Product features

OEX DXS4040 Starter Motor 12V 9 Tooth CW Denso Style

The OEX DXS4040 is a new 12V starter motor with a 9 tooth clockwise rotation pinion, Denso style, delivering 1.6kW power output with a 2 hole dry clutch mount.

Product Overview

The DXS4040 is a new 12V Denso style starter motor from OEX, featuring a 9 tooth clockwise rotation pinion and a 2 hole dry clutch mounting arrangement. Delivering 1.6kW of power, the DXS4040 is built to a 74mm flange diameter with 104mm mounting centres and an overall length of 190mm.

The OEX brand is sourced from market leading original equipment manufacturers and aftermarket suppliers. OEX products are sourced from ISO certified factories, and each product is backed by a comprehensive nationwide warranty.

Features & Benefits

1.6kW Power Rating: The 1.6kW power rating provides reliable cranking performance suited to the applications this starter is designed for.

9 Tooth Pinion, Clockwise Rotation: The 9 tooth pinion with clockwise rotation must match the application exactly for correct fitment.

Denso Style Design: Built to Denso style specifications for compatible fitment across applications originally equipped with a matching Denso unit.

Lightweight Construction: At 2.92kg, the DXS4040 is notably lighter than similarly specified units in the range.

2 Hole Dry Clutch Mount: The 2 hole mounting arrangement with a dry clutch design suits the specified fitment applications.

ISO Certified Manufacturing: Sourced from ISO certified factories, supporting consistent quality and reliability.

New Unit: Supplied new, not reconditioned.

Technical Specs

Specification Detail
Part No. DXS4040
Brand OEX
Type Starter Motor
Voltage 12V
Power Rating 1.6kW
Number of Teeth 9
Rotation CW (Clockwise)
Suits Unit Make Denso
Flange Diameter 74mm
Mount Centres A 104mm
Mount Hole Diameter M10x1.25
Overall Length 190mm
Pinion at Rest 20mm
Pinion Diameter 29mm
Starter Mount Type 2 Hole
Wet / Dry Clutch Dry
New / Reman. New
Weight 2.92kg

Compatible With

The DXS4040 is a Denso style 9 tooth starter motor. Confirm your original starter's specifications match before ordering, as the similar DXS519 differs in power rating, length, and weight despite sharing the same flange and mounting dimensions.

Frequently Asked Questions

What is the power rating of the DXS4040?

The DXS4040 has a 1.6kW power rating.

How many teeth does the DXS4040 pinion have?

The DXS4040 has a 9 tooth pinion with clockwise rotation.

What is the difference between the DXS4040 and DXS519?

Both share the same flange diameter and mounting dimensions, but the DXS4040 delivers 1.6kW and weighs 2.92kg, while the DXS519 delivers 1.2kW and weighs 3.44kg.

What mounting type does the DXS4040 use?

The DXS4040 uses a 2 hole mounting arrangement with a dry clutch design.

Is the DXS4040 new or reconditioned?

The DXS4040 is supplied new.
