Nakamichi NAXSUZUKISWIFT2017ON - 10" Android Wireless CarPlay & GPS Navigation System

Upgrade your 2017+ Suzuki Swift with a commanding 10-inch display, full Android capability, and wireless smartphone integration with built-in GPS.

Product Overview

The Nakamichi NAXSUZUKISWIFT2017ON transforms your Suzuki Swift (2017 onwards) with a premium 10-inch multimedia system featuring full Android functionality, wireless CarPlay, Android Auto, and built-in GPS navigation. This vehicle-specific receiver runs a complete NK 13.0 Android system with 4GB RAM and 64GB storage, enabling direct app downloads from Google Play Store, multiple navigation platforms, and extensive customization that goes far beyond basic phone-mirroring solutions.

The expansive 10-inch IPS display delivers 1280×720 resolution with 500-nit brightness for exceptional visibility in Australian conditions, while the Swift-specific design includes colour-matched fascia and pre-configured wiring harness for seamless dashboard integration. The larger screen size provides significantly improved map visibility and touch target accuracy compared to smaller aftermarket units—particularly valuable for Swift's younger, tech-savvy demographic who expect modern smartphone-like interfaces.

Factory steering wheel controls integrate via CANBUS, maintaining safe, eyes-on-road operation while accessing voice commands, volume, and track controls. The built-in GPS module comes preloaded with navigation data, with flexibility to update or install alternative mapping apps through the Android platform—ideal for urban commuters and weekend adventurers alike. Audio capabilities include 4×50W amplification with dedicated subwoofer output and 4V pre-amp connections for external amplifiers, while dual video inputs support reverse cameras and auxiliary video sources. The system maintains full AM/FM radio with 30 station presets and includes GPS antenna, microphone, and all necessary cables.

Key Specifications

• Full Android system (NK 13.0) with 4GB RAM and 64GB internal storage
• Wireless Apple CarPlay and Android Auto (some Android devices require wired connection)
• Built-in GPS navigation with preloaded maps and Google Play Store access
• 10-inch IPS touchscreen with 1280×720 resolution and 500-nit brightness
• Vehicle-specific fit for Suzuki Swift 2017+ (AZ series, including Swift Sport)
• Bluetooth 5.0 with Enhanced Data Rate (EDR) for wireless connectivity
• Factory steering wheel control compatibility via CANBUS integration
• 4×50W maximum power output with 4V/10KΩ pre-amp outputs
• Dual USB interface: 4-pin for smartphone, 6-pin for media files
• FM (87.5-108.0MHz) and AM (522-1620KHz) radio with 30 total presets
• Multiple video inputs: reverse camera and front auxiliary camera support
• Operating voltage range: 10.5-16V DC (14.4V nominal)

Features & Benefits

10-inch display advantage provides substantially more screen real estate than 7-9 inch units, making navigation maps easier to read at a glance, touch targets larger and more accurate, and split-screen functionality more practical. For Swift's compact cabin, the larger display transforms the driving experience without overwhelming the dashboard proportions.

Full Android operating system provides unrestricted access to Google Play Store for downloading Spotify, YouTube Music, Waze, Sygic, offline media players, and thousands of other apps. Unlike locked-down systems, you control exactly what runs on your Swift's screen—perfect for drivers who want maximum flexibility and customization.

Built-in GPS with offline capability eliminates reliance on phone data during travel. Preloaded maps work immediately, and you can download comprehensive offline navigation from Play Store—essential for avoiding data charges during daily city commutes or weekend coastal drives where mobile coverage can be patchy.

Wireless smartphone integration connects your iPhone or Android device without cables for instant access to navigation, hands-free calling, messaging, and streaming music through Apple CarPlay or Android Auto. The system intelligently switches between native Android apps and phone mirroring based on your preference and connectivity status.

Vehicle-specific engineering ensures the 10-inch IPS display integrates perfectly into your Swift's dashboard with included colour-matched fascia and factory-specification wiring harness. CANBUS integration maintains steering wheel controls for volume, track skip, and voice commands without aftermarket adapters or functionality loss—critical for Swift Sport models with multi-function steering wheels.

Premium IPS display technology delivers superior viewing angles and colour accuracy compared to standard TFT screens, with 500-nit brightness that remains clearly visible in direct Australian sunlight. The 1280×720 resolution provides crisp text rendering for navigation prompts and messaging—a massive upgrade from smaller factory displays.

Expandable storage and performance with 4GB RAM and 64GB internal storage allows you to store extensive offline music libraries, download high-resolution maps for entire regions, and run multiple apps simultaneously without lag—crucial for younger Swift owners who expect smartphone-level performance from their in-car tech.

Comprehensive audio architecture provides 4×50W amplification for factory speakers plus dedicated subwoofer output and 4V pre-amp connections for adding external amplifiers. Whether maintaining stock audio or building a performance sound system befitting the Swift Sport's character, the NAX accommodates your upgrade path.

Dual video input support accommodates reverse cameras and optional front-facing cameras for comprehensive visibility. Particularly valuable for Swift owners navigating tight urban car parks or those who've added front splitters and want forward visibility assistance when parking close to kerbs.

Technical Specs

• Screen size: 10 inches diagonal
• Display type: IPS (In-Plane Switching) LCD
• Display resolution: 1280×720 pixels
• Brightness: 500 nit
• Operating system: NK 13.0 (Android-based)
• RAM: 4GB
• Internal storage: 64GB
• Operating voltage: 14.4V nominal (10.5-16V range)
• Maximum power output: 4×50W
• Pre-amp output voltage: 4V/10KΩ
• Pre-amp output impedance: ≤600Ω
• Speaker impedance compatibility: 4-8Ω
• Bluetooth version: 5.0 + EDR
• Bluetooth frequency: 2.4GHz
• Bluetooth range: up to 5m
• GPS: Built-in with external antenna (included)
• FM frequency range: 87.5-108.0MHz
• AM frequency range: 522-1620KHz
• FM presets: 18 stations
• AM presets: 12 stations
• USB charging output: 5V±0.25V/1A
• Video formats supported: H264, MP4, AVI, MKV, FLV
• Audio formats supported: MP3, APE, AAC, FLAC
• CANBUS integration: CAN RX/TX connector
• WiFi: Integrated (for app downloads and updates)
• Video inputs: Reverse camera + front auxiliary camera

Frequently Asked Questions

Will this fit my Swift Sport?

Yes, the NAX is compatible with all 2017+ Suzuki Swift variants including Swift Sport, GL, GLX, and GL Navigator. The unit fits both standard Swift and Swift Sport models (AZ series) with included vehicle-specific fascia and maintains compatibility with Sport's multi-function steering wheel controls.

Does the 10-inch screen look too big?

The 10-inch display is proportioned specifically for the Swift's dashboard and doesn't overwhelm the cabin. The larger screen significantly improves map readability and touch accuracy compared to smaller units, making it easier to use while driving—particularly valuable for navigation in unfamiliar areas.

Can I use navigation without my phone?

Absolutely. The built-in GPS with preloaded maps operates independently of your smartphone. Download additional offline navigation apps like Sygic, HERE WeGo, or Google Maps offline regions from Play Store for phone-free navigation—ideal for avoiding data charges during city commuting.

Will my steering wheel controls work?

Yes, the NAX includes CANBUS integration (CAN RX/TX interface) that maintains full compatibility with your Swift's factory steering wheel controls for volume adjustment, track skip, source selection, and voice command activation—including Swift Sport's additional steering wheel buttons.

How much storage is available for apps and music?

The system includes 64GB of internal storage for apps, offline maps, and media files. After system files, approximately 50-55GB remains available for your use—sufficient for multiple offline map regions, extensive music libraries, podcast downloads, and numerous apps.

Compatible With / Goes Well With

Confirmed vehicle compatibility:

• Suzuki Swift AZ series (2017-current Australian market)
• Swift GL, GLX, GL Navigator variants
• Swift Sport (all specifications including turbo models)
• Compatible with both manual and CVT automatic transmission models

Installation accessories (vehicle-specific harness included):

• Compatible with Nakamichi/Aerpro/CAC Suzuki fascia kits
• Works with factory and aftermarket steering wheel control interfaces
• Supports Swift Sport multi-function steering wheel controls
• Compatible with factory speaker systems

Recommended upgrades:

• Aftermarket component speakers (6.5" front coaxial or component)
• Compact 4-channel amplifiers for enhanced audio clarity
• Reverse cameras with composite video output and wide-angle lens
• GPS antenna extension cables for optimal satellite reception
• USB extension cables for centre console smartphone mounting

Software compatibility:

• Google Maps (via Android Auto or native Android)
• Waze (via Android Auto or native Android)
• Spotify, Apple Music, YouTube Music (via CarPlay or native apps)
• Sygic GPS Navigation (downloadable from Play Store)
• TuneIn Radio, Pocket Casts (for podcasts and streaming radio)
• Torque Pro OBD2 diagnostics (with compatible adapter)

Popular Swift audio upgrades:

• 6.5" coaxial speakers for front doors (replace factory speakers)
• Compact under-seat powered subwoofers (8-10 inch)
• 4-channel amplifiers (50-75W RMS per channel)
• Sound deadening kits for door panels and boot

Swift Sport specific upgrades:

• Performance-tuned component speaker sets
• Compact high-power amplifiers for spirited driving soundtrack
• OBD2 adapters for performance monitoring apps

Note: All 2017+ Swift models receive vehicle-matched fascia and harness. Swift Sport owners should confirm steering wheel control button count when ordering to ensure correct CANBUS programming. Send dashboard photos with year and variant for accurate fitment confirmation.
