Mongoose MC6NA/PA | Heavy Duty Audio Camera

Ultimate heavy duty metal camera with integrated audio microphone for complete incident documentation.

Product Overview

The Mongoose MC6NA/PA Heavy Duty Audio Camera combines robust metal body construction with integrated microphone technology to provide comprehensive audio-visual monitoring for the most demanding commercial applications. This professional safety camera features IP69K protection rating with Sony CCD image processing, delivering reliable performance in extreme Australian conditions while capturing both video and audio for complete incident documentation.

Available in PAL (MC6PA) and NTSC (MC6NA) TV systems, this audio-enabled camera is perfect for fleet management, security monitoring, and professional installations requiring complete situational awareness. The integrated microphone provides synchronized audio recording essential for understanding incident context and communication during reversing or monitoring operations.

Key Specifications

• Heavy duty metal body construction with integrated microphone
• IP69K water and dust protection (highest available rating)
• Sony CCD image processor with 420 TV line resolution
• Available in PAL (MC6PA) or NTSC (MC6NA) TV systems
• Viewing angles: Horizontal 90°, Vertical 70°, Diagonal 100°
• Night vision: 18x infrared LEDs
• Built-in microphone for audio recording
• 4G vibration rating for heavy machinery
• Operating temperature: -20°C to 70°C
• Complete installation kit included

Features & Benefits

Complete Audio-Visual Documentation - Integrated microphone provides synchronized audio recording with video, ensuring complete incident documentation including verbal communications, equipment sounds, and environmental audio cues essential for professional fleet management.

Extreme Environment Durability - IP69K protection with 4G vibration rating and metal construction handles the harshest conditions from mining operations to agricultural machinery, withstanding high-pressure washing, extreme temperatures, and heavy vibration.

Professional Sony CCD Performance - Superior image quality with Sony CCD processor ensures reliable performance across temperature extremes (-20°C to 70°C), maintaining consistent video quality in demanding Australian commercial environments.

Complete Installation Solution - Comprehensive kit includes hexagon screws, wrench, sunshade, U-bracket, user manual, 4-pin RCA adapter, and DC power cable for professional installation without additional component sourcing.

Advantages & Limitations

Advantages:

• Integrated microphone for complete audio-visual recording
• IP69K highest protection rating with 4G vibration resistance
• Professional Sony CCD image processor
• Complete installation kit with all accessories
• Available in both PAL and NTSC systems
• Metal construction for extreme durability
• Wide temperature operating range (-20°C to 70°C)

Limitations:

• Higher cost than video-only cameras
• Heavier weight requires secure mounting (86.5 x 77 x 75mm)
• 420 TV line resolution (not HD)
• Professional installation recommended for optimal audio performance

Technical Specs

• Construction: Heavy duty metal body with integrated microphone
• Protection: IP69K (water jets, steam, dust proof)
• Vibration rating: 4G for heavy machinery applications
• Image processor: Sony CCD, 420 TV line resolution
• TV systems: PAL (MC6PA) or NTSC (MC6NA)
• Viewing angles: 90°H, 70°V, 100°D
• Night vision: 18x infrared LEDs
• Audio: Built-in microphone
• Operating temperature: -20°C to 70°C
• Connector: 4-pin aviation connector
• Dimensions: 86.5 x 77 x 75mm
• Includes: Complete installation kit with accessories

Frequently Asked Questions

How does the audio recording work? The built-in microphone captures synchronized audio with video, providing complete incident documentation including verbal communications and environmental sounds during operation.

Can this withstand mining and construction environments? Yes, the IP69K rating with 4G vibration resistance and metal construction make it specifically designed for the harshest industrial applications including mining and heavy construction.

What's included in the installation kit? Complete kit includes hexagon screws, wrench, sunshade, U-bracket, user manual, 4-pin RCA adapter, and DC power cable for professional installation.

Compatible With / Goes Well With

• Professional MDVR systems with audio recording
• Fleet management monitoring solutions
• Heavy commercial vehicle installations
• Mining and construction equipment
• Agricultural machinery monitoring
• Security surveillance systems requiring audio
