Nakamichi NA9SUZUKIALTO20092014 9" Android Wireless CarPlay Head Unit Suzuki Alto 2009-2014

Transform Your Suzuki Alto with Full Smartphone Integration

Product Overview

The Nakamichi NA9SUZUKIALTO20092014 delivers seamless wireless Apple CarPlay and Android Auto integration engineered specifically for 2009-2014 Suzuki Alto models. This 9-inch touchscreen head unit replaces your factory stereo with a modern Android-based system featuring built-in GPS navigation, Bluetooth 5.0 connectivity, and full steering wheel control compatibility. Designed for direct plug-and-play installation with included vehicle-specific fascia and harnesses, this unit transforms your daily commute with hands-free calling, real-time navigation, and instant access to your favourite apps—all while maintaining factory functionality.

The system runs on NK 13.0 Android OS with 4GB RAM and 64GB storage, providing responsive performance for multitasking between navigation, music streaming, and hands-free communication. The 1280×720 IPS display delivers clear visibility in Australian sunlight with 500 nit brightness, while the wireless connectivity eliminates cable clutter for iPhone users and selected Android devices.

Key Specifications

• Factory-engineered fit for Suzuki Alto 2009-2014 models with included fascia panel
• 9-inch IPS touchscreen with 1280×720 resolution and 500 nit brightness
• Wireless Apple CarPlay and Android Auto (wired connection for specific Android brands)
• NK 13.0 Android operating system with 4GB RAM and 64GB internal storage
• Built-in GPS with preloaded map data, updatable via Google Play Store
• Bluetooth 5.0 with Enhanced Data Rate for hands-free calling and audio streaming
• AM/FM radio with 18 FM and 12 AM presets
• 4×50W maximum power output with 4V pre-out for external amplification
• Compatible with factory steering wheel controls via included harness
• Reverse camera input and auxiliary video input for dash cameras
• Dual USB interfaces: 4-pin for smartphone connection, 6-pin for media playback

Features & Benefits

Wireless smartphone mirroring keeps cables off your dash. Wireless CarPlay connects your iPhone automatically when you start the car, while Android Auto pairs compatible devices without fumbling with cables—ideal for quick trips around Perth or long highway runs where you need navigation and music ready instantly.

Vehicle-specific installation eliminates modification guesswork. The included fascia panel and main harness are pre-configured for 2009-2014 Suzuki Alto dashboards, maintaining factory appearance while adding modern functionality. Steering wheel controls remain fully operational, preserving your ability to adjust volume and skip tracks without reaching for the screen.

Built-in GPS works offline when mobile data drops. Preloaded GPS map data ensures navigation continues through remote areas and mobile black spots common on Australian regional roads. Update maps via Google Play Store when connected to Wi-Fi, or download alternative navigation apps for backup routing options.

Bluetooth 5.0 delivers clear hands-free calling in noisy environments. Enhanced Data Rate technology maintains stable connections and clear audio quality even with road noise, making phone calls safer and more practical during commutes or while running errands around town.

High-brightness IPS display stays readable in direct sunlight. The 500 nit screen maintains visibility during harsh Australian summer conditions, while the 1280×720 resolution provides crisp text for navigation instructions and contact lists. The IPS panel offers wide viewing angles for both driver and passenger visibility.

Expandable audio system supports aftermarket upgrades. The 4V pre-output voltage drives external amplifiers for improved sound quality, while dedicated subwoofer output allows bass expansion. Rear left and right speaker outputs support four-speaker configurations, with amplifier control signal for automatic power management.

Dual-camera capability enhances safety and security. Connect a reverse camera for parking assistance and a front-facing dash camera simultaneously. Both inputs display on the 9-inch screen, providing visual awareness for tight parking situations and incident recording during daily driving.

Technical Specs

• Screen: 9" IPS touchscreen, 1280×720 resolution, 500 nit brightness
• Operating System: NK 13.0 Android
• Memory: 4GB RAM, 64GB ROM
• Wireless Connectivity: Wireless Apple CarPlay, Wireless/Wired Android Auto
• Bluetooth: Version 5.0 with Enhanced Data Rate, 2.4GHz frequency, 5m range
• GPS: Built-in GPS receiver with external antenna
• Radio: FM 87.5-108.0 MHz (18 presets), AM 522-1620 kHz (12 presets)
• Audio Output: 4×50W maximum power, 4V/10KΩ pre-output
• Speaker Impedance: 4-8Ω compatible
• Pre-Output Impedance: ≤600Ω
• Audio Outputs: Front L/R, Rear L/R, Subwoofer, Amplifier Control
• Video Inputs: Reverse camera input, AUX video input (F_CAMERA)
• USB Interfaces: 4-pin USB (smartphone connection), 6-pin USB (media playback)
• Additional Inputs: Radio antenna, GPS antenna, external microphone, brake detection, CAN-bus interface
• Power: 14.4V operating voltage (10.5-16V range), USB 5V±0.25V/1A output
• Video Formats: H264, MP4, AVI, MKV, FLV
• Audio Formats: MP3, APE, AAC, FLAC
• Compatibility: Suzuki Alto 2009-2014 models with steering wheel control retention

Frequently Asked Questions

Does this fit all Suzuki Alto models from 2009 to 2014?
Yes, this unit is engineered specifically for 2009-2014 Suzuki Alto dashboards. The included fascia and harness ensure direct fitment without modifications. Please message your dash photo and car year when ordering to confirm correct harness compatibility.

Will my factory steering wheel controls still work?
Yes, the included harness maintains full steering wheel control functionality. Volume adjustment, track skipping, and call answering remain operational through your factory buttons without additional programming required.

Is Android Auto wireless or do I need a cable?
Android Auto connectivity depends on your phone brand. Most modern Android devices support wireless connection, but some specific brands require wired USB connection. iPhone users enjoy fully wireless CarPlay operation for all compatible iPhone models.

Can I use this without connecting my phone?
Yes, the built-in Android OS operates independently. Access preloaded GPS maps, play media from USB or SD card, listen to AM/FM radio, and connect Bluetooth audio sources without smartphone connection. The system functions as a standalone Android tablet.

What's included for installation and do I need additional parts?
The package includes head unit with fascia, main harness, RCA cable, camera cable, rear speaker cable, microphone, GPS antenna, user manual, and two USB cables. Different Alto variants may require specific accessories—contact us with your dash photo for confirmation before purchase.

Compatible With / Goes Well With

• Suzuki Alto GF 2009-2014 (all trim levels)
• Aftermarket reverse cameras with RCA video output
• External amplifiers requiring 4V pre-out signal
• Powered subwoofers with RCA input
• Dash cameras with AUX video input capability
• Factory Suzuki steering wheel control systems
• Standard 4-8Ω aftermarket speakers
• GPS external antennas for improved satellite reception
