OEX DXA4090 Alternator 12V 120A Denso Style

SKU: DXA4090
Price
$448
Buy now, pay later
  • image
  • image
  • image

Shipping information

We offer fast and reliable shipping options to ensure that your order arrives in a timely manner. Our dedicated team works diligently to process and ship your items as quickly as possible.

Here are some key points to note about our shipping policy:

Standard Shipping

  • Frankies offers a $15.95 flat rate for Australia-wide shipping, no matter how many items you order. Some larger or heavier items may incur an additional fee, which will be communicated to you when your order is processed.
  • While we endeavour to dispatch all orders promptly, please be advised that due to the current national fuel shortages in Australia and the resulting pressure on logistics networks, order processing and dispatch may take up to 7 business days. We are not liable for delays caused by third-party freight carriers or fuel-related logistical disruptions. By placing an order, you acknowledge that delivery timeframes may be extended beyond our standard estimates during this period.

Estimated delivery times:

  • WA, NT, and TAS: currently experiencing longer shipping times
  • Holiday periods (e.g. Christmas): deliveries may be delayed due to increased freight volumes

Express Shipping

  • Express shipping is available and calculated based on your delivery location, as well as the size and weight of your order. To receive an accurate quote, please contact our Albion Park Rail store and request an "express shipping quote." Our team will promptly assist with pricing and availability. Payment for express shipping can be securely arranged over the phone.

Share this product

Share Post Pin E-mail

Product features

OEX DXA4090 12V 120A Denso Style Alternator Pad Mount 180mm CTC 6-Groove 50mm Pulley IR89 New Unit

The OEX DXA4090 is a new 12V 120A alternator in the Denso style with a pad mount configuration. Confirm all mounting dimensions and pin code against your vehicle's existing alternator before ordering. 3-year passenger vehicle warranty, 1-year commercial warranty.

Product overview

The DXA4090 uses a pad mount rather than the leg mount configuration found on most other OEX Denso alternators. A pad mount bolts directly to a flat mounting surface via a solid pad base rather than through separate mounting legs, and is common on certain commercial and industrial vehicle applications. Confirm your vehicle uses a pad mount bracket before ordering.

All mounting dimensions, pin code and pulley configuration should be confirmed against your vehicle's existing alternator before purchasing. The IR89 pin code is specific to this unit within the OEX Denso range covered in this session.

Features and benefits

New unit: Brand new, not remanufactured.

120A output: High-output alternator for vehicles with elevated electrical demands.

Pad mount, 180mm CTC, 69mm inside leg, 72mm leg thickness: Pad mount configuration. Confirm all mounting dimensions against the vehicle before ordering.

6-groove 50mm OD pulley: 6-groove multi-rib pulley for serpentine belt drive systems.

9mm pivot hole, 8mm adjusting hole: Confirm hole sizes suit the vehicle's mounting points.

IR89 pin code: Confirm pin code and all dimensions against your vehicle.

Internal regulator: Voltage regulation handled internally.

Non-insulated return: Earth return is not insulated. Confirm this suits your vehicle's wiring configuration.

3-year passenger / 1-year commercial warranty: Extended warranty for passenger vehicle applications.

Technical specs

Specification Detail
SKU DXA4090
Brand OEX
Voltage 12V
Output 120A
Style Denso
Regulator Internal
Mount Pad
Pulley Section 6-groove
Pulley OD 50mm
Mount CTC 180mm
Inside Leg 69mm
Leg Thickness 72mm
Pivot Hole 9mm
Adjusting Hole 8mm
Pin Code IR89
Insulated Return No
Condition New
Weight 5.98kg
Warranty 3 years (passenger), 1 year (commercial)

Frequently asked questions

Is this a new or remanufactured unit? New. The DXA4090 is a brand new unit, not remanufactured or rebuilt.

What is a pad mount alternator? A pad mount alternator bolts directly to a flat mounting surface via a solid pad base rather than through separate single, twin or quad mounting legs. This configuration is common on certain commercial and industrial vehicle applications. Confirm your vehicle uses a pad mount bracket before ordering.

What does non-insulated return mean? A non-insulated return means the alternator's earth return path runs through the chassis rather than through a dedicated insulated return wire. Confirm this suits your vehicle's wiring configuration before ordering.

What is the warranty on this alternator? 3 years for passenger vehicle applications, 1 year for commercial use.

What should I confirm before ordering this alternator? Confirm mount type (pad), CTC (180mm), inside leg (69mm), leg thickness (72mm), pivot hole (9mm), adjusting hole (8mm), pulley section (6-groove), pulley OD (50mm) and pin code (IR89) all match your vehicle's requirements. Alternators are vehicle-specific, verify fitment before purchasing.
