Product features

Ideal Amplifier For Speaker Systems & Efficient Subwoofers!

8-Channel High-Quality DSP Amplifier
The MOSCONI ONE 90.8 DSP is a universal 8-channel high-quality amplifier in Class AB technology and an integrated digital sound processor. It is the ideal amplifier for speaker systems and/ or efficient subwoofers. The digital 8-channel sound processor allows you to adjust your car's Hi-Fi system perfectly via PC software. In addition to an extensive active crossover, equalizer, and delay correction, various special filters are available. For system expansion, the ONE 90.8 DSP has a processed preamplifier output. Here you can easily connect the "Line IN" of another mono or stereo amplifier.

Features:

  • Class AB power amplifier full MOSFET
  • Unregulated power supply
  • High-level input with auto-sense power-on
  • Remote Volume Control DSP-RCD or DSP-RC MINI (Optional)
  • On-board DSP + 2 digitally processed line outputs

Specifications:

  • Colour: Black
  • Finishing: Powder Coating
  • Power Supply Voltage: 10 - 16V
  • DC-DC Converter Typology: Unregulated – Push Pull
  • Internal Fuse: 2 x 40A
  • Autosense Power-On (High Level Only): OFF-BTL-SE
  • Overall Efficiency: >60%
  • REM Output: 10 - 16V (100mA)
  • Stereo Power RMS @ 4Ω: 90W x 8
  • Promiscuous Mode Power RMS @ 4Ω 85W x 4 + 250W x 2 (BTL)
  • Bridge Power RMS @ 4Ω: 240W x 4
  • Stereo Power RMS @ 2Ω: 120W x 8 (BTL Not Allowed)
  • Low Level + High-Level Input Sensitivity Range: 0.8 ÷ 17V
  • Auto-Fading Between Inputs: Yes
  • Signal Mix Capability: Yes
  • Low-Level Input: RCA
  • High-Level Input: RCA
  • Pre Output: RCA (CH 7-8) DSP Processed
  • PC Connection: USB
  • Remote Control (Optional): Modular Jack
  • Bluetooth (Optional): MOS_BTM
  • Gain Level For Each Channel: -115 ÷ 6dB
  • Parametric Equalizer Bands (CH 1-2): 30
  • Parametric Equalizer Bands (CH 3-4): 25
  • Parametric Equalizer Bands (CH 5-6-7-8): 9
  • Preset: 4 Available
  • HP Frequency Range For Each Channel: 10 ÷ 20000Hz
  • LP Frequency Range For Each Channel: 10 ÷ 20000Hz
  • HP & LP Filter Slope For Each Cell: 6-12dB
  • HP & LP Filter Slope if Cascated (CH 1-4): Up to 60dB
  • HP & LP Filter Slope if Cascated (CH 5-8): Up to 48dB
  • Band Pass: Allowed
  • Variable «Q» Factor: 0.5 ÷ 40
  • Time Delay: 0 ÷ 15ms (Steps of 0.02ms)
  • Phase Inversion For Each Channel: 0/180°
  • Dimensions: 300mm x 200mm x 50mm
  • Weight: 2.60kg
