Nakamichi 9" Wireless CarPlay Android Auto Toyota RAV4 2001-2005 Dash 1 Head Unit

Modernize your second-generation Toyota RAV4 with wireless smartphone integration and Android 13 capability.

Product Overview

The Nakamichi NA9TOYOTARAV420012005 transforms your Toyota RAV4's factory infotainment into a comprehensive Android 13 multimedia system with wireless Apple CarPlay and Android Auto integration. This vehicle-specific 9-inch IPS touchscreen head unit is engineered exclusively for second-generation Toyota RAV4 models from 2001-2005 with Dash 1 configuration, replacing the factory display with a plug-and-play solution that includes the matching fascia panel for seamless dashboard integration. Running Android 13 (NK 13.0) with 4GB RAM and 64GB internal storage, the system delivers smooth performance across navigation, media playback, and app multitasking while providing ample space for offline maps, music libraries, and Android apps from the Google Play Store. Beyond smartphone mirroring, the system includes built-in GPS with preloaded navigation data, WiFi connectivity, comprehensive AM/FM radio with RDS supporting 18 FM and 12 AM presets, and Bluetooth 5.0 for hands-free calling and wireless audio streaming. The 4×50W amplifier drives factory RAV4 speakers or upgraded components, while 4V pre-outputs provide clean signal to external amplifiers. Factory steering wheel controls are retained via CAN bus integration where applicable, maintaining convenient control for RAV4 owners. This complete replacement solution maintains your RAV4's functional appearance while delivering the connected features modern drivers expect from contemporary vehicles.

Key Specifications

• 9-inch IPS touchscreen display with 1280×720 resolution and 500nit brightness
• Android 13 operating system (NK 13.0)
• 4GB RAM with 64GB internal storage
• Wireless Apple CarPlay and Android Auto (wired for some Android devices)
• Built-in GPS with preloaded navigation data, updateable via Google Play Store
• WiFi connectivity for internet access and app functionality
• Bluetooth 5.0+EDR (2.4GHz, 5m range)
• AM/FM radio tuner: FM 87.5-108.0MHz, AM 522-1620kHz with 18 FM/12 AM presets
• 4×50W maximum amplifier output to 4-8Ω speakers
• 4V/10kΩ pre-outputs with ≤600Ω impedance for external amplifiers
• Reversing camera input and front camera/auxiliary video input
• Dual USB interfaces: 4-pin for PhoneLink, 6-pin for media playback
• Factory steering wheel control compatibility via CAN bus integration
• External microphone included for enhanced hands-free clarity
• Video format support: H264, MP4, AVI, MKV, FLV
• Audio format support: MP3, APE, AAC, FLAC
• 10.5-16V operating voltage range (14.4V nominal)
• Includes RAV4 Dash 1-specific fascia panel for 2001-2005 models
• Compatible exclusively with Toyota RAV4 2001-2005 Dash 1 configuration

Features & Benefits

RAV4 Dash 1-Specific Engineering – Designed exclusively for second-generation Toyota RAV4 models from 2001-2005 with Dash 1 dashboard configuration. The included fascia panel matches your specific factory dash layout perfectly, while plug-and-play harnesses connect to existing wiring without cutting or splicing. Contact us with a photo of your dash to confirm you have Dash 1 configuration before purchase.

Wireless CarPlay Freedom – Connect your iPhone wirelessly and access Apple Maps, Spotify, Messages, and Siri through the 9-inch display without cable clutter. The system remembers your device and connects automatically when you start your RAV4, keeping your charging port available for other devices during daily driving or weekend adventures.

Android Auto Convenience – Pair compatible Android phones wirelessly (some models require wired connection) to mirror Google Maps, YouTube Music, WhatsApp, and Google Assistant on the touchscreen. Voice commands handle navigation and messaging while your hands remain on the wheel navigating varied conditions.

Latest Android 13 System – The upgraded NK 13.0 operating system provides enhanced security protocols, improved app compatibility, and refined performance over previous Android versions. Access Google Play Store to download navigation apps, streaming services, and entertainment options while the system manages updates automatically over WiFi.

Expanded 64GB Storage – Double the internal storage of earlier models accommodates extensive offline map data for regional touring, large music libraries with lossless audio files, multiple navigation apps for redundancy, and various Android applications running simultaneously without storage limitations.

Built-In GPS Navigation – Preloaded GPS data provides offline navigation capability when mobile coverage drops on regional highways or remote routes. Download alternative navigation apps from Google Play Store, update maps over WiFi, or run multiple navigation solutions for comprehensive coverage across Australian conditions.

High-Brightness IPS Display – The 1280×720 resolution IPS panel with 500nit brightness maintains excellent visibility in direct Australian sunlight, essential for RAV4 owners navigating sunny conditions. Wide viewing angles ensure passengers can see navigation details clearly, and the capacitive touchscreen responds intuitively like your smartphone.

Enhanced Pre-Output Signal – The 4V pre-output voltage delivers twice the signal strength of standard 2V units, reducing noise interference when driving external amplifiers. This clean signal improves sound quality in upgraded audio systems, ideal for RAV4 owners building custom audio configurations.

Factory Control Retention – CAN bus integration maintains functionality of factory Toyota RAV4 steering wheel controls where equipped, letting you adjust volume, skip tracks, and manage calls using existing buttons. The system adapts to Toyota's control protocols without requiring additional adapters.

Complete Installation Package – Includes RAV4 Dash 1-specific fascia panel, main wiring harness, RCA cables, camera cable, speaker cables, external microphone, GPS antenna, USB cables, and user manual. Everything required for installation is provided, though professional fitting is recommended for optimal integration with factory systems.

Technical Specs

• Display: 9" IPS touchscreen, 1280×720 resolution, 500nit brightness
• System: Android 13 (NK 13.0)
• Memory: 4GB RAM, 64GB internal storage
• Smartphone Integration: Wireless Apple CarPlay, Android Auto (wireless/wired depending on device)
• GPS: Built-in with preloaded data, updateable via Google Play Store
• Connectivity: WiFi
• Bluetooth: Version 5.0+EDR, 2.4GHz frequency, 5m range
• Radio Tuner: FM 87.5-108.0MHz, AM 522-1620kHz, RDS support, 18 FM/12 AM presets
• Audio Output: 4 channels × 50W maximum, 4-8Ω speaker impedance
• Pre-Outputs: 4V/10kΩ, ≤600Ω impedance (front left/right, rear left/right, subwoofer)
• Video Inputs: Reversing camera, front camera/auxiliary
• USB Interfaces: 4-pin (PhoneLink), 6-pin (media playback)
• USB Charging: 5V±0.25V/1A
• Video Formats: H264, MP4, AVI, MKV, FLV
• Audio Formats: MP3, APE, AAC, FLAC
• Power: 14.4V nominal (10.5-16V operating range)
• CAN Bus: Factory steering wheel control integration
• Microphone: External microphone included
• Antenna: GPS antenna included
• Fascia: Toyota RAV4 2001-2005 Dash 1 specific panel included

Compatible Vehicle:

• Toyota RAV4: 2001-2005 (second-generation, Dash 1 configuration only)

Package Includes:

• 1× Nakamichi head unit with RAV4 Dash 1-specific fascia panel
• 1× Main wiring harness
• 1× RCA cable
• 1× Camera cable
• 1× Rear left/right speaker cable
• 1× External microphone
• 1× GPS antenna
• 1× User manual
• 2× USB cables

Frequently Asked Questions

How do I know if I have Dash 1 configuration?

RAV4 models from 2001-2005 came with different dashboard layouts called Dash 1 and Dash 2. The easiest way to confirm your configuration is to send us a photo of your current dashboard and stereo area. We'll verify your dash type and ensure you receive the correct fascia panel and harness for proper fitment.

Is this specifically designed for my RAV4 generation?

Yes, this unit is engineered exclusively for second-generation Toyota RAV4 models from 2001-2005 with Dash 1 dashboard configuration. The fascia panel and wiring harness are configured specifically for this dash layout. Contact us with your exact RAV4 year and a dash photo before purchase to confirm compatibility.

Is CarPlay and Android Auto wireless or wired?

Apple CarPlay is wireless for all iPhones. Android Auto is wireless for most modern Android devices, but some specific phone brands may require wired USB connection via the included 4-pin PhoneLink cable. Both connection methods are fully supported through the dual USB interface.

Can I install Android apps from the Play Store?

Yes, the full Android 13 system provides access to Google Play Store. The 64GB internal storage accommodates navigation apps, music streaming services, video players, and most Android applications. Download offline maps, entertainment apps, and productivity tools directly to the unit.

Will my steering wheel controls continue to work?

Yes, CAN bus integration maintains factory Toyota RAV4 steering wheel control functionality where equipped. The system communicates directly with your vehicle's control protocols, allowing continued use of volume, track skip, and call management buttons without requiring additional adapters in typical installations.

Compatible With / Goes Well With

• Toyota RAV4 2001-2005 Dash 1 factory steering wheel control systems
• Aftermarket reversing cameras with composite video output
• External amplifiers via 4V RCA pre-outputs
• Component speakers and coaxial speakers (4Ω to 8Ω)
• Subwoofer systems via dedicated pre-output
• GPS antenna extension cables for optimal signal placement
• Front-facing dash cameras via auxiliary video input
• Android Auto-compatible apps from Google Play Store
• WiFi-enabled streaming services and navigation apps
• Professional installation services for dash-specific integration
