LED Autolamps LB246AM 12/24V Amber Emergency Mini Light Bar Amber Lens With Amber LEDs 18 Selectable Flash Patterns

SKU: LB246AM
Price
$330
Buy now, pay later
  • image
  • image
  • image

Shipping information

We offer fast and reliable shipping options to ensure that your order arrives in a timely manner. Our dedicated team works diligently to process and ship your items as quickly as possible.

Here are some key points to note about our shipping policy:

Standard Shipping

  • Frankies offers a $15.95 flat rate for Australia-wide shipping, no matter how many items you order. Some larger or heavier items may incur an additional fee, which will be communicated to you when your order is processed.
  • While we endeavour to dispatch all orders promptly, please be advised that due to the current national fuel shortages in Australia and the resulting pressure on logistics networks, order processing and dispatch may take up to 7 business days. We are not liable for delays caused by third-party freight carriers or fuel-related logistical disruptions. By placing an order, you acknowledge that delivery timeframes may be extended beyond our standard estimates during this period.

Estimated delivery times:

  • WA, NT, and TAS: currently experiencing longer shipping times
  • Holiday periods (e.g. Christmas): deliveries may be delayed due to increased freight volumes

Express Shipping

  • Express shipping is available and calculated based on your delivery location, as well as the size and weight of your order. To receive an accurate quote, please contact our Albion Park Rail store and request an "express shipping quote." Our team will promptly assist with pricing and availability. Payment for express shipping can be securely arranged over the phone.

Share this product

Share Post Pin E-mail

Product features

LED Autolamps LB246AM 12-24V 30 LED Amber Emergency Mini Light Bar Amber Lens 246mm x 172mm x 64mm 18 Selectable Flash Patterns SAE/J845 Class 1 ECE R65 ECE R10 Permanent Mount IP67

The LED Autolamps LB246AM is a 12-24V amber emergency mini light bar with 30 LEDs, amber lens, and 18 selectable flash patterns. 246mm x 172mm x 64mm. Class 1 QUAD. SAE/J845 Class 1 compliant. ECE R65 and ECE R10 approved. Permanent mount. IP67 waterproof. 10-30V. Five-year warranty. Sold individually.

Product overview

The LB246AM is the amber lens version of the LB246ACM amber emergency mini light bar, sharing the same 30 high-brightness 1W LEDs, 18 selectable flash patterns, Class 1 QUAD output, SAE/J845 Class 1 and ECE R65/R10 compliance, and 246mm x 172mm x 64mm permanent mount housing. The amber lens gives a traditional amber appearance whether the bar is active or inactive, compared to the clear lens of the LB246ACM which activates amber when energised. IP67 waterproof. Operating temperature -40°C to +60°C. 10-30V compatible with 12V and 24V systems.

Features and benefits

30 high-brightness 1W LEDs.

Class 1 QUAD amber emergency output.

Amber lens: Traditional amber appearance when both active and inactive.

18 selectable flash patterns.

Permanent mount.

246mm x 172mm x 64mm.

SAE/J845 Class 1 compliant, ECE R65 and ECE R10 approved.

IP67 fully waterproof and submersible.

10-30V: Compatible with 12V and 24V vehicle electrical systems.

Operating temperature: -40°C to +60°C.

Five-year warranty.

Technical specs

Specification Detail
SKU LB246AM
Brand LED Autolamps
Type Amber emergency mini light bar
LED Count 30
LED Power 1W per LED
LED Colour Amber
Lens Amber
Housing Colour Black
Light Output Class Class 1 QUAD
Flash Patterns 18 selectable
Mount Type Permanent
Operating Voltage 10V to 30V
Dimensions 246mm x 172mm x 64mm
IP Rating IP67
Compliance SAE/J845 Class 1, ECE R65, ECE R10
Operating Temperature -40°C to +60°C
Manufactured In China (Taiwan)
Warranty Five years

Frequently asked questions

Is the LB246AM SAE/J845 Class 1 compliant?

Yes. The LB246AM is SAE/J845 Class 1 compliant and holds ECE R65 and ECE R10 approval, confirming compliance with the highest internationally recognised standards for vehicle warning light bars.

What is the difference between the LB246AM and the LB246ACM?

The LB246AM has an amber lens giving a traditional amber appearance whether active or inactive. The LB246ACM has a clear lens that activates amber when energised. Both share the same 30-LED Class 1 QUAD output, 18 selectable flash patterns, 246mm x 172mm x 64mm permanent mount housing, and SAE/J845 Class 1 and ECE R65/R10 compliance.

How many flash patterns does the LB246AM have?

The LB246AM has 18 selectable flash patterns.

What voltage does the LB246AM operate on?

The LB246AM operates on 10V to 30V, compatible with both 12V and 24V vehicle electrical systems.

Is the LB246AM waterproof?

Yes. The LB246AM has an IP67 rating, meaning it is fully dust-tight and can withstand submersion in up to 1 metre of water for up to 30 minutes.
