Mongoose MC6BWH Wireless Rear Camera for MCK741WH Monitor System

Additional wireless camera to expand your MCK741WH system coverage

The Mongoose MC6BWH is a professional-grade wireless rear camera designed specifically for use with the MCK741WH monitor system. This high-definition 1080p AHD camera utilises advanced 2.4GHz digital wireless technology to transmit crystal-clear video without cables, making it perfect for adding extra coverage to trucks, buses, campervans, and commercial vehicles.

With superior IP69K waterproofing and 18 powerful infrared LEDs, this camera delivers exceptional performance in all weather conditions and provides clear night vision down to 0.1 Lux. The robust construction and wide 125° diagonal viewing angle make it ideal for monitoring blind spots, trailer connections, or side areas of large vehicles.

Features & Benefits

• MCK741WH Compatible: Designed specifically to work with the MCK741WH wireless monitor system
• True Wireless Connection: 2.4GHz digital transmission eliminates cable installation between camera and monitor
• 1080p AHD Quality: High-definition SONY sensor delivers crisp, clear video in 1280x1080 resolution
• Superior Waterproofing: IP69K rating provides maximum protection against water, dust, and harsh conditions
• Exceptional Night Vision: 18 infrared LEDs provide clear visibility down to 0.1 Lux illumination
• Wide Angle Coverage: 125° diagonal viewing angle captures maximum area around your vehicle
• Heavy Duty Construction: Built to withstand commercial vehicle vibration (4G rating) and temperature extremes
• Dual Voltage Operation: 12V~24V compatibility for cars, trucks, and heavy machinery
• Surface Mount Design: U-bracket mounting system for secure installation on any vehicle surface
• PAL TV System: Compatible with Australian broadcasting standards
• Complete Installation Kit: Includes all mounting hardware, brackets, and cables needed

Technical Specs

• Resolution: 1280x1080 (1080p AHD)
• Image Sensor: SONY AHD sensor
• Lens Angle: Horizontal 95°, Vertical 75°, Diagonal 125°
• TV System: PAL
• Wireless Technology: 2.4GHz digital transmission
• Waterproof Rating: IP69K
• Vibration Rating: 4G
• Operating Voltage: 12V~24V DC
• Night Vision: 0.1 Lux minimum illumination
• IR LEDs: 18 pieces
• Built-in Microphone: No
• Connection Type: DC connector
• Cable Length: 0.6m power line
• Dimensions: 86.5mm × 77mm × 75mm
• Housing Colour: Black
• Operating Temperature: -20°C to 70°C
• Storage Temperature: -30°C to 80°C
• Mounting Type: Surface mount U-bracket
• Brand: Mongoose
• Model Number: MC6BWH
• Barcode: 9326270001914

Compatible With

• MCK741WH wireless monitor system (required)
• Additional MC6BWH cameras (up to 4 total on one system)
• 12V and 24V commercial vehicle electrical systems
• Trucks, buses, and delivery vehicles
• Campervans, motorhomes, and RVs
• Trailers and heavy machinery
• Fleet vehicle applications

What's Included:

• 1x MC6BWH wireless camera
• 1x Hexagon screws
• 1x Hexagon wrench
• 1x Sunshade
• 1x U-shape bracket
• 1x User manual
• 1x 4pin-RCA adapter
• 1x DC power cable

Installation Notes:

• Requires MCK741WH monitor system to operate
• Although video signal is wireless, camera requires 12V~24V power and earth connections
• Professional installation recommended for optimal positioning and power connections
• Up to 4 MC6BWH cameras can be connected to one MCK741WH system
