OEX HXS023 Starter Motor 12V 9 Tooth CW Hitachi Style

The OEX HXS023 is a new 12V starter motor with a 9 tooth clockwise rotation pinion, Hitachi style, delivering 2.3kW power output with a 2 hole dry clutch mount.

Product Overview

The HXS023 is a new 12V Hitachi style starter motor from OEX, featuring a 9 tooth clockwise rotation pinion and a 2 hole dry clutch mounting arrangement. Delivering a strong 2.3kW of power, the HXS023 is built to a 95mm flange diameter with 120mm mounting centres and an overall length of 212mm.

The HXS023 is not interchangeable with the HXS053, as the HXS053 has a flat section on the flange mount that the HXS023 does not share. Please confirm compatibility by OE number before ordering.

Features & Benefits

Strong 2.3kW Power Rating: The 2.3kW power rating provides strong cranking performance suited to the applications this starter is designed for.

9 Tooth Pinion, Clockwise Rotation: The 9 tooth pinion with clockwise rotation must match the application exactly for correct fitment.

Hitachi Style Design: Built to Hitachi style specifications for compatible fitment across applications originally equipped with a matching Hitachi unit.

2 Hole Dry Clutch Mount: The 2 hole mounting arrangement with a dry clutch design suits the specified fitment applications.

New Unit: Supplied new, not reconditioned.

Technical Specs

Specification Detail
Part No. HXS023
Brand OEX
Type Starter Motor
Voltage 12V
Power Rating 2.3kW
Number of Teeth 9
Rotation CW (Clockwise)
Suits Unit Make Hitachi
Flange Diameter 95mm
Mount Centres A 120mm
Mount Hole Diameter 13mm
Overall Length 212mm
Pinion at Rest 10mm
Pinion Diameter 32mm
Starter Mount Type 2 Hole
Wet / Dry Clutch Dry
New / Reman. New
Weight 4.58kg

Compatible With

The HXS023 is a Hitachi style 9 tooth starter motor. This unit is not interchangeable with the HXS053, which has a flat section on the flange mount. Please confirm compatibility by OE number before ordering.

Frequently Asked Questions

Can the HXS023 be replaced with the HXS053?

No. The HXS023 is not interchangeable with the HXS053, as the HXS053 has a flat section on the flange mount that the HXS023 does not share.

How do I confirm the HXS023 will fit my vehicle?

Confirm compatibility by OE number before ordering.

What is the power rating of the HXS023?

The HXS023 has a 2.3kW power rating.

How many teeth does the HXS023 pinion have?

The HXS023 has a 9 tooth pinion with clockwise rotation.

Is the HXS023 new or reconditioned?

The HXS023 is supplied new.
