Ultra Vision BGLB-IMUX-125-KIT Behind Grille Light Bar Kit To Suit Isuzu MU-X RG 2021-on

Ultra Vision Behind Grille Light Bar Kit To Suit Isuzu MU-X RG 2021-on: Get the Power of Ultra Vision on Your Isuzu MU-X

With this Behind Grille Light Bar Kit, getting the power of Ultra Vision on your Isuzu MU-X is a smooth and pain free process.

Get everything you need in one kit without any cutting, drilling, or a bull bar! Cleverly designed specifically for the Isuzu MU-X 2021-on, the bumper or grille do not need to be removed for installation.

Only the grille shroud beneath the bonnet needs to be removed temporarily for access to mount the light bar behind.

The purpose-built MU-X light bar brackets mount to existing points on the body, all you will need is a 13mm & 12mm spanner to install.

Ultra Vision BGLB-IMUX-125-KIT Features:

• Designed specifically for the Isuzu MU-X 2021-on models
• No cutting or drilling required
• No bull bar required
• Includes 1x Raptor 125w LED Light Bar with 708m beam distance at 1 Lux
• 3-year warranty
• Brackets powder-coated black for sleek design and rust preservation
• Designed and made in Australia

Ultra Vision BGLB-IMUX-125-KIT Specifications:

• Wattage: 125 Watts
• Light Source: 18 High Power LEDs
• Light Output – Raw: 13,957 Lumens
• Light Output – Effective: 11,430 Lumens
• Voltage: 9-36V
• Current Draw: 10A @ 13.5V
• Operating Temp.: -40 to 80 Deg C
• Waterproof Rating: IP67
• Connector Type: Plugs 2 Pin Heavy Duty Deutsch
• Housing: Aluminium
• Lens: Construction Polycarbonate
• Bracket Stainless: Steel powder coated black
• Colour Temperature: 5700K
• Lifespan: 50,000 Hours
• Dimensions: 523 x 45 x 73mm
• Net Weight: 1.7kg
• Mounting Suitable: Side Mount Brackets
• Warranty: 3 Years
• Beam Type: Spot Beam

What's In The Box:

• 1 x Raptor 125W 20.5-Inch LED Light Bar in 5700k
• 1x Wiring Harness to suit
• 1x Purpose-built MU-X behind-grille black powder-coated bracket kit
• 2x MU-X high-beam plug & play wiring adaptors (1x for models up to July 2021 and 1x for Jan 2022-on models)
• 1x OEM-style switch to fit into factory switch blank
• 1x Mounting hardware kit (nuts, bolts, and brackets)
• Fitting and wiring instructions

Note: Please be advised that these brackets have been designed to suit Ultra Vision Lighting products only. Our warranty policy does not cover integration or behind grille kits that are fitted with any other lighting brands.
