LED Autolamps GH12B Black Grab Handle Blue With On/Off Switch

Caravan Grab Handle with Integrated LED Light & Blue Night Light 330 Lumens, Push Button Control.

Product Overview

The LED Autolamps GH12B is a 12V grab handle with integrated high-brightness LED lighting and a blue night light a practical and elegant dual-function solution for caravan doors, camper trailer entries, and enclosed vehicle access points. Combining a sturdy black aluminium grab handle with a 330-lumen main light (18 LEDs), a blue ambient night light (1 LED), and a push button with door control functionality, the GH12B turns a functional grab handle into a complete entry lighting solution.

The push button provides on/off control and also supports door-activated illumination, allowing the light to switch on automatically when the caravan or trailer door is opened ideal for late-night camp entries without fumbling for a switch. The blue night light remains on as a gentle ambient guide light. IP65 rated and constructed with a polycarbonate lens and base behind an aluminium cover, the GH12B is built for the demands of outdoor and travel use. Backed by LED Autolamps' 2-year warranty and supplied as a single unit in box packaging.

Key Specifications

• Function: Grab handle with integrated LED main light and blue night light
• Main LEDs: 18 LEDs
• Night light: 1 x blue LED
• Main light output: 330 lumens / 66 Lux @ 1m
• Colour temperature: 6500K cool white
• Installed dimensions: 222mm x 146mm x 29mm
• Cable length: 22cm
• Switch: Push button with door control
• Lens/base: Polycarbonate
• Cover: Aluminium
• Housing colour: Black
• IP rating: IP65
• Input voltage: 12V only
• Warranty: 2 years
• Barcode: 9335962104130
• Weight: 0.365kg
• Packaging: Box single unit
• Brand: LED Autolamps
• SKU: GH12B

Features & Benefits

• Integrated grab handle and light: Combines a functional entry grab handle with a 330-lumen LED main light and blue night light in a single compact unit, eliminating the need for separate grab handle and interior lamp installations
• 18 LED main light 330 lumens: High-brightness 6500K cool white output delivers 66 Lux at 1 metre for effective entry and step illumination
• Blue night light: Single blue LED provides a gentle ambient guide light for low-light navigation without activating the full brightness main light
• Push button with door control: The push button provides manual on/off control and supports door-activated illumination automatically lighting the entry when the door is opened
• Black aluminium cover: Robust aluminium construction with a clean black finish suited to modern caravan and camper trailer aesthetics
• Polycarbonate lens and base: Durable, UV-resistant construction for long-term outdoor performance
• IP65 rated: Protected against dust ingress and low-pressure water spray for reliable performance in outdoor travel environments
• 22cm cable: Pre-wired with a 22cm lead for straightforward connection during installation
• Screw mount installation: Simple two-screw installation with supplied gaskets for a weatherproof seal
• 2-year warranty: Backed by LED Autolamps' 2-year product warranty

Technical Specs

Compatible With

Suits all 12V caravans, camper trailers, enclosed trailers, and motorhomes requiring an integrated entry grab handle with lighting including:

• Caravans and camper trailers
• Motorhomes and campervans
• Enclosed trailers and horse floats
• Any 12V vehicle requiring a combined entry handle and light solution

Frequently Asked Questions

Does this grab handle light up automatically when the door is opened?

Yes the push button supports door control functionality, allowing the light to activate automatically when the caravan or trailer door is opened. The blue night light can remain on as a continuous ambient guide.

What is the blue light for?

The single blue LED night light provides gentle ambient illumination for navigating to the caravan or trailer entry in low-light conditions without activating the full 330-lumen main light.

How is the GH12B mounted?

The GH12B installs using two screws with the supplied gaskets for a weatherproof seal at the mounting surface. The 22cm cable connects to a 12V power source.

Is this suitable for 24V systems?

No the GH12B is 12V only. Do not connect to 24V systems.
