Roadvision RDL1901C Essentials DLE 9" LED Driving Light Set 240W

SKU: RDL1901C
Price
$399
Buy now, pay later
  • image
  • image
  • image

Shipping information

We offer fast and reliable shipping options to ensure that your order arrives in a timely manner. Our dedicated team works diligently to process and ship your items as quickly as possible.

Here are some key points to note about our shipping policy:

Standard Shipping

  • Frankies offers a $15.95 flat rate for Australia-wide shipping, no matter how many items you order. Some larger or heavier items may incur an additional fee, which will be communicated to you when your order is processed.
  • While we endeavour to dispatch all orders promptly, please be advised that due to the current national fuel shortages in Australia and the resulting pressure on logistics networks, order processing and dispatch may take up to 7 business days. We are not liable for delays caused by third-party freight carriers or fuel-related logistical disruptions. By placing an order, you acknowledge that delivery timeframes may be extended beyond our standard estimates during this period.

Estimated delivery times:

  • WA, NT, and TAS: currently experiencing longer shipping times
  • Holiday periods (e.g. Christmas): deliveries may be delayed due to increased freight volumes

Express Shipping

  • Express shipping is available and calculated based on your delivery location, as well as the size and weight of your order. To receive an accurate quote, please contact our Albion Park Rail store and request an "express shipping quote." Our team will promptly assist with pricing and availability. Payment for express shipping can be securely arranged over the phone.

Share this product

Share Post Pin E-mail

Product features

Roadvision RDL1901C Essentials DLE Series 2 9" LED Driving Light Set 240W Combination Beam

A 9" combination beam LED driving light set from the Roadvision Essentials DLE Series 2, the RDL1901C delivers 20,800 lumens per set with a beam distance of 1,155 metres at 1 lux per set, powered by 19 x 5W Osram LEDs per light at 240W per set, featuring Thermal Management Technology, IP68 protection, and black protective covers, backed by a 3-year warranty.

Product Overview

The Roadvision RDL1901C is a 9" combination beam driving light set from the Essentials DLE Series 2, delivering the maximum output in the DLE Series 2 range. Nineteen 5W Osram LEDs per light produce super-white daylight-close output across a combination beam pattern, delivering 20,800 lumens per set with 13,256 lux at 10 metres per set and a beam reach of 1,155 metres at 1 lux per set at 240W per set total. Roadvision's Thermal Management Technology manages heat dissipation for consistent output and long-term reliability. IP68 rated die-cast aluminium housing with polycarbonate lens. Multi-volt 10-30V DC input at 17.4A per set at 13.8V with over/under voltage and reverse polarity protection. EMI/EMC radio interference approved. Simple 2-wire installation via 2-pin Deutsch plug. Includes black protective covers. 50,000 hour LED lifespan. Backed by a 3-year warranty.

Features & Benefits

20,800 Lumens Per Set - 1,155 Metre Beam at 1 Lux: The RDL1901C delivers 20,800lm per set with 13,256 lux at 10 metres per set and a beam reach of 1,155 metres at 1 lux per set, providing outstanding long-range illumination for night driving in remote and high-speed environments.

19 x 5W Osram LEDs Per Light - Super White Output: Nineteen 5W Osram LEDs per light produce a super-white output close to daylight colour temperature for natural colour rendering and clear road surface visibility.

Combination Beam Pattern: The combination beam delivers both long-range spot-style penetration and broader flood-style lateral coverage from a single light unit for comprehensive road illumination.

Thermal Management Technology: Roadvision's Thermal Management Technology actively manages heat dissipation across the LED array, ensuring consistent output and long-term reliability across all operating environments.

IP68 Water and Dust Proof: IP68 rating provides full dust ingress protection and waterproof protection against sustained immersion, suited to off-road and all-weather driving applications.

Die-Cast Aluminium Housing with Polycarbonate Lens: Lightweight die-cast aluminium housing with polycarbonate lens provides structural rigidity and effective heat dissipation.

50,000 Hour LED Lifespan with Solid-State Technology: The 50,000 hour rated LED lifespan provides long-term maintenance-free reliability.

Multi-Volt 10-30V DC with Over/Under Voltage and Reverse Polarity Protection: Compatible with 12V and 24V vehicle electrical systems with full electronic protection for the LED driver.

EMI/EMC Radio Interference Approved: Confirmed compatible with vehicle communication, navigation, and electronic systems without interference.

Simple 2-Wire Installation via 2-Pin Deutsch Plug: Secure, weatherproof, and vibration-resistant 2-wire connection for straightforward installation.

Includes Black Protective Covers: Black protective covers are included for additional lens protection when driving lights are not in use.

3-Year Warranty: Backed by a 3-year Roadvision warranty.

Technical Specs

Specification Detail
SKU RDL1901C
Brand Roadvision
Series Essentials DLE Series 2
Description RDL7800 Series 9" Round Combination Beam
Beam Pattern Combination
Maximum Lumens 20,800lm Per Set
Maximum Lux at 10m 13,256lx Per Set
Maximum Beam Distance at 1lx 1,155m Per Set
Input Voltage 10-30V DC
Maximum Watts 240W Per Set
LED Quantity 19 x 5W Osram Per Light
Current Draw 17.4A at 13.8V Per Set
Lens Construction Polycarbonate
Housing Construction Die-Cast Aluminium
Wiring 2-Pin Deutsch Plug
Dimensions 229mm x 246mm x 96mm
IP Rating IP68
LED Lifespan 50,000 Hours
Protection Over/Under Voltage, Reverse Polarity
EMI/EMC Radio Interference Approved
Includes Black Protective Covers
Warranty 3 Years

Compatible With

The RDL1901C is compatible with 10-30V DC vehicle electrical systems including 12V and 24V platforms. The 2-pin Deutsch plug provides a secure weatherproof 2-wire connection. Sold as a set of two lights. A 7" version is available as the RDL1701C.

Frequently Asked Questions

Is the RDL1901C sold as a pair or individually?

The RDL1901C is sold as a set. All lumen, lux, wattage, and beam distance figures are stated per set of two lights.

Is the RDL1901C compatible with 24V vehicles?

Yes. The RDL1901C operates across 10-30V DC, making it compatible with both 12V and 24V vehicle electrical systems.

What is the difference between the RDL1901C and the RDL1701C?

Both are from the Essentials DLE Series 2 and share the same design, technology, and features. The RDL1901C is a 9" set producing 240W and 20,800lm per set with a 1,155m beam reach at 1 lux. The RDL1701C is a 7" set producing 170W and 16,000lm per set with a 941m beam reach at 1 lux. Choose the RDL1901C for maximum output and beam throw.

Does the RDL1901C include protective covers?

Yes. Black protective covers are included with the RDL1901C set.

What is Thermal Management Technology on the RDL1901C?

Roadvision's Thermal Management Technology actively monitors and manages heat dissipation from the LED array, ensuring consistent light output and long-term reliability across all operating temperatures and environments.
