Product features

Stinger SPF52200 200 Amp ANL Fuse with Shoc-Krome Plating

A high-current 200A ANL fuse with Shoc-Krome plating for ultimate circuit protection and maximum current transfer suited to large car audio systems and heavy-gauge main power runs.

Product Overview

The Stinger SPF52200 is a 200 Amp ANL-style fuse with Shoc-Krome plating. Designed for use with Stinger ANL fuse holders, it provides ultimate circuit protection for high-powered automotive electrical installations, with high-conductivity plating to minimise resistance and maximise current transfer at the fuse connection point.

At 200A, the SPF52200 sits between the 80A (SPF5280) and 250A (SPF52250) options in the Stinger ANL fuse range a common choice for high-powered single amplifier or dual amplifier main power runs on 1/0 AWG or 2 AWG wiring.

Features & Benefits

  • 200A ultimate circuit protection
  • ANL fuse format
  • Shoc-Krome plating for high conductivity and maximum current transfer
  • Compatible with all Stinger ANL fuse holders
  • Sold individually

Technical Specs

Specification Detail
SKU / Part Number SPF52200
Brand Stinger
Fuse Type ANL Style
Amperage Rating 200A
Plating Shoc-Krome
Pack Quantity 1 fuse

Compatible With / Goes Well With

Direct Vehicle Fit:

  • Universal — compatible with any standard ANL fuse holder

Goes Well With:

  • Stinger ANL fuse holders
  • 1/0 AWG or 2 AWG main power wiring
  • High-current distribution blocks and battery terminals
  • Stinger SPF5280 80A ANL fuse (lower amperage ANL option)
  • Stinger SPF52250 250A and SPF52300 300A ANL fuses (higher amperage ANL options)

Frequently Asked Questions

What is an ANL fuse and when do I need a 200A rating?

ANL fuses are bolt-down high-current fuses used for main power circuit protection in automotive installations. A 200A fuse is a common choice for high-powered single amplifier installs or dual amplifier setups on 1/0 AWG or 2 AWG main power runs. Install as close to the battery as possible on the main power feed.

Is this fuse sold individually or in a pack?

The SPF52200 is sold as a single fuse.

What wire gauge pairs with a 200A ANL fuse?

A 200A fuse typically pairs with 1/0 AWG (zero gauge) or 2 AWG main power wiring, depending on run length and total system load. Always confirm your wiring is rated for the continuous current draw before selecting a fuse rating.

Why does fuse plating matter?

Shoc-Krome plating reduces contact resistance at the fuse terminal, ensuring maximum current transfer between the fuse and holder. At 200A, minimising resistance is critical to avoid voltage drop and heat generation at the connection point.

Are these fuses compatible with non-Stinger ANL fuse holders?

The SPF52200 is a standard ANL-style fuse compatible with any standard ANL fuse holder. Confirm your holder accepts standard ANL fuses before purchasing.
