LED Autolamps FLT04 Red Line Forklift Lamp, No Plug

Red Line Forklift Safety Lamp Projects a 4.5m Red Line to Alert Pedestrians. 10–94V, IP67, ECE R10.

Product Overview

The LED Autolamps FLT04 is a red line beam forklift safety lamp designed to project a clearly visible red line onto the floor ahead of or behind a forklift, reach truck, or other material handling equipment alerting pedestrians and warehouse workers to the presence and movement of the vehicle before it comes into view. By projecting a bright red line up to 4.5 metres from the lamp, the FLT04 creates a visual safety zone around the forklift, reducing the risk of pedestrian-vehicle collisions in warehouses, distribution centres, loading docks, and industrial facilities.

Constructed with an aluminium housing, polycarbonate lens, and a compact 76mm x 73mm x 73mm body, the FLT04 mounts via an adjustable bracket that bolts to the rear of the forklift the angle can be set to achieve the desired floor projection distance and safety zone. The broad 10–94V multivolt input range covers 12V, 24V, 36V, and 48V forklift electrical systems without the need for voltage converters. IP67 rated and ECE R10/EMC approved, the FLT04 is backed by LED Autolamps' 3-year warranty. Supplied without a plug terminated with bare wires for direct connection to the vehicle's electrical system.

Key Specifications

• Function: Red line beam safety lamp
• Light projection: 4.5m
• LED count: 3 LEDs
• LED colour: Red
• Lens: Polycarbonate
• Housing: Aluminium black
• Dimensions: 76mm x 73mm x 73mm
• Cable: 45cm fixed no plug (bare wires)
• Mount type: Adjustable bracket bolt to vehicle
• IP rating: IP67
• Input voltage: 10–94V DC (multivolt)
• Current draw: 0.48A @ 10V / 0.06A @ 94V
• Compliance: ECE R10 / EMC approved
• Warranty: 3 years
• Weight: 0.38kg
• Packaging: Box single unit
• Brand: LED Autolamps
• SKU: FLT04

Features & Benefits

• 4.5m red line projection: Projects a bright red line up to 4.5 metres from the lamp onto the warehouse floor, creating a clearly visible safety exclusion zone around the forklift for pedestrians
• Improves pedestrian safety: The projected red line alerts workers to the forklift's presence before it comes around a corner or exits a trailer, significantly reducing collision risk in high-traffic warehouse environments
• 10–94V multivolt operation: Covers 12V, 24V, 36V, and 48V forklift and material handling equipment electrical systems without voltage converters or adapters
• Adjustable bracket mount: The angle of the lamp can be adjusted via the bracket after bolting to the vehicle, allowing the projection distance and safety zone to be optimised for the specific operating environment
• Aluminium housing: Robust aluminium construction withstands the demanding industrial environments typical of forklift and warehouse operations
• IP67 weatherproof: Fully protected against dust ingress and temporary water immersion for reliable performance in wash-down and outdoor yard environments
• ECE R10 and EMC approved: Meets ECE R10 electromagnetic compatibility requirements for use on vehicles in industrial and commercial settings
• Compact 76mm x 73mm x 73mm design: Small, low-profile design suits mounting in tight spaces on forklift masts, frames, and rear structures
• 3-year warranty: Backed by LED Autolamps' 3-year product warranty

Technical Specs

Compatible With

Suits all 10–94V material handling and industrial vehicles requiring red line safety projection including:

• Forklifts (electric and LPG) 12V, 24V, 36V, 48V systems
• Reach trucks and order pickers
• Pallet jacks and electric ride-on vehicles
• Warehouse tuggers and tow tractors
• Any industrial vehicle operating in pedestrian-shared environments

Frequently Asked Questions

How does the red line forklift safety lamp work?

The FLT04 projects a bright red line onto the floor ahead of or behind the forklift, creating a visible safety exclusion zone up to 4.5 metres from the lamp. This alerts pedestrians and other workers to the forklift's presence before it comes into their direct line of sight, reducing collision risk at intersections, corners, and loading dock exits.

Why is the voltage range so wide 10 to 94 volts?

Forklifts operate on a range of electrical systems typically 12V, 24V, 36V, or 48V depending on the manufacturer and model. The 10–94V multivolt input range ensures the FLT04 is compatible across all common forklift electrical systems without the need for voltage regulators or adapters.

Does this lamp come with a plug?

No the FLT04 is supplied with a 45cm bare wire cable without a plug. Direct wiring to the vehicle's electrical system is required. Connection by a qualified electrician is recommended.

Where is the lamp mounted on the forklift?

The FLT04 is typically bolted to the rear of the forklift using the adjustable bracket mount, projecting the red line rearward for pedestrian warning as the forklift reverses. It can also be mounted at the front for forward movement warning. The angle can be adjusted after mounting to set the desired projection distance.

What is the return policy for this product?

Return eligibility is subject to the retailer's policy. Contact the seller before ordering if you have any questions about this product.
