ALTIQ AWT28aux-DR Next-Gen Ranger/Everest 28" LED Light Bar Stealth Kit | Double Row Hybrid Behind Grille

ALTIQ AWT28aux-DR Next-Gen Ranger/Everest 28" LED Light Bar Stealth Kit | Double Row Hybrid Behind Grille

Factory Integration. Unmatched Brightness. True Stealth.

Discover the world’s first double row 28" LED Light Bar Stealth Kit engineered exclusively for the Next-Gen Ranger and Everest. This kit mounts a powerful hybrid light bar behind the grille for a seamless, factory-style look while delivering a near fourfold increase in lux and unmatched visibility for high-speed and off-road conditions.

Custom brackets ensure direct fitment with no extra components required, and the included wiring solutions cater to all headlight configurations—whether you have the AUX 6 switch panel or standard headlights. Precision-engineered with 3D scanning and CFD-tested for airflow, this kit is designed for perfect fit, maximum performance, and long-term durability.

AWT28aux-DR Feature:

• World-first double row 28" hybrid LED light bar for behind-grille integration
• Delivers up to 7200 lux—nearly four times the factory high beam output
• Direct fit with custom brackets—no extra hardware needed
• Multiple wiring options for AUX 6 panel and all headlight levels (1, 2, 3)
• Indestructible 3mm GE Lexan lens and 316L marine-grade stainless fasteners
• DuPont Midnight paint for a stealth, UV-resistant finish
• 56 x genuine 5W OSRAM P9 chips for 12,622 lumens and 1 lux at 746m
• Waterproof rated IP68/IP69K for extreme conditions
• 10-year warranty for peace of mind
• CFD-tested bracket system for optimal airflow

Specifications:

• Lux Distance: 1 lux @ 746m
• Lumens: 12,622
• Lens: 3mm GE Lexan (indestructible)
• LEDs: 56 x Genuine 5W OSRAM P9 Chips
• Finish: DuPont Midnight Paint
• Fasteners: 316L Marine Stainless Steel
• Waterproof Rating: IP68 / IP69K
• Warranty: 10 Years
• Input Voltage: 10-30V DC
• Current Draw: 11.33A @ 12V
• Included Wiring Harness: 14 Gauge Dual DT Output, Neg/Pos switched compatible
• Colour Temperature: 5700K @ 82+ CRI
• Weight: 2.48kg (including brackets)

What’s Included:

• ALTIQ Hybrid 28" LED Light Bar
• ALTIQ Light bar brackets for Next Gen Ranger/Everest
• DT Waterproof plug pigtail
• Heatshrink with inbuilt solder
• Instructions

Perfect for:

• Next-Gen Ranger and Everest owners seeking a stealth, factory-style lighting upgrade with maximum brightness and seamless integration for both on-road and off-road adventures.
