Mongoose MC10D | AHD Mini Dome Camera

Quick answer

The Mongoose MC10D is the | AHD Mini Dome Camera. The compact 45mm housing with metal construction ensures reliable operation while maintaining minimal visual impact inside vehicles.

Ultra-compact AHD mini dome camera designed for internal vehicle monitoring with audio recording.

Product Overview

The Mongoose MC10D AHD Mini Dome Camera delivers professional 1080P high-definition monitoring in an ultra-compact design specifically engineered for internal vehicle applications. This discreet mini dome camera is ideal for MDVR systems and AHD monitors, providing comprehensive interior surveillance with both video and audio recording capabilities for fleet management, security, and driver safety applications.

The compact 45mm housing with metal construction ensures reliable operation while maintaining minimal visual impact inside vehicles. With 150° wide angle coverage and infrared night vision, the MC10D provides complete interior monitoring capability perfect for commercial vehicles, taxis, buses, and security applications requiring discreet internal surveillance.

Key Specifications

• AHD 1080P Full HD resolution
• Ultra-compact mini dome design (45 x 32 x 43mm)
• 1/3" CMOS image sensor technology
• 150° wide angle lens coverage
• Night vision with 2x infrared LEDs
• 1-channel audio recording capability
• Metal case mini housing construction
• Internal use only application
• Heavy duty 4-pin connector system
• Weight: 100g lightweight design
• PAL TV system standard

Features & Benefits

Ultra-Compact Discreet Design: Minimal 45mm mini dome housing provides professional surveillance capability without overwhelming vehicle interiors, perfect for maintaining aesthetic appeal while ensuring comprehensive monitoring coverage.

150° Wide Interior Coverage: Exceptional wide angle lens captures complete interior views from a single mounting point, ideal for monitoring driver areas, passenger compartments, or cargo spaces in commercial vehicle applications.

Professional Audio Recording: Integrated 1-channel audio capability provides complete incident documentation with synchronized video and sound recording, essential for fleet management and security applications.

Internal Night Vision: Dual infrared LEDs ensure clear monitoring capability in low-light conditions, providing reliable interior surveillance during evening operations or in covered parking areas.

Advantages & Limitations

Advantages:

• Ultra-compact 45mm mini dome design
• 150° wide angle coverage from single camera
• Audio recording capability (1-channel)
• Professional metal construction
• Discreet internal mounting
• Compatible with MDVR and AHD monitor systems
• Lightweight 100g installation

Limitations:

• Internal use only (not weatherproof for external mounting)
• Requires compatible MDVR or AHD monitor system
• Camera cable sold separately (choose appropriate length)
• PAL system (ensure monitor compatibility)

Technical Specs

• Resolution: 1080P Full HD AHD
• Image sensor: 1/3" CMOS technology
• Lens: 150° wide angle coverage
• Night vision: 2x infrared LEDs
• Audio: 1-channel recording capability
• Construction: Metal case mini housing
• Application: Internal use only
• Connector: Heavy duty 4-pin system
• Dimensions: 45(L) x 32(H) x 43(W)mm
• Weight: 100g
• TV system: PAL standard
• Mounting: Adjustable bracket included

Warranty

This comes with the manufacturer's warranty through the Australian distributor. See the manufacturer's terms for details, plus our guarantees under the Australian Consumer Law.

FAQ about the MC10D

What is the Mongoose MC10D?

It is the Mongoose | AHD Mini Dome Camera. The compact 45mm housing with metal construction ensures reliable operation while maintaining minimal visual impact inside vehicles.

What are the main features of the MC10D?

AHD 1080P Full HD resolution. Ultra-compact mini dome design (45 x 32 x 43mm). 1/3" CMOS image sensor technology.

What warranty comes with the MC10D?

This comes with the manufacturer's warranty through the Australian distributor. See the manufacturer's terms for details, plus our guarantees under the Australian Consumer Law.
