Roadvision RWL4840F Stealth LED Work Light 40W Square Flood Beam
Roadvision RWL4840F Stealth LED Work Light 40W Square Flood Beam
Click to open expanded view

Roadvision RWL4840F Stealth LED Work Light 40W Square Flood Beam

SKU: RWL4840F
Price
$89
Buy now, pay later
  • image
  • image
  • image

Shipping information

We offer fast and reliable shipping options to ensure that your order arrives in a timely manner. Our dedicated team works diligently to process and ship your items as quickly as possible.

Here are some key points to note about our shipping policy:

Standard Shipping

  • Frankies offers a $15.95 flat rate for Australia-wide shipping, no matter how many items you order. Some larger or heavier items may incur an additional fee, which will be communicated to you when your order is processed.
  • While we endeavour to dispatch all orders promptly, please be advised that due to the current national fuel shortages in Australia and the resulting pressure on logistics networks, order processing and dispatch may take up to 7 business days. We are not liable for delays caused by third-party freight carriers or fuel-related logistical disruptions. By placing an order, you acknowledge that delivery timeframes may be extended beyond our standard estimates during this period.

Estimated delivery times:

  • WA, NT, and TAS: currently experiencing longer shipping times
  • Holiday periods (e.g. Christmas): deliveries may be delayed due to increased freight volumes

Express Shipping

  • Express shipping is available and calculated based on your delivery location, as well as the size and weight of your order. To receive an accurate quote, please contact our Albion Park Rail store and request an "express shipping quote." Our team will promptly assist with pricing and availability. Payment for express shipping can be securely arranged over the phone.

Share this product

Share Post Pin E-mail

Product features

Roadvision RWL4840F Stealth LED Work Light 40W Square Flood Beam

A compact square LED work light from the Roadvision Stealth RWL48 Series, the RWL4840F produces up to 3016 lumens from 4 x 9W Osram LEDs through a 110-degree flood beam, with 10-30V DC multi-volt input, die-cast aluminium housing, polycarbonate lens, 2-pin Deutsch plug wiring, and a 5-year warranty.

Product Overview

The Roadvision RWL4840F is a 40W square LED work light from the Stealth RWL48 Series, combining superior performance in a durable, maintenance-free package. The smoked-look lens and blackout mounting hardware give a stealth on-vehicle look, and the compact 81 x 82 x 67mm body suits demanding environments and applications where space is limited. Four 9W Osram LEDs produce up to 3016 maximum lumens of super white light close to daylight, spread across a 110-degree flood beam pattern that delivers 65 lux at 10 metres and reaches 81 metres at 1 lux.

The RWL4840F is equipped with thermal management technology that smart-adjusts to the environmental temperature to balance optimal performance and prevent overheating. The multi-volt 10-30V DC input draws a super low 1.4 to 3.3 amps at 13.8V, and solid-state technology delivers a 50,000 hour LED lifespan. Installation is a simple 2-wire connection via the 2-pin Deutsch plug, with over/under voltage protection, reverse polarity protection, and EMI/EMC radio interference approval built in.

Features & Benefits

40W Square Flood Beam - Up to 3016 Lumens: The RWL4840F produces up to 3016 maximum lumens through a 110-degree flood beam pattern, delivering 65 lux at 10 metres and a maximum distance of 81 metres at 1 lux for broad, even work area coverage.

4 x 9W Osram LEDs: Four 9W Osram LEDs produce super white light close to daylight, improving visibility and reducing eye strain during night work compared to warmer light sources.

Stealth Smoked-Look Lens and Blackout Hardware: The Stealth RWL48 Series features a smoked-look lens and blackout mounting hardware for a low-key, integrated on-vehicle appearance.

50,000 Hour LED Lifespan: Solid-state technology delivers a 50,000 hour LED lifespan for maintenance-free performance over the long service life typical of 4WD, work vehicle, and machinery applications.

Thermal Management Technology: The RWL4840F smart-adjusts to the environmental temperature, balancing optimal light performance with overheating prevention in demanding conditions.

Die-Cast Aluminium Housing with Polycarbonate Lens: The lightweight, tough die-cast aluminium housing and polycarbonate lens provide durability in the most demanding environments.

Multi-Volt 10-30V DC with Super Low Current Draw: The 10-30V DC multi-volt input draws just 1.4 to 3.3 amps at 13.8V, making the RWL4840F compatible with both 12V and 24V vehicle electrical systems without a voltage adaptor.

Simple 2-Wire Installation with Deutsch Plug: The 2-pin Deutsch plug and simple 2-wire installation make for a quick, professional connection to the vehicle wiring.

Built-In Circuit Protection: Over/under voltage protection, reverse polarity protection, and EMI/EMC radio interference approval protect both the lamp and the vehicle's electrical and communication equipment.

5-Year Warranty: The RWL4840F is backed by a 5-year Roadvision warranty.

Technical Specs

Specification Detail
SKU RWL4840F
Brand Roadvision
Series Stealth RWL48
Description LED Work Light 10-30V Square 40W Flood Beam
Beam Pattern 110° Flood
Maximum Lumens 3016lm
Maximum Watts 40W
Light Source 4 x 9W Osram LEDs
Input Voltage 10-30V DC
Current Draw 1.4-3.3A at 13.8V
Maximum Lux at 10m 65LX
Maximum Distance at 1 Lux 81m
Lens Polycarbonate
Housing Die-Cast Aluminium
Wiring 2 Pin Deutsch Plug
Dimensions 81 x 82 x 67mm
LED Lifespan 50,000 Hours
Warranty 5 Years

Compatible With

The RWL4840F is compatible with 10-30V DC vehicle electrical systems, covering both 12V and 24V vehicles. The Stealth RWL48 Series is also available as a 40W flush mount (RWL4840FFM) and a compact 23W flood beam (RWL4823F). Confirm mounting space and wiring access before purchase.

Frequently Asked Questions

How bright is the RWL4840F?

The RWL4840F produces up to 3016 maximum lumens from 4 x 9W Osram LEDs, delivering 65 lux at 10 metres and a maximum distance of 81 metres at 1 lux through a 110-degree flood beam.

Is the RWL4840F compatible with 24V vehicles?

Yes. The RWL4840F operates across 10-30V DC, making it compatible with both 12V and 24V vehicle electrical systems.

How does the RWL4840F connect to the vehicle?

The RWL4840F uses a 2-pin Deutsch plug with simple 2-wire installation, and includes over/under voltage protection, reverse polarity protection, and EMI/EMC radio interference approval.

What is the difference between the RWL4840F and RWL4840FFM?

Both share the same 40W output, 3016 lumens, and 110-degree flood beam. The RWL4840F is the standard surface mount version measuring 81 x 82 x 67mm, while the RWL4840FFM is the flush mount version requiring an 82 x 75mm panel cut-out.

What is the rated lifespan of the RWL4840F LEDs?

The RWL4840F has a rated LED lifespan of 50,000 hours with solid-state technology, providing long-term maintenance-free performance.
