Stinger SF9-TY03 9" Trapezoid Fascia for Toyota RAV4 XA40 Series (2014-2018)

XA40-specific 9" fascia engineered for fourth-generation RAV4 trapezoid dash geometry

Product Overview

The Stinger SF9-TY03 is a vehicle-specific fascia panel designed for Toyota RAV4 XA40 Series models (2014-2018) featuring trapezoid-shaped factory dash apertures. This fascia addresses the unique geometry of the fourth-generation RAV4 dashboard, where the factory opening features non-standard trapezoid dimensions that standard double-DIN fascias cannot properly accommodate. Engineered to OEM specifications, the SF9-TY03 provides seamless integration between compatible 9" floating-screen head units and the factory dashboard, maintaining the RAV4's refined interior aesthetic while enabling modern multimedia upgrades including wireless Apple CarPlay, Android Auto, and advanced navigation. Compatible with select Alpine, Kenwood, Pioneer, and Aerpro 9" head units featuring trapezoid mounting patterns, this fascia is essential for clean, professional installations in Australia's best-selling compact SUV platform of the mid-2010s era.

Key Specifications

• Vehicle fitment: Toyota RAV4 XA40 Series (2014-2018 models only)
• Screen size accommodation: 9" trapezoid-geometry head units
• Compatible head units: Alpine INE-AW4095/INE-AX809, Kenwood DMX80AXS, Pioneer DMH-AP6650BT, Aerpro AM9X
• Manufacturer: Stinger Electronics
• Part number: SF9-TY03
• Material: injection-moulded ABS plastic (colour-matched to factory trim)
• Installation type: fascia panel only (additional harnesses and brackets sold separately)
• Year range: 2014, 2015, 2016, 2017, 2018
• Chassis code: XA40 Series (fourth-generation RAV4)

Features & Benefits

XA40-specific trapezoid geometry precisely matches the unique non-rectangular aperture shape of the fourth-generation RAV4 dash, where standard double-DIN fascias leave visible gaps or fail to mount securely—this vehicle-specific design ensures flush, factory-quality panel alignment that maintains the RAV4's refined family SUV aesthetic rather than announcing itself as an aftermarket modification.

2014-2018 XA40 coverage encompasses the complete fourth-generation RAV4 span including GX, GXL, and Cruiser variants, providing upgrade path for vehicles purchased before wireless Apple CarPlay and Android Auto became standard features—particularly relevant for families with aging RAV4s still running factory touch-screen systems with outdated smartphone integration.

Compatible with modern 9" floating-screen head units including Alpine's iLX-AW4095 and iLX-AX809, Kenwood's DMX80AXS, Pioneer's DMH-AP6650BT, and Aerpro's AM9X—enabling wireless smartphone mirroring, reversing camera display upgrades, and turn-by-turn navigation on vehicles originally equipped with Toyota's pre-2019 multimedia systems lacking modern connectivity.

Injection-moulded construction matches factory dashboard material quality and UV resistance, withstanding the daily-driver demands of school runs, commuter traffic, and family road trips—critical for maintaining interior quality in high-use family vehicles where dashboard components face constant sunlight exposure through large windscreens.

Factory colour-matching maintains the RAV4's understated interior appearance valued by families, fleet buyers, and private owners where visible aftermarket modifications may impact resale value—the fascia blends seamlessly with surrounding trim panels, preserving the cohesive factory design language that contributes to strong RAV4 residual values.

Essential foundation component for complete head unit installations in XA40 RAV4 models—while sold separately from wiring harnesses, antenna adapters, and steering wheel control interfaces, this fascia is the required starting point for any professional multimedia upgrade in this generation, eliminating the guesswork around fitment compatibility.

Compatible with factory safety systems when paired with appropriate retention harnesses—enables multimedia upgrades without compromising factory reversing cameras, parking sensors, or Toyota Safety Sense features (where equipped), maintaining the comprehensive safety package that makes the RAV4 a popular family vehicle choice.

Technical Specs

• Part number: SF9-TY03
• Vehicle application: Toyota RAV4 XA40 Series (fourth generation)
• Year compatibility: 2014-2018 inclusive
• Chassis code: XA40
• Screen accommodation: 9" trapezoid-geometry floating-screen head units
• Material: injection-moulded ABS plastic
• Finish: factory-matched colour (typically black or charcoal depending on interior trim)
• Installation hardware: fascia panel only (mounting brackets, harnesses, and adapters sold separately)
• Compatible head unit models: Alpine INE-AW4095, Alpine INE-AX809, Kenwood DMX80AXS, Pioneer DMH-AP6650BT, Aerpro AM9X
• Trim variants: GX, GXL, Cruiser (all covered 2014-2018)

Frequently Asked Questions

Does this fascia include wiring harnesses or mounting brackets?

No, the SF9-TY03 is the fascia panel only. Complete installation requires a separate Toyota-specific primary wiring harness (connects head unit to factory loom), antenna adapter, steering wheel control interface, and potentially a reverse camera retention harness depending on your RAV4 variant. These components are available separately.

Will this fit 2019 or newer RAV4 models?

No, this fascia is specifically engineered for XA40 Series RAV4 (2014-2018) only. The 2019+ fifth-generation RAV4 (XA50 chassis) features a completely redesigned dashboard architecture requiring different fascia part numbers—verify your vehicle's year and chassis code before purchasing.

Which head units are confirmed compatible?

Confirmed compatible units include Alpine INE-AW4095, Alpine INE-AX809, Kenwood DMX80AXS, Pioneer DMH-AP6650BT, and Aerpro AM9X. These feature 9" screens with trapezoid mounting patterns matching the XA40 RAV4 aperture. Standard double-DIN or universal 9" units will not fit without this vehicle-specific fascia.

Why can't I use a standard double-DIN fascia in my RAV4?

The XA40 RAV4 features a trapezoid-shaped dash aperture—wider at the top than bottom—which standard rectangular double-DIN fascias cannot accommodate. The SF9-TY03's trapezoid geometry is essential for proper fitment, eliminating gaps and ensuring secure head unit mounting in this specific Toyota chassis.

Will I retain factory steering wheel controls and reversing camera?

The fascia itself is passive and doesn't affect factory features. Retaining steering wheel controls requires a separate steering wheel control interface, and preserving the factory reversing camera requires an appropriate retention harness. These components integrate with the new head unit to maintain factory functionality.

Compatible With / Goes Well With

• Alpine INE-AW4095 9" multimedia receiver (Apple CarPlay/Android Auto)
• Alpine INE-AX809 9" multimedia receiver (wireless CarPlay/Android Auto)
• Kenwood DMX80AXS 9" multimedia receiver (wireless connectivity)
• Pioneer DMH-AP6650BT 9" multimedia receiver (floating screen design)
• Aerpro AM9X 9" multimedia receiver (Toyota-specific integration)
• Toyota-specific primary wiring harnesses (ISO to factory connector)
• Toyota antenna adapters (aftermarket to factory antenna connection)
• Steering wheel control retention interfaces (maintain factory controls)
• Reverse camera retention harnesses (preserve factory camera functionality)
• GPS antenna adapters for head units with navigation
