Nakamichi NA9MAZDABT5020122019 9" Wireless CarPlay Mazda BT-50 2012-2019

Equip Your BT-50 Workhorse with Professional Technology

Product Overview

The Nakamichi NA9MAZDABT5020122019 delivers wireless Apple CarPlay and Android Auto to 2012-2019 Mazda BT-50 models through a rugged 9-inch touchscreen system with three distinct installation configurations. This Android-based head unit transforms your proven work ute's communication and navigation capabilities with built-in GPS, Bluetooth 5.0 connectivity, and full steering wheel control compatibility. Engineered for Mazda's durable work truck that shares its DNA with the Ford Ranger, this unit provides modern smartphone connectivity for worksite navigation, towing operations, and weekend adventure travel—note that installation options vary based on factory specifications, with Options 2 and 3 requiring factory camera hardwiring.

The system operates on NK 13.0 Android OS with 4GB RAM and 64GB storage, delivering dependable performance whether you're navigating to remote worksites, coordinating deliveries across regional WA, or planning weekend fishing trips. The 9-inch 1280×720 IPS display with 500 nit brightness remains visible through dust, direct sunlight, and demanding conditions typical of genuine dual-purpose ute use. Critical to successful installation: you must specify your installation option (1, 2, or 3) when ordering to receive the correct accessories for your specific BT-50 configuration.

Key Specifications

• Factory-engineered fit for Mazda BT-50 2012-2019 across three installation configuration options
• 9-inch IPS touchscreen with 1280×720 resolution and 500 nit brightness
• Wireless Apple CarPlay and Android Auto (wired connection for specific Android brands)
• NK 13.0 Android operating system with 4GB RAM and 64GB internal storage
• Built-in GPS with preloaded map data, updatable via Google Play Store
• Bluetooth 5.0 with Enhanced Data Rate for hands-free calling and audio streaming
• AM/FM radio with 18 FM and 12 AM preset stations
• 4×50W maximum power output with 4V pre-out for external amplification
• Compatible with factory steering wheel controls via included harness
• Reverse camera input (Options 2 & 3 require factory camera hardwiring)
• Auxiliary video input for dash cameras
• Dual USB interfaces: 4-pin for smartphone connection, 6-pin for media playback
• CAN-bus interface for vehicle integration
• Three installation options requiring correct accessory selection based on factory configuration

Installation Options Overview

Option 1: Base Configuration
Standard installation for BT-50 models with basic factory specifications. Includes appropriate fascia adapter and harness for straightforward integration with steering wheel control retention.

Option 2: Mid-Specification Models
For BT-50 models with specific factory equipment configurations. Different accessory package from Option 1. Important: If your BT-50 has a factory reverse camera, hardwiring is required during installation for camera retention. Budget additional installation time for camera integration.

Option 3: Higher-Specification Models
For BT-50 models with advanced factory equipment configurations. Distinct accessory package requirements. Important: If your BT-50 has a factory reverse camera, hardwiring is required during installation for camera retention. Professional installation recommended for proper camera integration and harness connection.

Features & Benefits

Configuration-specific installation ensures proper BT-50 fitment. Three distinct installation options accommodate the diverse factory specifications across 2012-2019 BT-50 production—from base work truck configurations to higher-specification models with additional features. This comprehensive approach ensures proper integration regardless of your BT-50's original factory equipment level.

Wireless smartphone mirroring for dual-purpose lifestyle. Wireless CarPlay and Android Auto eliminate cable clutter in work trucks where tools, safety gear, and equipment already compete for cabin space—ideal for navigating to job sites, coordinating trailer pickups, finding launch ramps, or planning weekend camping trips without cables tangling across the centre console.

Built-in GPS navigates worksites and adventure destinations. Preloaded GPS map data ensures continuous navigation to remote construction sites, rural properties, coastal fishing locations, and regional touring tracks. Install specialized apps like Hema Maps for detailed off-road navigation, or use real-time traffic for efficient metropolitan worksite routing during peak hour deliveries.

Rugged construction withstands demanding ute conditions. The 9-inch IPS screen maintains visibility through worksite dust, diesel exhaust glare, and harsh Australian sun exposure. The 500 nit brightness cuts through dashboard reflections, while the chassis design handles constant vibration from corrugated site access roads and heavy towing loads typical of genuine work truck use.

Factory camera retention with appropriate planning. Options 2 and 3 installations can retain factory reverse cameras through hardwiring during installation. While not plug-and-play like Option 1, proper camera hardwiring maintains your existing parking assistance—essential for confident reversing with loaded trays, towing boat trailers, or navigating tight worksite access. Budget additional installation time accordingly.

Bluetooth 5.0 delivers clear communication in noisy environments. Enhanced Data Rate technology maintains stable connections even with diesel engine noise, wind buffeting through open windows, and worksite background sounds—making hands-free client calls, site coordination, and dispatch communication practical and legal during work hours or weekend touring across regional areas.

Steering wheel control retention maintains driving focus. Factory steering wheel controls remain operational for volume adjustment and track control—essential when towing trailers where taking hands off the wheel creates risk, or during loaded tray driving where concentration on balance prevents accidents during worksite operations.

Expandable audio system supports touring upgrades. The 4V pre-output voltage drives external amplifiers to overcome engine, tire, and wind noise during towing or touring. Dedicated subwoofer output and four-channel speaker connections support audio upgrades for long-distance comfort during multi-hour regional drives or extended fishing trip travel.

Dual-camera capability enhances work and recreation safety. While factory reverse cameras (Options 2 & 3) aid towing operations and worksite reversing, auxiliary video inputs accommodate front-facing dash cameras for incident recording during worksite driving, insurance documentation, or journey recording during family adventure trips where evidence of track conditions matters.

Critical: Specify your installation option when ordering. You must identify which option (1, 2, or 3) matches your BT-50's factory configuration to receive the correct accessories. Different options use different fascia adapters and harnesses. Contact us with your dash photo, car year, and factory specification details for confirmation before purchase.

Technical Specs

• Screen: 9" IPS touchscreen, 1280×720 resolution, 500 nit brightness
• Operating System: NK 13.0 Android
• Memory: 4GB RAM, 64GB ROM
• Wireless Connectivity: Wireless Apple CarPlay, Wireless/Wired Android Auto
• Bluetooth: Version 5.0 with Enhanced Data Rate, 2.4GHz frequency, 5m range
• GPS: Built-in GPS receiver with external antenna
• Radio: FM 87.5-108.0 MHz (18 presets), AM 522-1620 kHz (12 presets)
• Audio Output: 4×50W maximum power, 4V/10KΩ pre-output
• Speaker Impedance: 4-8Ω compatible
• Pre-Output Impedance: ≤600Ω
• Audio Outputs: Front L/R, Rear L/R, Subwoofer, Amplifier Control
• Video Inputs: Reverse camera input (Options 2 & 3 require factory camera hardwiring), AUX video input (F_CAMERA)
• USB Interfaces: 4-pin USB (smartphone connection), 6-pin USB (media playback)
• Additional Inputs: Radio antenna, GPS antenna, external microphone, brake detection, CAN-bus interface (RX/TX)
• Power: 14.4V operating voltage (10.5-16V range), USB 5V±0.25V/1A output
• Video Formats: H264, MP4, AVI, MKV, FLV
• Audio Formats: MP3, APE, AAC, FLAC
• Compatibility: Mazda BT-50 2012-2019 with steering wheel control retention
• Installation: Three configuration-specific options requiring correct accessory selection
• Camera Note: Options 2 & 3 require factory camera hardwiring (not plug-and-play)

Frequently Asked Questions

How do I know which installation option I need?
You need to identify your BT-50's factory specification level. Option 1 suits base models, Options 2 & 3 suit models with different factory equipment configurations. If you have a factory reverse camera, you'll need Option 2 or 3 (both require camera hardwiring). Message us with your dash photo, car year, and factory specification details when ordering so we can confirm the correct option.

What if my BT-50 has a factory reverse camera?
Factory reverse cameras require Options 2 or 3, and both require hardwiring during installation (not plug-and-play). The camera will display on the new head unit screen, but proper hardwiring is necessary for signal connection. Budget additional installation time for camera integration. Professional installation is recommended for proper camera hardwiring.

Will my factory steering wheel controls still work?
Yes, all three installation options include harnesses that maintain steering wheel control functionality. Volume adjustment, track skipping, call answering, and source selection remain operational through your factory steering wheel buttons without additional programming—essential for safe operation during towing or worksite driving.

Can this handle worksite and towing conditions?
Yes, the unit is designed to withstand vibration, dust, heat, and demanding conditions typical of genuine dual-purpose ute use. The IPS screen remains visible in harsh sunlight and dusty worksite environments, while the electronics handle temperature extremes and constant vibration during towing and worksite access road driving.

What's included for installation and do I need additional parts?
The package includes head unit, option-specific fascia adapter, main harness, RCA cable, camera cable, rear speaker cable, microphone, GPS antenna, user manual, and two USB cables. You must specify your installation option (1, 2, or 3) when ordering. Options 2 & 3 with factory cameras require hardwiring during installation. Contact us with your dash photo for confirmation.

Compatible With / Goes Well With

• Mazda BT-50 2012-2019 (all trim levels across three installation options)
• Mazda BT-50 base models (Option 1)
• Mazda BT-50 mid-specification models (Option 2)
• Mazda BT-50 higher-specification models (Option 3)
• Factory Mazda BT-50 steering wheel control systems
• Factory Mazda BT-50 reverse cameras (Options 2 & 3, hardwiring required)
• Aftermarket reverse cameras with RCA video output
• Heavy-duty dash cameras for work vehicle documentation
• External amplifiers requiring 4V pre-out signal
• Powered subwoofers suitable for diesel vehicle noise environments
• Standard 4-8Ω aftermarket speakers rated for work truck conditions
• GPS external antennas for enhanced reception in remote worksites
• Specialized navigation apps (Hema Maps, Mud Map, CamperMate)
• Towing accessories requiring reverse camera visibility
• UHF radio systems for worksite or convoy communication
• Dual battery systems for extended work use
