LV Automotive LV9308DF HB4 9006 Direct Fit LED 22W 6500K 2 Pack

Direct Fit HB4/9006 LED Headlight Globes 22W, 6500K, 3200LM, 9–32V, 2 Pack

Product Overview

The LV Automotive LV9308DF is a direct fit LED replacement 2 pack for HB4 (9006) headlight sockets a common low beam and fog light fitment across many passenger vehicles, SUVs, and light commercial vehicles. Each globe draws 22W while delivering 6500K cool white light; the pair produces a combined 3200LM for improved nighttime visibility and a modern white light appearance over standard halogen globes.

Wide 9–32V operating voltage suits both 12V and 24V electrical systems. Plug-and-play installation requires no modification on compatible housings. After installation, verify and adjust beam alignment to maintain the correct beam pattern and avoid dazzling oncoming drivers.

Features & Benefits

• Direct fit HB4/9006 — replaces HB4 (9006) globes in compatible headlight and fog light housings; no wiring modification required
• 22W per bulb — significantly lower power consumption than standard halogen HB4 globes (typically 51W) while delivering greater brightness
• 6500K cool white light — crisp modern white output for improved visibility and contemporary aesthetics
• 3200LM per pair (1600LM per bulb) — substantial brightness increase over standard halogen equivalents
• 9–32V wide voltage range — compatible with 12V passenger vehicles and 24V commercial vehicles
• Compact direct fit design — plug-and-play installation in compatible housings; no external control box or wiring changes
• 2 pack — both globes supplied for simultaneous replacement on both sides

Technical Specs

Compatible With / Goes Well With

• Vehicles with HB4 (9006) headlight or fog light sockets
• 12V and 24V vehicle electrical systems
• Confirm fitment for your specific vehicle before purchasing

Weight

Not specified

Frequently Asked Questions

What is the HB4/9006 globe type and which vehicles use it?

HB4 and 9006 refer to the same globe type — HB4 is the international designation while 9006 is the SAE/North American designation. HB4/9006 is a single-filament globe with a P22d base, commonly used in low beam headlights and fog lights across many vehicle makes including Toyota, Honda, Nissan, Mazda, Subaru, Hyundai, and Kia models. Confirm the globe type for your specific vehicle's make, model, year, and position before purchasing.

How does 22W compare to the halogen globe it replaces?

Standard halogen HB4/9006 globes are typically rated at 51W. The LV9308DF draws only 22W while producing significantly more light output — this reduces the load on the vehicle's alternator and wiring, and generates less heat in the headlight housing.

What does 3200LM total output mean?

3200 lumens is the combined output of both globes in the pack — 1600 lumens per individual globe. A standard halogen HB4 globe produces approximately 1000–1100 lumens, so the LV9308DF provides approximately 50% more light output per globe from a lower wattage. Note that total lumen output and effective road illumination also depend on the headlight housing optics and beam pattern.

Why is beam alignment important after installing LED globes?

When changing globe types in a headlight housing, the position of the light source (the LED chip) may differ slightly from the original halogen filament position. Even small differences in light source position can affect the beam pattern — causing the hotspot to aim too high and potentially dazzle oncoming drivers, or too low and reducing visibility. Checking and adjusting headlight beam alignment after installation is recommended to maintain correct road illumination and comply with legal headlight aiming requirements.

Are these globes suitable for road use?

Road legality for LED headlight replacements depends on ADR compliance and whether the specific vehicle's headlight housing is designed for LED globes. The description notes the importance of beam alignment for maintaining correct beam pattern and avoiding dazzle — both are legal requirements for road use headlights. Confirm compliance status with LV Automotive and your local road authority before installing in a road-registered vehicle.
