OEX BXS0164 Starter Motor 12V 10Th CCW Bosch Style

SKU: BXS0164
Price
$379
Buy now, pay later
  • image
  • image
  • image

Shipping information

We offer fast and reliable shipping options to ensure that your order arrives in a timely manner. Our dedicated team works diligently to process and ship your items as quickly as possible.

Here are some key points to note about our shipping policy:

Standard Shipping

  • Frankies offers a $15.95 flat rate for Australia-wide shipping, no matter how many items you order. Some larger or heavier items may incur an additional fee, which will be communicated to you when your order is processed.
  • While we endeavour to dispatch all orders promptly, please be advised that due to the current national fuel shortages in Australia and the resulting pressure on logistics networks, order processing and dispatch may take up to 7 business days. We are not liable for delays caused by third-party freight carriers or fuel-related logistical disruptions. By placing an order, you acknowledge that delivery timeframes may be extended beyond our standard estimates during this period.

Estimated delivery times:

  • WA, NT, and TAS: currently experiencing longer shipping times
  • Holiday periods (e.g. Christmas): deliveries may be delayed due to increased freight volumes

Express Shipping

  • Express shipping is available and calculated based on your delivery location, as well as the size and weight of your order. To receive an accurate quote, please contact our Albion Park Rail store and request an "express shipping quote." Our team will promptly assist with pricing and availability. Payment for express shipping can be securely arranged over the phone.

Share this product

Share Post Pin E-mail

Product features

OEX BXS0164 12V 1.1kW 10 Tooth CCW Bosch Style Starter Motor

The OEX BXS0164 is a new 12V starter motor with a 1.1kW power rating, 10 tooth pinion and CCW rotation. It uses a Bosch style configuration with a 76mm flange, two-hole mounting and 213mm overall length.

Product overview

Designed as a replacement starter motor, the BXS0164 suits Bosch style units and operates at 12V. The unit has a 27mm pinion diameter, 42mm pinion at rest and 119mm mounting centres.

The supplied specifications identify this as a new, dry clutch starter motor weighing 3.0kg. The 1.1kW unit has a 213mm overall length. For the 1.7kW version with a 243mm overall length, use BXS4020.

Features and benefits

1.1kW power rating 12V operation: Provides a 1.1kW starting motor configuration for 12V electrical systems.

10 tooth pinion Bosch style: Uses a 10 tooth pinion with a 27mm pinion diameter and Bosch style configuration.

CCW rotation Confirmed rotation direction: The starter motor is specified for counter-clockwise rotation.

Two-hole starter mount Defined mounting arrangement: Uses a two-hole starter mounting configuration with 119mm mount centres and 11mm mounting holes.

213mm overall length 1.1kW configuration: The 1.1kW version measures 213mm overall. The source identifies BXS4020 as the 1.7kW alternative with a 243mm overall length.

Technical specs

Specification Detail
SKU BXS0164
Brand OEX
Type Starter Motor
Voltage 12V
Power Rating 1.1kW
Rotation CCW
Number of Teeth 10
Pinion Diameter 27mm
Pinion at Rest 42mm
Flange Diameter 76mm
Mount Centres A 119mm
Mount Hole Diameter 11mm
Overall Length 213mm
Starter Mount Type 2 Hole
Wet / Dry Clutch Dry
Suits Unit Make Bosch
New / Reman. New
Weight 3.0kg
Warranty 3yr Passenger, 1yr Commercial

Compatible with

The BXS0164 is specified as a Bosch style starter motor. It is the 1.1kW version with a 213mm overall length. For the 1.7kW version with a 243mm overall length, the source specifies BXS4020.

Frequently asked questions

What voltage is the OEX BXS0164 starter motor?

The BXS0164 operates at 12V. It has a 1.1kW power rating.

How many teeth does the BXS0164 starter motor have?

The starter motor has 10 teeth. The specified pinion diameter is 27mm.

What direction does the BXS0164 starter motor rotate?

The BXS0164 is specified with CCW rotation. This should be matched to the required application before installation.

How long is the BXS0164 starter motor?

The overall length is 213mm. The source notes that the 1.7kW BXS4020 version has a 243mm overall length.

What is the warranty on the BXS0164?

The supplied source specifies a 3 year passenger warranty and a 1 year commercial warranty.
