Black 7 pin flat plug seen from the pin side, with the cable boot on the right
Black 7 pin flat plug seen from the pin side, with the cable boot on the right
Click to open expanded view
NARVA logo

Narva 82141BL 7 Pin Flat 'Quickfit' Plastic Trailer Plug

SKU: 82141BL
Price
$22
Inc. GST. Most orders ship Australia wide for a flat $15.95. Larger or heavier items may cost more.
Buy now, pay later
  • image
  • image
  • image

Not on our shelf right now. We order this one in from our supplier.
Shipping information

Australia wide flat rate shipping is $15.95. Larger or heavier items may cost more; we will confirm when your order is processed. In stock items are dispatched within 1 to 2 business days. Report transit damage within 24 hours with photos so we can lodge a freight claim.

Share this product

Share Post Pin E-mail
Black 7 pin flat plug seen from the pin side, with the cable boot on the right

Narva 82141BL 7 Pin Flat 'Quickfit' Plastic Trailer Plug

$22

Product features

The Narva 82141BL is a 7 pin flat Quickfit trailer plug, the plug that goes on the trailer's cable. It has an ABS body with nickel plated terminals for better conductivity, is rated at 15A per pin at 12V, and meets the relevant ADRs.

Common reasons to replace a trailer plug

A trailer plug gets dragged on the ground, run over and left out in the rain. Cracked bodies, bent pins and green corrosion cause flickering lights and brake lights that work one day and fail the next. A fresh plug with plated terminals is a cheap fix that clears up most intermittent trailer light faults.

Specifications

Part number 82141BL
Connector style 7 pin flat
Item Trailer plug
Body Plastic, ABS
Terminals Nickel plated brass
Rating 15A at 12V
Compliance Relevant ADRs

Wiring it

Strip each core only as far as the terminal needs, twist the strands and tighten the screw firmly. Use the standard Australian 7 pin flat pinout, and make sure the cable clamp grips the outer sheath, not the cores. A dab of dielectric grease on the pins slows corrosion.

Warranty

This comes with the manufacturer's warranty through the Australian distributor. See the manufacturer's terms for details, plus our guarantees under the Australian Consumer Law.

FAQ

Is this a plug or a socket?

A plug, for the trailer side.

Does it match a 7 pin flat socket on my car?

Yes, it is a 7 pin flat pattern.

What is the current rating?

15A at 12V.

How do I wire the plug?

Feed the trailer cable through the cover, land each core on its numbered pin under the screw, then close the Quickfit body around the cable.

Is it a single plug?

Yes. You get one 7 pin flat plug for the trailer cable. The car side socket is the 82042BL.
