OEX BXS0201 Starter Motor 12V 11Th CCW Bosch Style

SKU: BXS0201
Price
$369
Buy now, pay later
  • image
  • image
  • image

Shipping information

We offer fast and reliable shipping options to ensure that your order arrives in a timely manner. Our dedicated team works diligently to process and ship your items as quickly as possible.

Here are some key points to note about our shipping policy:

Standard Shipping

  • Frankies offers a $15.95 flat rate for Australia-wide shipping, no matter how many items you order. Some larger or heavier items may incur an additional fee, which will be communicated to you when your order is processed.
  • While we endeavour to dispatch all orders promptly, please be advised that due to the current national fuel shortages in Australia and the resulting pressure on logistics networks, order processing and dispatch may take up to 7 business days. We are not liable for delays caused by third-party freight carriers or fuel-related logistical disruptions. By placing an order, you acknowledge that delivery timeframes may be extended beyond our standard estimates during this period.

Estimated delivery times:

  • WA, NT, and TAS: currently experiencing longer shipping times
  • Holiday periods (e.g. Christmas): deliveries may be delayed due to increased freight volumes

Express Shipping

  • Express shipping is available and calculated based on your delivery location, as well as the size and weight of your order. To receive an accurate quote, please contact our Albion Park Rail store and request an "express shipping quote." Our team will promptly assist with pricing and availability. Payment for express shipping can be securely arranged over the phone.

Share this product

Share Post Pin E-mail

Product features

OEX BXS0201 12V 1.1kW 11 Tooth CCW Bosch Style Starter Motor, 2-Hole Mount, New Unit

The BXS0201 from OEX is a new 12V 1.1kW starter motor in Bosch style with an 11-tooth pinion, counter-clockwise rotation, and a 2-hole mount configuration. It features a 79mm flange diameter, 119mm mount centres, and an overall length of 210mm. Sourced from ISO certified factories and backed by a comprehensive nationwide warranty.

Product overview

The BXS0201 is a direct replacement starter motor suited to applications calling for a Bosch-style unit with CCW rotation, an 11-tooth pinion, and a 2-hole mount. At 1.1kW, it delivers the cranking power required for the engine applications it is designed to replace.

OEX products are sourced from market-leading original equipment manufacturers and aftermarket suppliers operating from ISO certified factories. The BXS0201 carries a 3-year warranty for passenger vehicle applications and a 1-year warranty for commercial applications, backed by a comprehensive nationwide warranty network. This is a new unit, not a remanufactured one.

Features and benefits

New unit, not remanufactured: The BXS0201 is supplied as a new starter motor, providing confidence in service life from the point of installation.

1.1kW power rating: Delivers 1.1kW of cranking power, suited to the engine applications this unit is designed to replace.

11-tooth CCW pinion: Counter-clockwise rotation with an 11-tooth pinion and 28mm pinion diameter, matching the ring gear specifications of confirmed compatible applications.

2-hole Bosch style mount: The 2-hole mounting configuration with 79mm flange diameter and 119mm mount centres suits the engine block mounting points of Bosch-style applications calling for these dimensions.

ISO certified manufacturing: OEX products are sourced from ISO certified factories, providing assurance of consistent quality and manufacturing standards.

3-year passenger warranty: Backed by a 3-year warranty for passenger vehicle applications and a 1-year warranty for commercial applications, supported by a comprehensive nationwide warranty network.

Technical specs

Specification Detail
SKU BXS0201
Brand OEX
Voltage 12V
Power Rating 1.1kW
Rotation Counter-Clockwise (CCW)
Number of Teeth 11
Pinion Diameter 28mm
Pinion at Rest 42.5mm
Flange Diameter 79mm
Mount Centres A 119mm
Mount Hole Diameter 11mm
Overall Length 210mm
Starter Mount Type 2 Hole
Suits Unit Make Bosch Style
Condition New
Weight 3.08kg
Warranty 3 Years Passenger, 1 Year Commercial

Frequently asked questions

Is the BXS0201 a new or remanufactured unit?
The BXS0201 is a new starter motor, not a remanufactured unit.

What warranty does the BXS0201 carry?
The BXS0201 is backed by a 3-year warranty for passenger vehicle applications and a 1-year warranty for commercial applications, supported by a comprehensive nationwide OEX warranty network.

What is the rotation direction of the BXS0201?
The BXS0201 rotates counter-clockwise (CCW). Confirm that your application requires CCW rotation before ordering, as an incorrect rotation direction will prevent the starter from engaging the ring gear correctly.

What standards are OEX products manufactured to?
OEX products are sourced from market-leading original equipment manufacturers and aftermarket suppliers operating from ISO certified factories, providing assurance of consistent manufacturing quality.

What are the key dimensions I need to confirm before ordering?
The key dimensions for fitment confirmation are the flange diameter (79mm), mount centres A (119mm), mount hole diameter (11mm), pinion diameter (28mm), pinion at rest (42.5mm), and overall length (210mm). Contact us if you need assistance confirming fitment for your specific application.
