Stinger SRP-SZ001H HEIGH10 Infotainment Package For Suzuki Jimny 2018–2023

SKU: SRPSZ001H
Sale price
$1,799.96
Regular price
$1,999.95
You save
10%
Buy now, pay later
  • image
  • image
  • image

Shipping information

We offer fast and reliable shipping options to ensure that your order arrives in a timely manner. Our dedicated team works diligently to process and ship your items as quickly as possible.

Here are some key points to note about our shipping policy:

Standard Shipping

  • Frankies offers a $15.95 flat rate for Australia-wide shipping, no matter how many items you order. Some larger or heavier items may incur an additional fee, which will be communicated to you when your order is processed.
  • While we endeavour to dispatch all orders promptly, please be advised that due to the current national fuel shortages in Australia and the resulting pressure on logistics networks, order processing and dispatch may take up to 7 business days. We are not liable for delays caused by third-party freight carriers or fuel-related logistical disruptions. By placing an order, you acknowledge that delivery timeframes may be extended beyond our standard estimates during this period.

Estimated delivery times:

  • WA, NT, and TAS: currently experiencing longer shipping times
  • Holiday periods (e.g. Christmas): deliveries may be delayed due to increased freight volumes

Express Shipping

  • Express shipping is available and calculated based on your delivery location, as well as the size and weight of your order. To receive an accurate quote, please contact our Albion Park Rail store and request an "express shipping quote." Our team will promptly assist with pricing and availability. Payment for express shipping can be securely arranged over the phone.

Share this product

Share Post Pin E-mail

Product features

The Complete Jimny Upgrade HEIGH10 10" Infotainment With CarPlay, SWC and Camera Retention

Product Overview

The Stinger SRP-SZ001H is an all-inclusive infotainment replacement kit designed for 2018–2023 Suzuki Jimny vehicles. This kit combines the Stinger HEIGH10 10" infotainment system with all the vehicle-specific hardware needed to retain factory steering wheel audio controls (where fitted) and the factory reverse camera (in select models), delivering a complete, plug-and-play upgrade without sourcing individual parts.

The bundle includes the HEIGH10 unit, radio mounting kit, vehicle interface with harness, reverse camera retention harness, a dual USB flush mount kit, and an ISO harness everything needed for a professional installation result. Please note: for Jimny vehicles fitted with the trapezoid OEM radio from 2021–2022, the reverse camera cannot be retained using the included harness. The Stinger HEIGH10 head unit is included.

Key Specifications

  • Manufacturer Part Number: SRP-SZ001H
  • Included head unit: Stinger HEIGH10 UN1810 (10" display)
  • Screen size: 10" HD capacitive touchscreen
  • Colour depth: 16.7 million colours
  • Apple CarPlay: Yes
  • Android Auto: Yes
  • AM/FM radio: Yes — with RDS tuner
  • Dual USB: Yes
  • HDMI input: Yes
  • RCA output: 4V, 6-channel
  • Digital Sound Processor: Yes — with TOSLINK output
  • Bluetooth: Yes — handsfree and audio playback with aptX
  • iGo navigation: Optional (not confirmed as included — see red-flags)
  • Steering wheel control retention: Yes — if factory fitted
  • Reverse camera retention: Yes — select models only
  • Reverse camera retention exclusion: Jimny with trapezoid OEM radio 2021–2022 — not retained with included harness
  • Dual USB flush mount kit: Included
  • Plug & Play: Yes

Features & Benefits

  • 10" HD Capacitive Touchscreen — The HEIGH10's 10" display with 16.7 million colour rendering upgrades the Jimny's compact centre stack to a modern, feature-rich infotainment interface.
  • Apple CarPlay & Android Auto — Wired CarPlay and Android Auto bring navigation, music, calls, and messaging to the 10" screen from a connected smartphone.
  • Steering Wheel Control Retention — Factory steering wheel audio buttons are retained via the included vehicle interface on Jimny models fitted with this feature.
  • Reverse Camera Retention — The included reverse camera retention harness retains the factory reverse camera on select Jimny models. Note: Jimny vehicles fitted with the trapezoid OEM radio from 2021–2022 cannot retain the reverse camera using the included harness.
  • Dual USB Flush Mount Kit — A dual USB flush mount kit is included, allowing factory-style USB access points to be integrated into the new installation.
  • 4V 6-Channel RCA Output + DSP — The HEIGH10's output stage and built-in DSP with TOSLINK provides the foundation for connecting external amplifiers and audio processors.
  • Complete Hardware Bundle — Radio mounting kit, vehicle interface with harness, reverse camera retention harness, dual USB flush mount kit, and ISO harness are all included.

Technical Specs

Specification Detail
Part Number SRP-SZ001H
Included Head Unit Stinger HEIGH10 UN1810
Brand Stinger
Screen Size 10" HD capacitive touchscreen
Colour Depth 16.7 million colours
Apple CarPlay Yes
Android Auto Yes
AM/FM Radio Yes — RDS tuner
Dual USB Yes
HDMI Input Yes
RCA Output 4V, 6-channel
Digital Sound Processor Yes — TOSLINK output
Bluetooth Yes — handsfree + audio, aptX
iGo Navigation See note — confirm with supplier
SWC Retention Yes — if factory fitted
Reverse Camera Retention Yes — select models (see exclusion below)
Camera Exclusion Trapezoid OEM radio 2021–2022 — not retained
Dual USB Flush Mount Kit Included
Plug & Play Yes
Included Components HEIGH10, mounting kit, vehicle interface, camera harness, dual USB flush mount, ISO harness

Compatible With / Goes Well With

  • Suzuki Jimny 2018, 2019, 2020, 2021, 2022, 2023
  • Factory Suzuki Jimny steering wheel audio controls — where factory fitted
  • Factory Suzuki Jimny reverse camera — select models (see caution below)

Frequently Asked Questions

Does the SRP-SZ001H include the HEIGH10 head unit?

Yes — the Stinger HEIGH10 infotainment system is included, along with all vehicle-specific installation hardware. This is a complete all-in-one upgrade package.

Will this kit retain my factory reverse camera?

In most cases, yes — the kit includes a reverse camera retention harness for compatible Jimny models. However, Jimny vehicles fitted with the trapezoid OEM radio from 2021 to 2022 cannot retain the factory reverse camera using the included harness. Confirm your Jimny's factory radio type before purchase.

How do I know if my Jimny has the trapezoid OEM radio?

The trapezoid OEM radio features a distinctively shaped (non-rectangular) head unit surround in the factory dash. It was fitted to certain 2021–2022 Jimny variants.

Will my steering wheel audio controls be retained?

Yes — on Jimny models factory-fitted with steering wheel audio controls, these are retained via the included vehicle interface. If your Jimny does not have factory steering wheel audio controls, this feature is not applicable.

Does the kit include a dual USB flush mount?

Yes — a dual USB flush mount kit is included, allowing USB access points to be neatly integrated into the installation without external cables or adaptors.
