Mongoose MC103 AHD Camera – 1080P Audio Night Vision Heavy Duty

Full HD reversing camera built to survive high-pressure wash-downs and constant vibration.

Product Overview

The Mongoose MC103 is a heavy-duty AHD reverse camera engineered for commercial vehicles, agricultural equipment, construction machinery, and trailers operating in extreme Australian conditions. Featuring a 1/2.9" CMOS sensor delivering Full HD 1080p (1920×1080) video through PAL signal output, this camera provides crisp detail for reversing operations and perimeter monitoring. Built to IP69K standards, it survives direct high-pressure, high-temperature jet washing that destroys standard cameras within weeks in commercial vehicle cleaning bays. The 10G vibration resistance ensures reliable operation on corrugated outback roads, construction sites, and agricultural fields where constant shaking causes connection failures in consumer-grade cameras. Eighteen IR LEDs provide night vision to 0.1 Lux minimum illumination, while the integrated microphone captures ambient audio for complete situational awareness. The adjustable U-bracket surface mount with included hardware allows precise angle positioning, and the 100° horizontal field of view captures wide coverage behind trucks, trailers, and heavy equipment.

Key Specifications

• Sensor: 1/2.9" CMOS
• Resolution: 1920×1080p Full HD (1080p)
• Frame rate: 25-30fps (PAL standard)
• Lens angle: 100° horizontal, 57° vertical, 116° diagonal
• Signal system: PAL (Australian standard), AHD output
• Waterproof rating: IP69K (high-pressure, high-temperature wash-down resistant)
• Vibration resistance: 10G shock rating
• Night vision: 18 IR LEDs, minimum illumination 0.1 Lux
• Audio: built-in microphone
• Power: 12V DC
• Connection: 4-pin aviation connector (weather-sealed)
• Cable length: 600mm
• Mounting: surface mount U-bracket with adjustable positioning
• Dimensions: 97 × 80 × 88mm
• Operating temperature: -20°C to +70°C (95% RH max)
• Storage temperature: -40°C to +80°C (95% RH max)
• Housing colour: black
• Brand: Mongoose
• SKU: MC103
• Barcode: 9326270001655

Features & Benefits

Full HD 1080p for Clear Number Plate Recognition – 1920×1080 resolution captures fine detail including vehicle registration numbers, obstacle identification, and ground crew faces that 720p cameras render too blurry for incident documentation or insurance claims.

IP69K Rating for Commercial Wash Bay Survival – Exceeds IP68 waterproof standards to withstand direct high-pressure, high-temperature jet washing in commercial vehicle cleaning facilities, agricultural equipment decontamination, and mining site wash-downs where standard cameras fail catastrophically.

10G Vibration Resistance for Corrugated Roads – Engineered to survive constant vibration from trucks on unsealed outback tracks, agricultural machinery in fields, and construction equipment on rough worksites, preventing the connection failures and component damage that destroy standard automotive cameras.

18 IR LEDs for Extended Night Vision Range – More IR illumination than typical 12-LED cameras provides longer-range night vision and better coverage across the full 100° field of view, critical for reversing in unlit loading bays, construction sites, and rural properties.

100° Wide-Angle Coverage Without Fish-Eye Distortion – Captures broad area behind vehicles without the extreme barrel distortion of 120°+ cameras that make judging distances difficult, providing optimal balance between coverage width and image usability for reversing operations.

Built-In Audio for Complete Awareness – Integrated microphone captures reversing beepers, ground crew warnings, and mechanical sounds that indicate issues before visible damage occurs, providing multi-sensory documentation for incident investigations.

Adjustable U-Bracket for Precise Angle Positioning – Surface mount bracket with included hex key allows fine-tuning camera angle after installation without removing the camera, accommodating different vehicle mounting surfaces and desired viewing positions.

4-Pin Aviation Connector for Reliable Connection – Weather-sealed aviation connector provides secure power, video, and audio connection resistant to vibration loosening and water ingress that causes intermittent faults in standard plug-and-socket designs.

Full Metal Housing for Heat Dissipation – Durable black metal construction provides superior cooling compared to plastic housings, allowing the camera to maintain stable operation in hot engine bay or battery compartment installations during Australian summers.

PAL Standard for Australian Compatibility – Factory configured for 50Hz PAL video signal used in Australian monitors and DVRs, eliminating compatibility issues and image distortion from NTSC cameras imported from North American markets.

Technical Specs

• Model number: MC103
• Image sensor: 1/2.9" CMOS (Full HD capable)
• Video resolution: 1920×1080p (Full HD/1080p)
• Frame rate: 25-30fps (PAL standard)
• Field of view: 100° horizontal, 57° vertical, 116° diagonal
• Video output: AHD (Analog High Definition), PAL system
• Minimum illumination: 0.1 Lux
• IR illumination: 18 IR LEDs for night vision
• Night sensor: automatic IR LED activation at low light
• Audio: built-in microphone with audio output
• Mirror image function: yes (for reverse orientation mounting)
• Waterproof rating: IP69K (high-pressure, high-temperature resistant)
• Vibration rating: 10G shock resistance
• Operating voltage: 12V DC
• Power consumption: not specified
• Connection type: 4-pin aviation connector (weather-sealed)
• Cable length: 600mm included
• Mounting type: surface mount with adjustable U-bracket
• Mounting hardware: 2× 4×12mm screws, 1× hex key included
• Housing material: metal construction
• Housing colour: black
• Dimensions: 97mm (W) × 80mm (H) × 88mm (D)
• Weight: not specified
• Operating temperature: -20°C to +70°C, 95% RH maximum
• Storage temperature: -40°C to +80°C, 95% RH maximum
• Viewing type: reverse camera orientation

Frequently Asked Questions

What monitor do I need for this AHD camera?

You need an AHD-compatible monitor or DVR that accepts 1080p AHD input. Standard analog composite monitors won't display the full 1080p resolution from this camera.

Will this survive commercial truck wash bays?

Yes, IP69K rating means it handles high-pressure, high-temperature wash-downs that destroy standard IP67 or IP68 cameras, making it ideal for commercial vehicle cleaning facilities.

How does 10G vibration resistance help?

The 10G rating ensures the camera survives constant vibration from corrugated roads, construction sites, and agricultural work that causes connection failures and component damage in standard cameras.

What's the difference between 100° and 120° viewing angles?

The 100° lens provides wide coverage without the extreme barrel distortion (fish-eye effect) of 120°+ cameras, making distance judgement easier and more accurate for reversing.

How far can it see at night with 18 IR LEDs?

The 18 IR LEDs provide extended night vision range compared to typical 12-LED cameras, with clear visibility across the full 100° field of view in complete darkness.

Compatible With / Goes Well With

• AHD-compatible monitors and DVR systems (1080p capable)
• 12V commercial vehicle electrical systems
• Heavy-duty trucks and buses
• Agricultural machinery and tractors
• Construction equipment and earth-moving vehicles
• Trailers and semi-trailers
• Caravans and motorhomes requiring heavy-duty solutions
• Mining and industrial vehicles
• Compatible with Mongoose MC103 mounting brackets and extension cables

Note: Requires AHD-compatible monitor or DVR. Will NOT work with standard composite analog monitors at full 1080p resolution. Verify your monitor supports AHD input before purchase.
