Roadvision BR302ARW LED Rear Combination Lamp - Stop/Tail/Indicator/Reverse

Roadvision BR302ARW LED Rear Combination Lamp - Stop/Tail/Indicator/Reverse

Complete compact lighting solution with the Roadvision BR302ARW, integrating Stop, Tail, Indicator, and Reverse functions in a tough, reliable 282mm package designed for 4WDs, small to medium trucks, and trailers.

Product Overview

The Roadvision BR302ARW LED Combination Lamp is the complete all-in-one lighting solution for 4WDs, small to medium trucks, and trailers, combining Stop, Tail, Indicator, and Reverse functions in a compact, durable 282mm package. Designed for versatility and performance, this comprehensive maintenance-free lamp features 9 LEDs each for stop/tail, indicators, and reverse functions, offering brighter output and greater efficiency than traditional incandescent lights while drawing significantly less power—just 0.08A for stop, 0.02A for tail, 0.1A for indicators, and 0.1A for reverse at 13.8V. The multi-volt 10-30V DC input ensures compatibility with both 12V and 24V electrical systems commonly found in 4WDs, light commercial vehicles, trucks, and trailers. The integrated reverse function eliminates the need for separate reverse lamps, simplifying installation and reducing component count while maximizing functionality in a compact package. Built with unbreakable polycarbonate lenses and a rugged high-impact ABS housing, the BR302ARW is fully sealed against dust and water ingress for reliable operation in demanding off-road and commercial environments. Rated to an impressive 100,000-hour LED lifespan with solid-state technology, this lamp eliminates bulb replacements and maintenance downtime for true fit-and-forget performance. The simple surface-mount design with compact 116mm mounting hole centres and 300mm tinned copper cable allows straightforward installation with color-coded wiring including reverse circuit for foolproof connections. ADR-approved under CTA-061851 for all functions and backed by Roadvision's comprehensive 5-year warranty, the BR302ARW delivers tough, compact, and reliable complete lighting that's built to endure harsh conditions whether you're tackling outback trails or commercial hauling applications.

Features & Benefits

Complete Compact Multi-Function Design: Versatile 282mm length integrates Stop, Tail, Indicator, and Reverse functions in a space-efficient package, eliminating separate reverse lamps while making it ideal for 4WDs, small to medium trucks, and trailers.

Maintenance-Free LED Technology: Solid-state LED construction with 9 LEDs each for stop/tail, indicators, and reverse offers brighter output and greater efficiency than traditional incandescent lights with 100,000-hour rated lifespan, eliminating bulb replacements.

Multi-Volt Compatibility: 10-30V DC input voltage range ensures compatibility with both 12V and 24V electrical systems, making this lamp suitable for 4WDs, light commercial vehicles, trucks, trailers, and mobile equipment without modifications.

Ultra-Efficient Operation: Low current draw of only 0.08A for stop, 0.02A for tail, 0.1A for indicators, and 0.1A for reverse at 13.8V provides brighter output while drawing significantly less power than traditional lights, reducing electrical system load.

Rugged Construction: Unbreakable polycarbonate lenses and rugged high-impact ABS housing withstand stone strikes, vibration, and harsh weather conditions while remaining fully sealed against dust and water ingress for reliable operation.

Integrated Reverse Functionality: 9 LEDs dedicated to reverse lighting eliminate the need for separate reverse lamps, simplifying wiring, reducing installation time, and providing comprehensive rear lighting coverage in a single compact unit.

Simple Installation & ADR Approved: Straightforward surface-mount design with compact 116mm mounting hole centres and 300mm tinned copper cable with reverse circuit ensures quick installation. Full ADR approval (CTA-061851) backed by comprehensive 5-year warranty for fit-and-forget reliability.

Technical Specifications

Compatible With

The Roadvision BR302ARW LED Combination Lamp is compatible with all vehicles and trailers operating on 10-30V DC electrical systems including 4WDs, light commercial vehicles, utes, small to medium trucks, trailers, utility trailers, box trailers, boat trailers, caravans, camper trailers, horse floats, mobile equipment, and agricultural machinery. Suitable for triple surface-mount applications requiring 116mm mounting hole spacing with integrated reverse lighting. Ideal for 4WD enthusiasts, trailer builders, fleet operators, owner-operators, and commercial vehicle workshops requiring ADR-approved, compact, maintenance-free lighting solutions with comprehensive rear lighting coverage and tough, reliable performance for demanding applications.

Frequently Asked Questions

What makes the BR302 Series suitable for 4WDs and small to medium trucks? The BR302ARW's compact 282mm length with 116mm mounting hole centres makes it ideal for space-constrained applications on 4WDs, utes, and small to medium trucks. With 9 LEDs each for stop/tail, indicators, and reverse, it delivers complete lighting functionality in a tough, compact package built for off-road and commercial use.

Does the integrated reverse light eliminate the need for separate reverse lamps? Yes, the BR302ARW includes dedicated reverse functionality with 9 LEDs providing bright white reverse illumination, eliminating the need for separate reverse lamps in most applications. This simplifies wiring, reduces installation time, and provides comprehensive rear lighting coverage in a single compact unit.

Can this lamp be used on both 12V and 24V vehicles? Yes, the BR302ARW features multi-volt 10-30V DC input, making it compatible with both 12-volt 4WDs and light commercial vehicles and 24-volt small to medium trucks and trailers without any modifications or adjustments required for universal fitment.

How does LED technology compare to traditional incandescent lights? The BR302ARW's LED technology offers brighter output and greater efficiency than traditional incandescent lights while drawing significantly less power. With 100,000-hour lifespan, LEDs eliminate frequent bulb replacements, reduce maintenance costs, and provide instant-on response for improved safety across all functions.

Is this lamp ADR approved for legal road use in Australia? Yes, the BR302ARW is fully ADR approved under CTA-061851 for all functions including stop, tail, indicator, and reverse, ensuring full legal compliance for Australian road use on commercial vehicles, trailers, 4WDs, and caravans.
