Nakamichi NA9TOYOTAHIACE20192022 9" Wireless CarPlay Android Auto Toyota Hiace 2019-2022 Head Unit

Transform your Toyota Hiace commercial van with wireless smartphone integration and Android 13 capability.

Product Overview

The Nakamichi NA9TOYOTAHIACE20192022 transforms your Toyota Hiace's factory infotainment into a comprehensive Android 13 multimedia system with wireless Apple CarPlay and Android Auto integration. This vehicle-specific 9-inch IPS touchscreen head unit is engineered exclusively for sixth-generation Toyota Hiace models from 2019-2022, replacing the factory display with a plug-and-play solution that includes the matching fascia panel for seamless dashboard integration. The system works directly with your factory Hiace reversing camera and retains factory USB functionality, eliminating the need for additional adapters or complex wiring modifications. Running Android 13 (NK 13.0) with 4GB RAM and 64GB internal storage, the system delivers smooth performance across navigation, media playback, and app multitasking while providing ample space for offline maps, music libraries, and Android apps from the Google Play Store. Beyond smartphone mirroring, the system includes built-in GPS with preloaded navigation data, WiFi connectivity, comprehensive AM/FM radio with RDS supporting 18 FM and 12 AM presets, and Bluetooth 5.0 for hands-free calling and wireless audio streaming. The 4×50W amplifier drives factory Hiace speakers or upgraded components, while 4V pre-outputs provide clean signal to external amplifiers. Factory steering wheel controls are retained via CAN bus integration, maintaining the convenient control experience Hiace operators need during commercial deliveries, passenger transport, and mobile business operations.

Key Specifications

• 9-inch IPS touchscreen display with 1280×720 resolution and 500nit brightness
• Android 13 operating system (NK 13.0)
• 4GB RAM with 64GB internal storage
• Wireless Apple CarPlay and Android Auto (wired for some Android devices)
• Built-in GPS with preloaded navigation data, updateable via Google Play Store
• WiFi connectivity for internet access and app functionality
• Bluetooth 5.0+EDR (2.4GHz, 5m range)
• AM/FM radio tuner: FM 87.5-108.0MHz, AM 522-1620kHz with 18 FM/12 AM presets
• 4×50W maximum amplifier output to 4-8Ω speakers
• 4V/10kΩ pre-outputs with ≤600Ω impedance for external amplifiers
• Factory reversing camera compatibility (plug-and-play)
• Factory USB retention (maintains original USB functionality)
• Front camera/auxiliary video input
• Dual USB interfaces: 4-pin for PhoneLink, 6-pin for media playback
• Factory steering wheel control compatibility via CAN bus integration
• External microphone included for enhanced hands-free clarity
• Video format support: H264, MP4, AVI, MKV, FLV
• Audio format support: MP3, APE, AAC, FLAC
• 10.5-16V operating voltage range (14.4V nominal)
• Includes Hiace-specific fascia panel for 2019-2022 models
• Compatible exclusively with Toyota Hiace 2019-2022 (sixth-generation)

Features & Benefits

Hiace 2019-2022-Specific Engineering – Designed exclusively for sixth-generation Toyota Hiace commercial vans from 2019-2022 with included fascia panel that matches your factory dash perfectly. Plug-and-play harnesses connect to existing wiring without cutting or splicing, maintaining the reliability Toyota engineered into Australia's most trusted commercial van platform.

Factory Camera Integration – Works directly with your Toyota Hiace factory reversing camera without requiring additional adapters or complex hardwiring. The system switches automatically to rear view when you select reverse gear, maintaining the safety feature Toyota designed for commercial operations, tight parking, and loading dock maneuvers.

Factory USB Retention – Maintains your factory USB ports and functionality, preserving original USB charging and data connections while adding the new head unit's capabilities. This integration ensures passengers can charge devices using factory-installed USB ports without sacrificing functionality during commercial operations.

Wireless CarPlay Freedom – Connect your iPhone wirelessly and access Apple Maps, Spotify, Messages, and Siri through the 9-inch display without cable clutter. The system remembers your device and connects automatically when you start your Hiace, keeping your charging port available during commercial deliveries, passenger transport, or mobile business operations.

Android Auto Convenience – Pair compatible Android phones wirelessly (some models require wired connection) to mirror Google Maps, YouTube Music, WhatsApp, and Google Assistant on the touchscreen. Voice commands handle navigation and messaging while your hands remain on the wheel managing delivery schedules and commercial routes.

Latest Android 13 System – The upgraded NK 13.0 operating system provides enhanced security protocols, improved app compatibility, and refined performance over previous Android versions. Access Google Play Store to download fleet management apps, delivery tracking tools, and navigation solutions while the system manages updates automatically over WiFi.

Expanded 64GB Storage – Double the internal storage of earlier models accommodates extensive offline map data for delivery routes and regional coverage, large music libraries for extended commercial driving, multiple navigation apps for route optimization, and various Android applications essential for mobile business operations.

Built-In GPS Navigation – Preloaded GPS data provides offline navigation capability when mobile coverage drops on regional delivery routes or areas with limited cellular reception. Download alternative navigation apps from Google Play Store, update maps over WiFi, or run multiple navigation solutions optimized for commercial routing and delivery efficiency.

High-Brightness IPS Display – The 1280×720 resolution IPS panel with 500nit brightness maintains excellent visibility in direct Australian sunlight, essential for Hiace operators navigating sunny conditions during commercial deliveries and passenger transport. Wide viewing angles ensure clear visibility, and the capacitive touchscreen responds intuitively during commercial operations.

Enhanced Pre-Output Signal – The 4V pre-output voltage delivers twice the signal strength of standard 2V units, reducing noise interference when driving external amplifiers. This clean signal improves sound quality in upgraded audio systems, ideal for Hiace operators seeking premium audio quality during extended commercial driving or passenger transport services.

Complete Installation Package – Includes Hiace-specific fascia panel, main wiring harness, RCA cables, camera cable, speaker cables, external microphone, GPS antenna, USB cables, and user manual. Everything required for installation is provided, though professional fitting is recommended for optimal integration with factory Hiace systems.

Technical Specs

• Display: 9" IPS touchscreen, 1280×720 resolution, 500nit brightness
• System: Android 13 (NK 13.0)
• Memory: 4GB RAM, 64GB internal storage
• Smartphone Integration: Wireless Apple CarPlay, Android Auto (wireless/wired depending on device)
• GPS: Built-in with preloaded data, updateable via Google Play Store
• Connectivity: WiFi
• Bluetooth: Version 5.0+EDR, 2.4GHz frequency, 5m range
• Radio Tuner: FM 87.5-108.0MHz, AM 522-1620kHz, RDS support, 18 FM/12 AM presets
• Audio Output: 4 channels × 50W maximum, 4-8Ω speaker impedance
• Pre-Outputs: 4V/10kΩ, ≤600Ω impedance (front left/right, rear left/right, subwoofer)
• Video Inputs: Factory reversing camera (compatible), front camera/auxiliary
• USB Interfaces: 4-pin (PhoneLink), 6-pin (media playback)
• USB Charging: 5V±0.25V/1A
• Video Formats: H264, MP4, AVI, MKV, FLV
• Audio Formats: MP3, APE, AAC, FLAC
• Power: 14.4V nominal (10.5-16V operating range)
• CAN Bus: Factory steering wheel control integration
• Factory USB: Retention of original USB functionality
• Microphone: External microphone included
• Antenna: GPS antenna included
• Fascia: Toyota Hiace 2019-2022 specific panel included

Compatible Vehicle:

• Toyota Hiace: 2019-2022 (sixth-generation, all variants including LWB, SLWB)

Package Includes:

• 1× Nakamichi head unit with Hiace-specific fascia panel
• 1× Main wiring harness
• 1× RCA cable
• 1× Camera cable
• 1× Rear left/right speaker cable
• 1× External microphone
• 1× GPS antenna
• 1× User manual
• 2× USB cables

Frequently Asked Questions

Is this specifically designed for my 2019-2022 Hiace?

Yes, this unit is engineered exclusively for sixth-generation Toyota Hiace models from 2019-2022 including all variants. The included fascia panel and wiring harness are configured for this generation-specific integration. Contact us with your exact Hiace year and variant plus a photo of your current dash to confirm harness compatibility before purchase.

Will my factory reversing camera work with this unit?

Yes, the system is designed to work directly with Toyota Hiace 2019-2022 factory reversing cameras without requiring additional adapters or complex wiring. The camera cable connects to your existing camera wiring, and the display switches automatically to rear view when you select reverse gear.

Does this maintain my factory USB ports?

Yes, the system retains factory USB functionality, maintaining original USB charging and data connections. Your factory USB ports continue to work for passenger charging and device connectivity while the new head unit adds dual USB interfaces for PhoneLink and media playback.

Is CarPlay and Android Auto wireless or wired?

Apple CarPlay is wireless for all iPhones. Android Auto is wireless for most modern Android devices, but some specific phone brands may require wired USB connection via the included 4-pin PhoneLink cable. Both connection methods are fully supported through the dual USB interface.

Will my steering wheel controls continue to work?

Yes, CAN bus integration maintains factory Toyota Hiace steering wheel control functionality. The system communicates directly with your vehicle's control protocols, allowing continued use of volume, track skip, and call management buttons without requiring additional adapters.

Compatible With / Goes Well With

• Toyota Hiace 2019-2022 factory reversing cameras (plug-and-play)
• Factory Hiace steering wheel control systems
• Factory USB ports (retained functionality)
• External amplifiers via 4V RCA pre-outputs
• Component speakers and coaxial speakers (4Ω to 8Ω)
• Subwoofer systems via dedicated pre-output
• GPS antenna extension cables for optimal signal placement
• Front-facing dash cameras via auxiliary video input
• Android Auto-compatible apps from Google Play Store
• Fleet management and delivery tracking applications
• WiFi-enabled streaming services and navigation apps
• Professional installation services for commercial vehicle integration
