
• Hiace: 2005+
• Hilux: 2005-2013
• Kluger: 2003-2013
• Landcruiser 100 Series: 2003-2006
• Landcruiser 200 Series: 2007-2014
• Landcruiser Prado 120 Series: 2003-2009
• MR2: 2000-2002
• RAV-4: 2000-2011
• Rukus: 2006+
• Yaris: 2005-2014

Package Includes:

• 1× Nakamichi head unit with Toyota model-specific fascia panel
• 1× Main wiring harness
• 1× RCA cable
• 1× Camera cable
• 1× Rear left/right speaker cable
• 1× External microphone
• 1× GPS antenna
• 1× User manual
• 2× USB cables

Frequently Asked Questions

Will this fit my specific Toyota model and year?

The NA9TOYOTAUNIVERSAL is compatible with 19 Toyota models listed above within specified year ranges. Each installation requires a vehicle-specific fascia panel and wiring harness configuration. Contact us with your vehicle's exact year, model, and a photo of your current dash before purchase to confirm compatibility and ensure correct harness selection.

Does this work with my factory reversing camera?

Factory Toyota cameras may require professional installation to hardwire connections properly depending on your specific model and year. Aftermarket reversing cameras connect directly via the included camera cable and work plug-and-play. Contact us with your vehicle details to determine the correct camera integration method.

Is CarPlay and Android Auto wireless or wired?

Apple CarPlay is wireless for all iPhones. Android Auto is wireless for most modern Android devices, but some specific phone brands may require wired USB connection via the included 4-pin PhoneLink cable. Both connection methods are fully supported through the dual USB interface.

Can I install Android apps from the Play Store?

Yes, the full Android 13 system provides access to Google Play Store. The 64GB internal storage accommodates navigation apps, music streaming services, video players, and most Android applications. Download offline maps for remote touring, entertainment apps, and productivity tools directly to the unit.

Will my steering wheel controls continue to work?

Yes, CAN bus integration maintains factory Toyota steering wheel control functionality in most compatible models. The system communicates directly with your vehicle's control protocols, allowing continued use of volume, track skip, and call management buttons without requiring additional adapters in typical installations.

Compatible With / Goes Well With

• Vehicle-specific installation harnesses for Toyota models
• Aftermarket reversing cameras with composite video output
• Factory Toyota camera hardwire integration (professional installation recommended)
• External amplifiers via 4V RCA pre-outputs
• Component speakers and coaxial speakers (4Ω to 8Ω)
• Subwoofer systems via dedicated pre-output
• GPS antenna extension cables for optimal signal placement
• Front-facing dash cameras via auxiliary video input
• Android Auto-compatible apps from Google Play Store
• WiFi-enabled streaming services and navigation apps
• Professional installation services for complex integrations
