Product features

OEX HXS053 Starter Motor 12V 9 Tooth CW Hitachi Style

The OEX HXS053 is a new 12V starter motor with a 9 tooth clockwise rotation pinion, Hitachi style, delivering 2.3kW power output with a 2 hole dry clutch mount.

Product Overview

The HXS053 is a new 12V Hitachi style starter motor from OEX, featuring a 9 tooth clockwise rotation pinion and a 2 hole dry clutch mounting arrangement. Delivering a strong 2.3kW of power, the HXS053 is built to a 95mm flange diameter with 120mm mounting centres and an overall length of 230mm.

The HXS053 has a flat section on the flange mount and cannot be replaced with the HXS023, despite similar specifications.

Features & Benefits

Strong 2.3kW Power Rating: The 2.3kW power rating provides strong cranking performance suited to the applications this starter is designed for.

9 Tooth Pinion, Clockwise Rotation: The 9 tooth pinion with clockwise rotation must match the application exactly for correct fitment.

Hitachi Style Design: Built to Hitachi style specifications for compatible fitment across applications originally equipped with a matching Hitachi unit.

Flat Section Flange Mount: The flat section on the flange mount distinguishes this unit and means it cannot be replaced with the HXS023.

2 Hole Dry Clutch Mount: The 2 hole mounting arrangement with a dry clutch design suits the specified fitment applications.

New Unit: Supplied new, not reconditioned.

Technical Specs

Specification Detail
Part No. HXS053
Brand OEX
Type Starter Motor
Voltage 12V
Power Rating 2.3kW
Number of Teeth 9
Rotation CW (Clockwise)
Suits Unit Make Hitachi
Flange Diameter 95mm
Mount Centres A 120mm
Mount Hole Diameter 13mm
Overall Length 230mm
Pinion at Rest 10mm
Pinion Diameter 32mm
Starter Mount Type 2 Hole
Wet / Dry Clutch Dry
New / Reman. New
Weight 5.3kg

Compatible With

The HXS053 is a Hitachi style 9 tooth starter motor with a flat section on the flange mount. This unit cannot be replaced with the HXS023, despite similar specifications. Confirm your original starter's flange design matches before ordering.

Frequently Asked Questions

Can the HXS053 be replaced with the HXS023?

No. The HXS053 has a flat section on the flange mount and cannot be replaced with the HXS023.

What is the power rating of the HXS053?

The HXS053 has a 2.3kW power rating.

How many teeth does the HXS053 pinion have?

The HXS053 has a 9 tooth pinion with clockwise rotation.

What mounting type does the HXS053 use?

The HXS053 uses a 2 hole mounting arrangement with a dry clutch design and a flat section on the flange mount.

Is the HXS053 new or reconditioned?

The HXS053 is supplied new.
