OEX ACX0710L 3 mm Single Core Auto Cable Violet 100 m Roll

SKU: ACX0710L
Price
$92
Inc. GST. Most orders ship Australia wide for a flat $15.95. Larger or heavier items may cost more.
Buy now, pay later
  • image
  • image
  • image

Shipping information

Australia wide flat rate shipping is $15.95. Larger or heavier items may cost more; we will confirm when your order is processed. In stock items are dispatched within 1 to 2 business days. Report transit damage within 24 hours with photos so we can lodge a freight claim.

Share this product

Share Post Pin E-mail
OEX ACX0710L 3mm Automotive Cable, Single Core Violet 100m Roll

OEX ACX0710L 3 mm Single Core Auto Cable Violet 100 m Roll

$92

Product features

Australian made 3 mm single core automotive cable in violet, on a 100 m roll.

It has a 1.13 mm² oxygen free copper conductor in fine strands, with UV stabilised V90 PVC insulation that copes with engine bay heat and sun on the outside of a vehicle.

OEX rates it at 10 A continuous at 30 degrees, which suits switch feeds, relay wiring, lighting and general accessory circuits.

Specifications

  • Industry size: 3 mm
  • Cross section: 1.13 mm²
  • Gauge: 17 AWG
  • Strands: 16 x 0.32 mm
  • Conductor: OFHC copper
  • Current rating: 10 A at 30 degrees
  • Voltage rating: up to 110 V
  • Insulation: PVC, V90, UV stabilised
  • Colour: Violet
  • Length: 100 m roll
  • Weight: 1.4 kg
  • Standards: AS/NZS 3808:2000, RoHS
  • Made in: Australia

FAQ

What is the OEX ACX0710L?

OEX Australian made 3 mm single core automotive cable, violet, 100 m roll. 1.13 mm² OFHC copper, 10 A rated, V90 UV stable PVC.

How do I choose between 3, 4, 5 and 6 mm cable?

Go by the current draw and the run length. OEX rates 3 mm at 10 A, 4 mm at 15 A, 5 mm at 20 A and 6 mm at 30 A at 30 degrees. Long runs need a size up to keep voltage drop down.

Can you help me pick the right size?

Yes. Send us the job, the current draw and the length of the run and we will point you to the right cable.
