Rockford Fosgate P2D4-10 Punch 10" P2 4-Ohm DVC Subwoofer

Rockford Fosgate Punch 10" P2 4-Ohm DVC Subwoofer: Rockford Fosgate Punch 10" P2 4-Ohm DVC Subwoofer: Certainly Continues with the Tradition

The Rockford Fosgate P2 10” subwoofer continues “The PUNCH” tradition. The P2D4-10 features a Dual 4-Ohm voice coil, 300 Watts RMS power handling, and can accommodate a grille insert using the included cast aluminum trim ring.

Kevlar fiber reinforced paper cones deliver bass impact you can feel along with VAST technology to increase surface cone area up to 25%. The P2 subwoofers perform best in standard sealed and vented enclosures. Includes diamond cut cast aluminum trim ring. Optional grille insert available.

Rockford Fosgate P2D4-10 Features:

• Dual linear spider with embedded 16 AWG tinsel leads
• Custom 10-AWG nickel plated push terminals
• Extended pole piece and bumped vented backplate
• High-temp voice coil with spun-laced Nomex® re-inforcement collar
• Protective PVC textured magnet cover
• Kevlar fiber reinforced paper cone
• StampCast basket with integrated spider venting
• Diamond cut cast aluminum trim ring with optional grille


Specifications:

• Power Handling (Watts RMS)300 Watts RMS
• 600 Watts Max
• Mounting Depth5.92 in. (150.4 mm)
• Voice Coil Diameter2.25" (57.15 mm)
• Nominal ImpedanceDual 4-Ohm
• Size10"
• Magnet Weight (oz)66.4 oz. (1.88 kg.)
• Speaker ConnectorDual 10 AWG compression
• Shipping Weight13.6 Lbs. (6.16 kg)
• Cutout Diameter9.13 in. (232 mm)
• Qts0.57
• SPL (dB @ 1w/1m)84
• Fs (Hz)30.8
• Qes0.62
• Qms7.00
• Vas (Liters)35.4
• Xmax (mm)11
• Woofer Displacement0.060 cu. ft. (1.7 Liters)
• CEA-2031 CompliantCEA-2031 Guidelines
• Le (mH)5.3
• Re (Ohms)6.40
• Sd (cm2)360
• Subwoofer TypeStandard
• Voice Coil TypeDual Voice Coil
