LED Autolamps MAXILAMPC1XC 12/2V Maxilamp LED Stop/Tail/Indicator/Reflector Black Chrome Bolt Mount

Round Four-Function LED Combination Lamp Black Chrome, 125mm, ECE Approved, 7-Year Warranty.

Product Overview

The LED Autolamps MAXILAMPC1XC is a 125mm round LED combination lamp delivering stop, tail, indicator, and reflector functions in a single compact round unit with a black chrome finish. Unlike the rectangular Maxi series lamps, the MAXILAMPC1XC's round form factor and 2-bolt surface mount suit applications where a circular lamp profile is preferred or required including round lamp housings on trailers, caravans, and custom vehicle builds.

The PMMA acrylic lens over an ABS base provides durability and UV resistance, while ECE approval (CTA060073) confirms legal compliance for road use. IP67 rated, 12/24V multivolt, and backed by LED Autolamps' 7-year warranty one of the longest in the industry for a round combination lamp of this type. Supplied as a single unit in blister packaging and weighing just 0.394kg.

Key Specifications

• Functions: Stop, tail, indicator, reflector
• Housing: Black chrome
• Shape: Round 125mm diameter
• Overall dimensions: 125mm x 45mm x 40mm
• Lens: PMMA acrylic
• Base: ABS
• Mount type: 2-bolt surface mount
• IP rating: IP67
• Input voltage: 12–24V DC (multivolt)
• Compliance: ECE CTA060073
• Warranty: 7 years
• Weight: 0.394kg
• Packaging: Blister pack single unit
• Brand: LED Autolamps
• SKU: MAXILAMPC1XC

Features & Benefits

• Round 125mm form factor: Compact round design suits round lamp housings and trailer applications where a circular combination lamp is required
• Four-function combination lamp: Stop, tail, indicator, and inbuilt reflex reflector in a single unit, simplifying wiring and reducing lamp count
• Black chrome finish: Premium black chrome housing suits modern trailer and commercial vehicle builds requiring a sleek, professional aesthetic
• PMMA acrylic lens: Durable, UV-resistant acrylic lens maintains clarity and light output over years of outdoor exposure
• 2-bolt surface mount: Straightforward two-bolt mounting for secure installation on flat surfaces
• ECE approved CTA060073: Certified for legal use across all four functions on road vehicles and trailers
• IP67 waterproof: Completely sealed against dust and temporary water immersion
• 12V and 24V compatible: Multivolt operation suits passenger trailers, caravans, and 24V commercial vehicles
• 7-year warranty: LED Autolamps' industry-leading 7-year warranty

Technical Specs

Compatible With

Universal suits all 12V and 24V trailers, caravans, and commercial vehicles requiring a round ADR/ECE-compliant combination lamp including:

• Trailers with round lamp housings or round lamp cutouts
• Caravans and camper trailers
• Custom trailer and vehicle builds
• Agricultural and construction trailers

Frequently Asked Questions

Is this lamp round or rectangular?

This lamp is round with a 125mm diameter it is not the same form factor as the rectangular MAXILAMPC3XR or MAXILAMPC3XRWB lamps. Confirm your mounting cutout or housing accepts a round 125mm lamp before purchasing.

Is this lamp ECE approved for Australian road use?

Yes the MAXILAMPC1XC is ECE approved under CTA060073, confirming it meets compliance standards for road use across all four functions.

Does the 7-year warranty cover all functions?

Yes the 7-year warranty is provided by LED Autolamps and covers manufacturing defects across the complete lamp. Contact your retailer or LED Autolamps for warranty claim procedures.

What lens material does this lamp use?

The MAXILAMPC1XC uses a PMMA acrylic lens a UV-resistant, impact-resistant material that maintains clarity and light transmission over years of outdoor use.

What is the return policy for this product?

Return eligibility is subject to the retailer's policy. Always confirm the mounting cutout size and shape before purchasing. Contact the seller if you're unsure prior to purchase.
