OEX MXA306 Alternator 12V 140A Mitsubishi Style Holden Adventra VY Series 2 5.7 L Gen3

SKU: MXA306
Price
$377
Buy now, pay later
  • image
  • image
  • image

Shipping information

We offer fast and reliable shipping options to ensure that your order arrives in a timely manner. Our dedicated team works diligently to process and ship your items as quickly as possible.

Here are some key points to note about our shipping policy:

Standard Shipping

  • Frankies offers a $15.95 flat rate for Australia-wide shipping, no matter how many items you order. Some larger or heavier items may incur an additional fee, which will be communicated to you when your order is processed.
  • While we endeavour to dispatch all orders promptly, please be advised that due to the current national fuel shortages in Australia and the resulting pressure on logistics networks, order processing and dispatch may take up to 7 business days. We are not liable for delays caused by third-party freight carriers or fuel-related logistical disruptions. By placing an order, you acknowledge that delivery timeframes may be extended beyond our standard estimates during this period.

Estimated delivery times:

  • WA, NT, and TAS: currently experiencing longer shipping times
  • Holiday periods (e.g. Christmas): deliveries may be delayed due to increased freight volumes

Express Shipping

  • Express shipping is available and calculated based on your delivery location, as well as the size and weight of your order. To receive an accurate quote, please contact our Albion Park Rail store and request an "express shipping quote." Our team will promptly assist with pricing and availability. Payment for express shipping can be securely arranged over the phone.

Share this product

Share Post Pin E-mail

Product features

OEX MXA306 Alternator 12V 140A Mitsubishi Style

The OEX MXA306 is a new 12V 140A alternator, Mitsubishi style, suited to the Holden Adventra VY Series 2 5.7L Gen3, featuring an internal regulator, single leg mount, and a 6 groove pulley.

Product Overview

The MXA306 is a new 12V Mitsubishi style alternator from OEX, delivering 140A of output through an internal regulator, and is a match for the Holden Adventra VY Series 2 5.7L Gen3. Built with a single leg mount and a mount centre to centre distance of 139mm, the MXA306 features a 6 groove pulley with a 57.5mm outside diameter.

This unit is fitted with a standard regulator and has a pin lug length of 51mm. An adaptor is available to suit HXK-32 and HXK-24 applications. Importantly, the MXA306 will not interchange with the MXA2020, MXA332, or MXA330, so confirm the correct part number before ordering.

Features & Benefits

140A Output at 12V: Delivers 140A of charging output on a standard 12V electrical system.

Internal Regulator: Fitted with a standard internal regulator, keeping the charging system compact.

Single Leg Mount: The single leg mounting arrangement matches the original Mitsubishi style fitment for straightforward installation.

6 Groove Pulley: The 6 groove pulley at 57.5mm outside diameter suits the specified fitment applications.

Suits Holden Adventra VY Series 2 5.7L Gen3: Specifically matched to this application, ensuring correct fitment and function.

Adaptor Available for HXK-32, HXK-24: An adaptor is available to suit HXK-32 and HXK-24 applications, extending fitment flexibility.

Not Interchangeable with MXA2020, MXA332, or MXA330: Despite similar appearance and specifications, this unit will not interchange with these other part numbers.

New Unit: Supplied new, not reconditioned.

Technical Specs

Specification Detail
Part No. MXA306
Brand OEX
Type Alternator
Voltage 12V
Power Rating 140A
Regulator Type Internal (Standard)
Suits Unit Make Mitsubishi
Suits Vehicle Holden Adventra VY Series 2 5.7L Gen3
Alternator Mount Single Leg
Mount Cnt to Cnt 139mm
Mount Leg Thickness 50mm
Adjusting Hole Diameter 10.5mm
Pivot Hole Diameter 10.5mm
Pulley Outside Diameter 57.5mm
Pulley Section 6 Groove
Pin Code IR49
Pin Lug Length 51mm
Adaptor Compatibility HXK-32, HXK-24
New / Reman. New
Weight 5.96kg

Compatible With

The MXA306 is a Mitsubishi style 12V 140A alternator suited to the Holden Adventra VY Series 2 5.7L Gen3, with an adaptor available for HXK-32 and HXK-24 applications. This unit will not interchange with the MXA2020, MXA332, or MXA330; confirm your vehicle and application match before ordering.

Frequently Asked Questions

Which vehicle does the MXA306 suit?

The MXA306 is suited to the Holden Adventra VY Series 2 5.7L Gen3.

Can I use the MXA306 in place of the MXA2020 or MXA332?

No. The MXA306 will not interchange with the MXA2020, MXA332, or MXA330, despite similar specifications.

What voltage and output does the MXA306 provide?

The MXA306 is a 12V alternator delivering 140A of output.

Is an adaptor available for other applications?

Yes. An adaptor is available to suit HXK-32 and HXK-24 applications.

Is the MXA306 new or reconditioned?

The MXA306 is supplied new.
