Product features

OEX BXS4020 12V 1.7kW 10 Tooth CCW Bosch Style Starter Motor, 2-Hole Mount, Dry Clutch, New Unit

The BXS4020 from OEX is a new 12V 1.7kW starter motor in Bosch style with a 10-tooth pinion, counter-clockwise rotation, and a 2-hole mount configuration. It features a 76mm flange diameter, dry clutch, and an overall length of 243mm. Note that this unit will not interchange with BXS0181.

Product overview

The BXS4020 is a direct replacement starter motor suited to applications calling for a Bosch-style unit with CCW rotation and a 2-hole mount. At 1.7kW, it provides the power output required for the engine applications it suits, and the dry clutch design is appropriate for the operating conditions of those vehicles.

This is a new unit, not a remanufactured one, and carries a 3-year warranty for passenger vehicle applications and a 1-year warranty for commercial applications. Before ordering, confirm that this unit does not need to interchange with BXS0181, as the two units are not compatible with each other despite the similar Bosch style classification.

Features and benefits

New unit, not remanufactured: The BXS4020 is supplied as a new starter motor, not a remanufactured unit, providing confidence in service life from the point of installation.

1.7kW power rating: Delivers 1.7kW of cranking power, suited to the engine applications this unit is designed to replace.

10-tooth CCW pinion: Counter-clockwise rotation with a 10-tooth pinion and 28mm pinion diameter, matching the ring gear specifications of confirmed compatible applications.

2-hole Bosch style mount: The 2-hole mounting configuration with 76mm flange diameter and 119mm mount centres suits the engine block mounting points of Bosch-style applications.

Dry clutch design: Fitted with a dry clutch, appropriate for the operating conditions of the applications this unit is designed to suit.

3-year passenger warranty: Backed by a 3-year warranty for passenger vehicle applications and a 1-year warranty for commercial applications.

Will not interchange with BXS0181: This unit is not interchangeable with the OEX BXS0181 despite sharing a similar Bosch style classification. Confirm the correct part number for your application before ordering.

Technical specs

Specification Detail
SKU BXS4020
Brand OEX
Voltage 12V
Power Rating 1.7kW
Rotation Counter-Clockwise (CCW)
Number of Teeth 10
Pinion Diameter 28mm
Pinion at Rest 42mm
Flange Diameter 76mm
Mount Centres A 119mm
Mount Hole Diameter 11mm
Overall Length 243mm
Starter Mount Type 2 Hole
Clutch Type Dry
Suits Unit Make Bosch Style
Condition New
Weight 3.76kg
Warranty 3 Years Passenger, 1 Year Commercial

Frequently asked questions

Will the BXS4020 interchange with the OEX BXS0181?
No. Despite both being Bosch style starter motors, the BXS4020 will not interchange with the BXS0181. Confirm the correct part number for your specific application before ordering. Contact us if you need assistance identifying the right unit.

Is the BXS4020 a new or remanufactured unit?
The BXS4020 is a new starter motor, not a remanufactured unit.

What warranty does the BXS4020 carry?
The BXS4020 is backed by a 3-year warranty for passenger vehicle applications and a 1-year warranty for commercial applications.

What is the rotation direction of the BXS4020?
The BXS4020 rotates counter-clockwise (CCW). Confirm that your application requires CCW rotation before ordering, as fitting an incorrect rotation direction will result in the starter not engaging the ring gear correctly.

What are the key dimensions I need to confirm before ordering?
The key dimensions for fitment confirmation are the flange diameter (76mm), mount centres A (119mm), mount hole diameter (11mm), pinion diameter (28mm), pinion at rest (42mm), and overall length (243mm). Contact us if you need assistance confirming fitment for your specific application.
