OEX MXA2046 Alternator 12V 130A Mitsubishi Style

SKU: MXA2046
Price
$350
Buy now, pay later
  • image
  • image
  • image

Shipping information

We offer fast and reliable shipping options to ensure that your order arrives in a timely manner. Our dedicated team works diligently to process and ship your items as quickly as possible.

Here are some key points to note about our shipping policy:

Standard Shipping

  • Frankies offers a $15.95 flat rate for Australia-wide shipping, no matter how many items you order. Some larger or heavier items may incur an additional fee, which will be communicated to you when your order is processed.
  • While we endeavour to dispatch all orders promptly, please be advised that due to the current national fuel shortages in Australia and the resulting pressure on logistics networks, order processing and dispatch may take up to 7 business days. We are not liable for delays caused by third-party freight carriers or fuel-related logistical disruptions. By placing an order, you acknowledge that delivery timeframes may be extended beyond our standard estimates during this period.

Estimated delivery times:

  • WA, NT, and TAS: currently experiencing longer shipping times
  • Holiday periods (e.g. Christmas): deliveries may be delayed due to increased freight volumes

Express Shipping

  • Express shipping is available and calculated based on your delivery location, as well as the size and weight of your order. To receive an accurate quote, please contact our Albion Park Rail store and request an "express shipping quote." Our team will promptly assist with pricing and availability. Payment for express shipping can be securely arranged over the phone.

Share this product

Share Post Pin E-mail

Product features

OEX MXA2046 Alternator 12V 130A Mitsubishi Style

The OEX MXA2046 is a new 12V 130A alternator, Mitsubishi style, featuring an internal regulator, twin leg mount, and a 7 groove pulley.

Product Overview

The MXA2046 is a new 12V Mitsubishi style alternator from OEX, delivering 130A of output through an internal regulator. Built with a twin leg mount and a mount centre to centre distance of 162mm, the MXA2046 features a 7 groove pulley with a 65mm outside diameter.

This unit will not replace the MXA2060, a 150 amp unit. The adjustment hole is threaded, while the rear mounting leg is unthreaded; confirm both the adjusting hole and rear mounting leg against your original unit before ordering.

Features & Benefits

130A Output at 12V: Delivers 130A of charging output on a standard 12V electrical system.

Internal Regulator: An internal regulator keeps the charging system compact without needing a separate external regulator unit.

Twin Leg Mount: The twin leg mounting arrangement matches the original Mitsubishi style fitment for straightforward installation.

7 Groove Pulley: The 7 groove pulley at 65mm outside diameter suits the specified fitment applications.

Threaded Adjustment Hole, Unthreaded Rear Mounting Leg: The adjustment hole is threaded while the rear mounting leg is unthreaded; confirm both against your original unit for correct fitment.

Mitsubishi Style Design: Built to Mitsubishi style specifications for compatible fitment across applications originally equipped with a matching Mitsubishi unit.

New Unit: Supplied new, not reconditioned.

Technical Specs

Specification Detail
Part No. MXA2046
Brand OEX
Type Alternator
Voltage 12V
Power Rating 130A
Regulator Type Internal
Suits Unit Make Mitsubishi
Alternator Mount Twin Leg
Mount Cnt to Cnt 162mm
Inside Mounting Legs 81mm
Adjusting Hole Diameter M8x1.25 (Threaded)
Pivot Hole Diameter 10mm
Rear Mounting Leg Unthreaded
Pulley Outside Diameter 65mm
Pulley Section 7 Groove
Pin Code IR203
New / Reman. New
Weight 6.36kg

Compatible With

The MXA2046 is a Mitsubishi style 12V 130A alternator with a twin leg mount. This unit will not replace the MXA2060 (150 amp). The adjustment hole is threaded and the rear mounting leg is unthreaded; confirm both against your original unit before ordering.

Frequently Asked Questions

Can the MXA2046 replace the MXA2060?

No. The MXA2046 will not replace the MXA2060, which is a 150 amp unit.

Is the adjustment hole threaded?

Yes. The adjustment hole is threaded, while the rear mounting leg is unthreaded. Confirm both against your original unit before ordering.

What voltage and output does the MXA2046 provide?

The MXA2046 is a 12V alternator delivering 130A of output.

What pulley does the MXA2046 use?

The MXA2046 uses a 7 groove pulley with a 65mm outside diameter.

Is the MXA2046 new or reconditioned?

The MXA2046 is supplied new.
