LED Autolamps 42RM Rear End Outline LED Marker Red Lens 16cm Cable Blister Pack
Click to open expanded view
LED AUTOLAMPS logo

LED Autolamps 42RM Rear End Outline LED Marker Red Lens 16cm Cable Blister Pack

SKU: 42RM
Price
$37
Buy now, pay later
  • image
  • image
  • image

Shipping information

We offer fast and reliable shipping options to ensure that your order arrives in a timely manner. Our dedicated team works diligently to process and ship your items as quickly as possible.

Here are some key points to note about our shipping policy:

Standard Shipping

  • Frankies offers a $15.95 flat rate for Australia-wide shipping, no matter how many items you order. Some larger or heavier items may incur an additional fee, which will be communicated to you when your order is processed.
  • While we endeavour to dispatch all orders promptly, please be advised that due to the current national fuel shortages in Australia and the resulting pressure on logistics networks, order processing and dispatch may take up to 7 business days. We are not liable for delays caused by third-party freight carriers or fuel-related logistical disruptions. By placing an order, you acknowledge that delivery timeframes may be extended beyond our standard estimates during this period.

Estimated delivery times:

  • WA, NT, and TAS: currently experiencing longer shipping times
  • Holiday periods (e.g. Christmas): deliveries may be delayed due to increased freight volumes

Express Shipping

  • Express shipping is available and calculated based on your delivery location, as well as the size and weight of your order. To receive an accurate quote, please contact our Albion Park Rail store and request an "express shipping quote." Our team will promptly assist with pricing and availability. Payment for express shipping can be securely arranged over the phone.

Share this product

Share Post Pin E-mail

Product features

Classic Truck-Style Red LED Rear Marker Chrome Bracket, ADR 49/00, IP67, Clip-In Lens.

Product Overview

The LED Autolamps 42RM is a red LED rear end outline marker light in the classic truck style, featuring a chrome bracket, polycarbonate clip-in lens, and a clear lens design with internal red LEDs. Measuring 74mm x 38mm x 35mm with a 28.5mm bolt hole spacing, the 42RM is a widely used rear and side marker lamp for trailers, caravans, trucks, and commercial vehicles across Australia.

ADR approved under Category 49/00 (CRN 42839) and IP67 rated for complete weatherproof protection, the 42RM operates on both 12V and 24V systems with a minimal current draw of just 0.05A at 12V. The clip-in lens design allows lens replacement without removing the bracket, and the 16cm cable provides a practical lead length for most mounting locations. Supplied as a single unit in blister packaging, with the chrome bracket version (42RM) distinguishing it from the black bracket alternative (42RMB).

Key Specifications

  • Function: Rear end outline / marker light
  • LED colour: Red
  • Lens: Clear polycarbonate clip-in
  • Bracket: Chrome
  • Dimensions: 74mm x 38mm x 35mm
  • Bolt hole spacing: 28.5mm
  • Cable length: 16cm
  • Mount type: Surface mount (horizontal bracket)
  • IP rating: IP67
  • Input voltage: 12–24V DC (multivolt)
  • Current draw: 0.05A @ 13.8V / 0.06A @ 28V
  • Compliance: ADR 49/00 CRN 42839
  • Warranty: 5 years
  • Packaging: Blister pack single unit
  • Brand: LED Autolamps
  • SKU: 42RM

Features & Benefits

  • Classic truck style: The 42RM is one of the most widely used rear marker lamp form factors on Australian trucks and trailers, fitting standard marker positions across a broad range of vehicle types
  • Chrome bracket: Premium chrome finish bracket suits traditional trailer and truck builds; the black bracket alternative (42RMB) is available for those preferring a darker aesthetic
  • Polycarbonate clip-in lens: The replaceable clip-in lens allows lens swap without removing the bracket, simplifying maintenance on working vehicles
  • Clear lens with internal red LEDs: Modern LED design maintains colour accuracy and brightness without lens discolouration from UV exposure over time
  • ADR 49/00 approved CRN 42839: Fully compliant with Australian Design Rules for rear end outline markers on trailers and commercial vehicles
  • IP67 weatherproof: Completely dust-proof and protected against temporary water immersion for reliable outdoor performance in all Australian conditions
  • Ultra-low current draw: Just 0.05A at 12V, placing minimal load on the vehicle's electrical system and extending LED lifespan
  • 12V and 24V compatible: Multivolt operation suits passenger and caravan trailers through to 24V heavy commercial trucks
  • 5-year warranty: Backed by LED Autolamps' industry-standard 5-year warranty

Technical Specs

Specification Detail
SKU 42RM
Brand LED Autolamps
Function Rear End Outline / Marker Light
LED Colour Red
Lens Clear polycarbonate clip-in
Bracket Colour Chrome
Dimensions 74mm x 38mm x 35mm
Bolt Hole Spacing 28.5mm
Cable Length 16cm
Mount Type Surface mount horizontal bracket
IP Rating IP67
Input Voltage 12–24V DC (multivolt)
Current Draw 0.05A @ 13.8V / 0.06A @ 28V
ADR Compliance ADR 49/00 CRN 42839
Warranty 5 Years
Packaging Blister Pack single unit

Compatible With

Universal suits all 12V and 24V trailers, caravans, and commercial vehicles requiring ADR-compliant rear end marker lighting including:

  • Box trailers, car trailers, and boat trailers
  • Caravans and camper trailers
  • Light and heavy commercial trucks
  • Agricultural and construction trailers
  • Horse floats and livestock trailers

Pairs well with:

  • LED Autolamps MAXILAMPC3XR stop/tail/indicator combination lamp
  • LED Autolamps 35CARM red/amber side marker
  • LED Autolamps 7030R red self-adhesive reflectors

Frequently Asked Questions

What is the difference between the 42RM and the 42RMB?

The 42RM has a chrome bracket while the 42RMB has a black bracket. Both are otherwise identical in function, dimensions, LED colour, and specifications. Choose based on your preferred bracket finish.

Is this lamp ADR approved for Australian road use?

Yes the 42RM is ADR approved under Category 49/00 with CRN 42839, confirming it meets Australian legal requirements for rear end outline markers on trailers and commercial vehicles.

Can the lens be replaced without removing the bracket?

Yes the clip-in lens design allows lens replacement without removing the bracket from the mounting surface, making maintenance on installed units straightforward.

What is the current draw of this lamp?

The 42RM draws just 0.05A at 13.8V (12V system) and 0.06A at 28V (24V system), placing minimal load on the vehicle's electrical system.

What is the bolt hole spacing for mounting?

The centre-to-centre distance between the two mounting bolt holes is 28.5mm. Confirm this suits your mounting surface before purchasing.
