Product features

Stinger SPD510 PRO Series 8GA T-Block Power Distribution Block

A compact 3-port 8GA T-distribution block from the Stinger PRO Series Shoc-Krome corrosion-resistant finish, oversized set screws, deep wire recesses, and daisy-chain design for flexible installation.

Product Overview

The Stinger SPD510 is a PRO Series 8 gauge T-distribution block providing three 8GA ports in a compact T-block form factor. It can be used to split or join power or ground connections at the 8GA level connecting one input to two outputs, or daisy-chaining multiple T-blocks together for more complex distribution.

Oversized set screws ensure maximum contact and vibration-resistant termination, while deep wire recesses eliminate exposed wire for a safe, professional finish. The Shoc-Krome coating provides corrosion resistance.

Features & Benefits

  • Three 8GA ports — input and two outputs, or daisy-chain configuration
  • Daisy-chain design for flexible multi-block configurations
  • Corrosion-resistant Shoc-Krome finish
  • Oversized set screws for maximum contact and secure termination
  • Deep wire recesses — no exposed wire for a professional finish
  • Non-fused — suitable for both power and ground side use

Technical Specs

Specification Detail
SKU / Part Number SPD510
Brand Stinger
Series PRO
Port Count 3
Wire Gauge 8 AWG (8GA)
Finish Shoc-Krome (corrosion resistant)
Wire Connection Oversized set screws
Fused No

Compatible With / Goes Well With

Direct Vehicle Fit:

  • Universal — suitable for 8GA power or ground distribution

Goes Well With:

  • Stinger SK4281 / SK4681 8GA amplifier wiring kits (for power or ground distribution)
  • Stinger STK8 8GA amplifier wiring kit
  • Car audio amplifiers with 8GA power or ground connections
  • Stinger SHD820 fused distribution block (if per-output fusing is also required)

Frequently Asked Questions

What is a T-distribution block used for?

A T-block splits one connection into two (or joins two into one), in a compact T-shaped housing. In car audio, it is commonly used to split a single 8GA power or ground run to two amplifiers, or to extend a ground bus where multiple short ground cables need to connect to a single chassis point.

Can the SPD510 be daisy-chained?

Yes. The daisy-chain design allows multiple SPD510 blocks to be linked together, expanding the number of distribution points for more complex builds.

Is this block fused?

No. The SPD510 is a non-fused T-distribution block. Fusing must be provided externally on the main power run if using this for power distribution.

What gauge wire is compatible with the SPD510?

The SPD510 is rated for 8GA (8 AWG) wire on all three ports. It is not designed for 4GA or 0GA wiring — for larger gauge applications, see the Stinger SHD20 or SHD820 HPM Series distribution blocks.

Can this be used for both power and ground?

Yes. Like all Stinger distribution blocks, the SPD510 can be used on either the positive power or negative ground side of the installation.
