Crystal Mobile DBH50M 5W 80-Channels Pro Handheld Waterproof UHF CB Radio
Click to open expanded view
CRYSTAL MOBILE logo

Discontinued

Crystal Mobile DBH50M 5W 80-Channels Pro Handheld Waterproof UHF CB Radio

SKU: DBH50M

No Longer Available. Please contact us for recommendations or alternatives. (02) 4257-2636

Shipping information

We offer fast and reliable shipping options to ensure that your order arrives in a timely manner. Our dedicated team works diligently to process and ship your items as quickly as possible.

Here are some key points to note about our shipping policy:

Standard Shipping

  • Frankies offers a $15.95 flat rate for Australia-wide shipping, no matter how many items you order. Some larger or heavier items may incur an additional fee, which will be communicated to you when your order is processed.
  • While we endeavour to dispatch all orders promptly, please be advised that due to the current national fuel shortages in Australia and the resulting pressure on logistics networks, order processing and dispatch may take up to 7 business days. We are not liable for delays caused by third-party freight carriers or fuel-related logistical disruptions. By placing an order, you acknowledge that delivery timeframes may be extended beyond our standard estimates during this period.

Estimated delivery times:

  • WA, NT, and TAS: currently experiencing longer shipping times
  • Holiday periods (e.g. Christmas): deliveries may be delayed due to increased freight volumes

Express Shipping

  • Express shipping is available and calculated based on your delivery location, as well as the size and weight of your order. To receive an accurate quote, please contact our Albion Park Rail store and request an "express shipping quote." Our team will promptly assist with pricing and availability. Payment for express shipping can be securely arranged over the phone.

Share this product

Share Post Pin E-mail

Product features

Ideal For Professional Use & the Serious Off-Roader!

Waterproof 5W Handheld UHF CB Radio
The Crystal Mobile DBH50M Handheld UHF CB Radio is loaded with all the features you would expect to find in our full size in-car UHF radio including 80 channels, 83 DCS codes, duplex range extender, 38 DTCSS codes and the list goes on. Not only does the DBH50M feature a sturdy aluminium die-cast chassis, but it is also IP67 Waterproof and Dustproof. The powerful 5W power output provides a communication radius of up to 15 km. (Depending on terrain and atmospheric conditions)

Notes:

  • Free programming software is available at http://tdj.com.au/firmware/Crystal/DBH50M/
  • Info on IP ratings can be found here: http://www.dsmt.com/resources/ip-rating-chart/

Features:

  • Professional Series
  • IP67 Waterproof & Dustproof Rated
  • Aluminium Diecast Chassis
  • 5 Watts Power Output
  • 80 Narrow Band Channels
  • Rechargeable Lithium-Ion 1500mAh Battery (1500mAh Battery Included, 12V & 240V Chargers Included)
  • Automatic Squelch Control
  • 83 DCS Codes
  • 38 CTCSS Codes
  • Duplex Range Extension
  • Channel Scanning
  • Dual Channel Monitor
  • Hands-Free VOX Capable
  • Easy to Read Backlit Display and Buttons
  • High Gain Antenna
  • FM Radio (Requires Programming Cable to Enable)
  • VOX Compatible

Specifications:

  • Frequency Range: UHF: 476.4250 - 477.4125MHz
  • Channel Capacity: 80 Channels
  • Phase-Locked Step: 5KHz, 6.25KHz
  • Operating Voltage: 7.4 DC ±20%
  • Battery Life: More than 14 Hours (1500mAh), by 5-5-90 Work Cycle
  • Frequency Stability: ±2.5ppm
  • Operating Temperature: -20~ +55°C
  • Sensitivity: (12dB SINAD) ≤0.35_V
  • Adjacent Channel Selectivity: ≥60dB
  • Intermodulation: ≥60dB
  • Spurious Rejection: ≥80dB
  • Audio Power Output: 500mW (@ 10%)
  • Modulation: 11K_F3E
  • Adjacent Channel: ≥60dB
  • Hum & Noise: ≥40dB
  • Spurious Emission: ≤-36dB
  • Audio Response: 6dB / per Interval
  • Audio Distortion: ≤5%
  • Optional Accessories: DBH50USB Programming Cable
  • Packaging Type: Giftbox

What's Included:

  • 1x DBH50M Hand Held UHF Radio
  • 1x Rechargeable Lithium-Ion Battery
  • 1x Charging Dock
  • 1x 240V AC Charger
  • 1x 12V DC Charger
  • 1x High Gain Antenna
  • 1x Earpiece/Mic
  • 1x Belt Clip
  • 1x Wrist Strap
  • 1x User Manual
