LED Autolamps 80BARRM Multi Volt LED Stop/Tail/Indicator Assembly 180 LEDs
Click to open expanded view
LED AUTOLAMPS logo

LED Autolamps 80BARRM Multi Volt LED Stop/Tail/Indicator Assembly 180 LEDs

SKU: 80BARRM
Price
$208
Buy now, pay later
  • image
  • image
  • image

Shipping information

We offer fast and reliable shipping options to ensure that your order arrives in a timely manner. Our dedicated team works diligently to process and ship your items as quickly as possible.

Here are some key points to note about our shipping policy:

Standard Shipping

  • Frankies offers a $15.95 flat rate for Australia-wide shipping, no matter how many items you order. Some larger or heavier items may incur an additional fee, which will be communicated to you when your order is processed.
  • While we endeavour to dispatch all orders promptly, please be advised that due to the current national fuel shortages in Australia and the resulting pressure on logistics networks, order processing and dispatch may take up to 7 business days. We are not liable for delays caused by third-party freight carriers or fuel-related logistical disruptions. By placing an order, you acknowledge that delivery timeframes may be extended beyond our standard estimates during this period.

Estimated delivery times:

  • WA, NT, and TAS: currently experiencing longer shipping times
  • Holiday periods (e.g. Christmas): deliveries may be delayed due to increased freight volumes

Express Shipping

  • Express shipping is available and calculated based on your delivery location, as well as the size and weight of your order. To receive an accurate quote, please contact our Albion Park Rail store and request an "express shipping quote." Our team will promptly assist with pricing and availability. Payment for express shipping can be securely arranged over the phone.

Share this product

Share Post Pin E-mail

Product features

ADR Approved Stop/Tail/Indicator Assembly 180 LEDs, Individual Lens Replacements, 278x100mm, IP67

Product Overview

The LED Autolamps 80BARRM is the wide-format flagship of the 80 series a 12/24V rear combination lamp with 180 LEDs across a 278mm x 100mm x 28mm black bracket, nearly 1.5 times the width of the 80BARM. The same individual lens replacement design keeps maintenance cost low across the higher LED count, and carries identical CRN33059 and CRN33098 ADR certifications.

Drawing 0.33A stop, 0.06A tail, and 0.31A indicator at 13.8V, with a 240mm centre-to-centre mount. Rated IP67 and backed by a 5-year warranty.

Features & Benefits

  • 180 LEDs — high-density LED array across a 278mm wide lamp for a visually striking, high-output rear lighting presence
  • Individual lens replacements — each lens section replaces independently without removing the full unit — ideal for fleet maintenance
  • ADR approved — stop/tail CRN33059 and indicator CRN33098 — same certifications as the 80BARM
  • Black bracket — professional finish for trailer and truck rear panels
  • 240mm centre-to-centre mount — confirm against your panel before installation
  • Pre-wired surface mount — ready to connect out of the blister pack
  • IP67 rated — fully sealed against dust and water immersion
  • 12/24V dual voltage — compatible with both 12V light vehicles and 24V heavy transport
  • 5-year warranty — backed by LED Autolamps' full warranty programme

Technical Specs

Specification Detail
SKU 80BARRM
Lamp Type Stop / Tail / Indicator
LED Quantity 180
Voltage Range 12V / 24V
Dimensions 278mm x 100mm x 28mm
Mount Centre-to-Centre 240mm
Stop Current Draw 0.33A @ 13.8V
Tail Current Draw 0.06A @ 13.8V
Indicator Current Draw 0.31A @ 13.8V
Lens Individual replacements
Housing Colour Black
Mounting Surface mount
Connector Pre-wired
Protection Rating IP67
Stop/Tail Compliance ADR — CRN33059
Indicator Compliance ADR — CRN33098
Packaging Blister pack
Warranty 5 years

Compatible With / Goes Well With

  • Trucks, trailers, and commercial vehicles requiring a wide-format, high-output rear combination lamp
  • 12V light vehicles and 24V heavy transport applications
  • Trailer builds requiring ADR-approved stop/tail/indicator lighting with full CRN certification
  • LED Autolamps 80BARM (same CRN approvals, narrower 188mm format)
  • LED Autolamps wiring harnesses and trailer lighting accessories

Frequently Asked Questions

Is the 80BARRM approved for road use in Australia?

Yes. The 80BARRM holds ADR CRN certifications for stop/tail (CRN33059) and indicator (CRN33098), meeting Australian Design Rules requirements for legal on-road use.

How does the 80BARRM differ from the 80BARM?

The 80BARRM is 278mm wide with 180 LEDs and a 240mm mount spacing, while the 80BARM is 188mm wide with 72 LEDs and a 150mm mount spacing. Both carry the same CRN certifications and current draw figures — choose based on the panel width and visual impact required.

What does individual lens replacement mean for maintenance?

Each lens section can be replaced independently — reducing repair costs on commercial fleets where replacing the full lamp for a single damaged lens is not cost-effective.

What is the IP rating on the 80BARRM?

The 80BARRM is rated IP67, meaning it is fully sealed against dust and capable of withstanding water immersion — suitable for exposed trailer and truck body mounting.

What warranty does the 80BARRM carry?

The 80BARRM is backed by a 5-year warranty from LED Autolamps.
