Nakamichi 9" Wireless CarPlay Android Auto Toyota Prius V 2012-2019 Head Unit

Upgrade your Toyota Prius V hybrid with wireless smartphone integration and Android 13 capability.

Product Overview

The Nakamichi NA9TOYOTAPRIUSV20122019 transforms your Toyota Prius V's factory infotainment into a comprehensive Android 13 multimedia system with wireless Apple CarPlay and Android Auto integration. This vehicle-specific 9-inch IPS touchscreen head unit is engineered exclusively for Toyota Prius V hybrid wagons from 2012-2019, replacing the factory display with a plug-and-play solution that includes the matching fascia panel for seamless dashboard integration. The system works directly with your factory Prius V reversing camera, eliminating the need for additional adapters or complex wiring modifications. Running Android 13 (NK 13.0) with 4GB RAM and 64GB internal storage, the system delivers smooth performance across navigation, media playback, and app multitasking while providing ample space for offline maps, music libraries, and Android apps from the Google Play Store. Beyond smartphone mirroring, the system includes built-in GPS with preloaded navigation data, WiFi connectivity, comprehensive AM/FM radio with RDS supporting 18 FM and 12 AM presets, and Bluetooth 5.0 for hands-free calling and wireless audio streaming. The 4×50W amplifier drives factory Prius V speakers or upgraded components, while 4V pre-outputs provide clean signal to external amplifiers. Factory steering wheel controls are retained via CAN bus integration, maintaining the efficient control experience Prius V owners expect during eco-conscious driving and family transportation duties.

Key Specifications

• 9-inch IPS touchscreen display with 1280×720 resolution and 500nit brightness
• Android 13 operating system (NK 13.0)
• 4GB RAM with 64GB internal storage
• Wireless Apple CarPlay and Android Auto (wired for some Android devices)
• Built-in GPS with preloaded navigation data, updateable via Google Play Store
• WiFi connectivity for internet access and app functionality
• Bluetooth 5.0+EDR (2.4GHz, 5m range)
• AM/FM radio tuner: FM 87.5-108.0MHz, AM 522-1620kHz with 18 FM/12 AM presets
• 4×50W maximum amplifier output to 4-8Ω speakers
• 4V/10kΩ pre-outputs with ≤600Ω impedance for external amplifiers
• Factory reversing camera compatibility (plug-and-play)
• Front camera/auxiliary video input
• Dual USB interfaces: 4-pin for PhoneLink, 6-pin for media playback
• Factory steering wheel control compatibility via CAN bus integration
• External microphone included for enhanced hands-free clarity
• Video format support: H264, MP4, AVI, MKV, FLV
• Audio format support: MP3, APE, AAC, FLAC
• 10.5-16V operating voltage range (14.4V nominal)
• Includes Prius V-specific fascia panel for 2012-2019 models
• Compatible exclusively with Toyota Prius V 2012-2019

Features & Benefits

Prius V-Specific Engineering – Designed exclusively for Toyota Prius V hybrid wagons from 2012-2019 with included fascia panel that matches your factory dash perfectly. Plug-and-play harnesses connect to existing wiring without cutting or splicing, maintaining the reliability standards Toyota engineered into this efficient hybrid platform.

Factory Camera Integration – Works directly with your Toyota Prius V factory reversing camera without requiring additional adapters or complex hardwiring. The system switches automatically to rear view when you select reverse gear, maintaining the safety feature Toyota designed into your hybrid wagon for parking and low-speed maneuvers.

Wireless CarPlay Freedom – Connect your iPhone wirelessly and access Apple Maps, Spotify, Messages, and Siri through the 9-inch display without cable clutter. The system remembers your device and connects automatically when you start your Prius V, keeping your charging port available for other devices during eco-conscious commuting or family road trips.

Android Auto Convenience – Pair compatible Android phones wirelessly (some models require wired connection) to mirror Google Maps, YouTube Music, WhatsApp, and Google Assistant on the touchscreen. Voice commands handle navigation and messaging while your hands remain on the wheel maximizing hybrid efficiency through smooth, distraction-free driving.

Latest Android 13 System – The upgraded NK 13.0 operating system provides enhanced security protocols, improved app compatibility, and refined performance over previous Android versions. Access Google Play Store to download navigation apps, fuel economy tracking tools, and entertainment options while the system manages updates automatically over WiFi.

Expanded 64GB Storage – Double the internal storage of earlier models accommodates extensive offline map data for regional commuting routes, large music libraries with lossless audio files, multiple navigation apps for comprehensive coverage, and various Android applications running simultaneously without storage limitations during daily hybrid use.

Built-In GPS Navigation – Preloaded GPS data provides offline navigation capability when mobile coverage drops on regional routes or areas with limited cellular reception. Download alternative navigation apps from Google Play Store, update maps over WiFi, or run multiple navigation solutions optimized for eco-routing and efficient journey planning.

High-Brightness IPS Display – The 1280×720 resolution IPS panel with 500nit brightness maintains excellent visibility in direct Australian sunlight, essential for Prius V owners navigating sunny conditions during daily commutes and weekend family outings. Wide viewing angles ensure passengers can see navigation details clearly, and the capacitive touchscreen responds intuitively.

Enhanced Pre-Output Signal – The 4V pre-output voltage delivers twice the signal strength of standard 2V units, reducing noise interference when driving external amplifiers. This clean signal improves sound quality in upgraded audio systems, ideal for Prius V owners seeking premium audio quality without compromising the hybrid's efficiency focus.

Complete Installation Package – Includes Prius V-specific fascia panel, main wiring harness, RCA cables, camera cable, speaker cables, external microphone, GPS antenna, USB cables, and user manual. Everything required for installation is provided, though professional fitting is recommended for optimal integration with hybrid vehicle systems.

Technical Specs

• Display: 9" IPS touchscreen, 1280×720 resolution, 500nit brightness
• System: Android 13 (NK 13.0)
• Memory: 4GB RAM, 64GB internal storage
• Smartphone Integration: Wireless Apple CarPlay, Android Auto (wireless/wired depending on device)
• GPS: Built-in with preloaded data, updateable via Google Play Store
• Connectivity: WiFi
• Bluetooth: Version 5.0+EDR, 2.4GHz frequency, 5m range
• Radio Tuner: FM 87.5-108.0MHz, AM 522-1620kHz, RDS support, 18 FM/12 AM presets
• Audio Output: 4 channels × 50W maximum, 4-8Ω speaker impedance
• Pre-Outputs: 4V/10kΩ, ≤600Ω impedance (front left/right, rear left/right, subwoofer)
• Video Inputs: Factory reversing camera (compatible), front camera/auxiliary
• USB Interfaces: 4-pin (PhoneLink), 6-pin (media playback)
• USB Charging: 5V±0.25V/1A
• Video Formats: H264, MP4, AVI, MKV, FLV
• Audio Formats: MP3, APE, AAC, FLAC
• Power: 14.4V nominal (10.5-16V operating range)
• CAN Bus: Factory steering wheel control integration
• Microphone: External microphone included
• Antenna: GPS antenna included
• Fascia: Toyota Prius V 2012-2019 specific panel included

Compatible Vehicle:

• Toyota Prius V: 2012-2019 (all trim levels including i-Tech variants)

Package Includes:

• 1× Nakamichi head unit with Prius V-specific fascia panel
• 1× Main wiring harness
• 1× RCA cable
• 1× Camera cable
• 1× Rear left/right speaker cable
• 1× External microphone
• 1× GPS antenna
• 1× User manual
• 2× USB cables

Frequently Asked Questions

Is this specifically designed for my Prius V?

Yes, this unit is engineered exclusively for Toyota Prius V hybrid wagons from 2012-2019. The included fascia panel and wiring harness are configured for Prius V-specific integration. Contact us with your exact Prius V year and trim level plus a photo of your current dash to confirm harness compatibility before purchase.

Will my factory reversing camera work with this unit?

Yes, the system is designed to work directly with Toyota Prius V factory reversing cameras without requiring additional adapters or complex wiring. The camera cable connects to your existing camera wiring, and the display switches automatically to rear view when you select reverse gear.

Is CarPlay and Android Auto wireless or wired?

Apple CarPlay is wireless for all iPhones. Android Auto is wireless for most modern Android devices, but some specific phone brands may require wired USB connection via the included 4-pin PhoneLink cable. Both connection methods are fully supported through the dual USB interface.

Can I install Android apps from the Play Store?

Yes, the full Android 13 system provides access to Google Play Store. The 64GB internal storage accommodates navigation apps, music streaming services, fuel economy tracking applications, and most Android apps. Download offline maps, entertainment apps, and productivity tools directly to the unit.

Will my steering wheel controls continue to work?

Yes, CAN bus integration maintains factory Toyota Prius V steering wheel control functionality. The system communicates directly with your hybrid vehicle's control protocols, allowing continued use of volume, track skip, and call management buttons without requiring additional adapters.

Compatible With / Goes Well With

• Toyota Prius V 2012-2019 factory reversing cameras (plug-and-play)
• Factory Prius V steering wheel control systems
• External amplifiers via 4V RCA pre-outputs
• Component speakers and coaxial speakers (4Ω to 8Ω)
• Subwoofer systems via dedicated pre-output
• GPS antenna extension cables for optimal signal placement
• Front-facing dash cameras via auxiliary video input
• Android Auto-compatible apps from Google Play Store
• Fuel economy tracking and eco-driving applications
• WiFi-enabled streaming services and navigation apps
• Professional installation services for hybrid vehicle integration
