OEX MXA220 Alternator 12V 90A Mitsubishi Style

SKU: MXA220
Price
$464
Buy now, pay later
  • image
  • image
  • image

Shipping information

We offer fast and reliable shipping options to ensure that your order arrives in a timely manner. Our dedicated team works diligently to process and ship your items as quickly as possible.

Here are some key points to note about our shipping policy:

Standard Shipping

  • Frankies offers a $15.95 flat rate for Australia-wide shipping, no matter how many items you order. Some larger or heavier items may incur an additional fee, which will be communicated to you when your order is processed.
  • While we endeavour to dispatch all orders promptly, please be advised that due to the current national fuel shortages in Australia and the resulting pressure on logistics networks, order processing and dispatch may take up to 7 business days. We are not liable for delays caused by third-party freight carriers or fuel-related logistical disruptions. By placing an order, you acknowledge that delivery timeframes may be extended beyond our standard estimates during this period.

Estimated delivery times:

  • WA, NT, and TAS: currently experiencing longer shipping times
  • Holiday periods (e.g. Christmas): deliveries may be delayed due to increased freight volumes

Express Shipping

  • Express shipping is available and calculated based on your delivery location, as well as the size and weight of your order. To receive an accurate quote, please contact our Albion Park Rail store and request an "express shipping quote." Our team will promptly assist with pricing and availability. Payment for express shipping can be securely arranged over the phone.

Share this product

Share Post Pin E-mail

Product features

OEX MXA220 Alternator 12V 90A Mitsubishi Style

The OEX MXA220 is a new 12V 90A alternator, Mitsubishi style, featuring an internal regulator with a 2 pin regulator plug, pad mount, and a 6 groove pulley.

Product Overview

The MXA220 is a new 12V Mitsubishi style alternator from OEX, delivering 90A of output through an internal regulator. Built with a pad mounting arrangement and a mount centre to centre distance of 181mm, the MXA220 features a 6 groove pulley with a 49mm outside diameter.

This unit has a 2 pin regulator plug. For applications requiring a 3 pin regulator plug, use the MXA2063 instead.

Features & Benefits

90A Output at 12V: Delivers 90A of charging output on a standard 12V electrical system.

Internal Regulator, 2 Pin Plug: The internal regulator uses a 2 pin plug; for a 3 pin regulator plug, use the MXA2063 instead.

Pad Mount: The pad mounting arrangement matches the original Mitsubishi style fitment for straightforward installation.

6 Groove Pulley: The 6 groove pulley at 49mm outside diameter suits the specified fitment applications.

Mitsubishi Style Design: Built to Mitsubishi style specifications for compatible fitment across applications originally equipped with a matching Mitsubishi unit.

New Unit: Supplied new, not reconditioned.

Technical Specs

Specification Detail
Part No. MXA220
Brand OEX
Type Alternator
Voltage 12V
Power Rating 90A
Regulator Type Internal, 2 Pin Plug
Suits Unit Make Mitsubishi
Alternator Mount Pad
Mount Cnt to Cnt 181mm
Mount Centres B 135mm
Mount Leg Thickness 75mm
Pivot Hole Diameter 9mm / 10mm
Pulley Outside Diameter 49mm
Pulley Section 6 Groove
Pin Code IR29
New / Reman. New
Weight 5.9kg

Compatible With

The MXA220 is a Mitsubishi style 12V 90A alternator with a pad mount and 2 pin regulator plug. For applications requiring a 3 pin regulator plug, use the MXA2063 instead. Confirm fitment against your original alternator's mounting dimensions and pin code (IR29) before ordering.

Frequently Asked Questions

How many pins does the regulator plug have on the MXA220?

The MXA220 has a 2 pin regulator plug. If your application requires a 3 pin plug, use the MXA2063 instead.

What voltage and output does the MXA220 provide?

The MXA220 is a 12V alternator delivering 90A of output.

What is the difference between the MXA220 and MXA230?

Both deliver 90A at 12V, but the MXA220 uses a pad mount with a 6 groove pulley and 2 pin regulator plug, while the MXA230 uses a twin leg mount with a 4 groove pulley.

How is the MXA220 mounted?

The MXA220 uses a pad mount with a 181mm mounting centre to centre distance.

Is the MXA220 new or reconditioned?

The MXA220 is supplied new.
