LED Autolamps 35ARM Stop/Tail Indicator With 18 Square LEDs Multi Volt Blister

Red/Amber LED Side Marker Chrome Base, 4 LEDs, ADR CRN 34099, 12/24V, Clip-In Lens.

Product Overview

The LED Autolamps 35ARM is a red and amber LED side marker lamp from the 35 Series, featuring a chrome base bracket, 4 LEDs, clear lens, and pre-wired cable. The chrome bracket distinguishes the 35ARM from the black bracket 35ARMB both are otherwise identical in function, dimensions, and ADR compliance. Sharing the proven 58mm x 35mm x 21mm 35 Series form factor, the 35ARM delivers ADR-compliant red and amber side marker output across 12V and 24V systems.

Installation is via surface mount bracket run wires through the back and clip the lens into place. ADR approved (CRN 34099, ADR 45/01), IP67 rated, and backed by LED Autolamps' 5-year warranty. Supplied as a single unit in blister packaging.

Key Specifications

• Function: Red/amber side marker
• LED count: 4
• LED colour: Red and amber
• Lens: Clear clip-in replaceable
• Bracket colour: Chrome
• Housing colour: Black
• Dimensions: 58mm x 35mm x 21mm
• Centre-to-centre mounting: 28mm
• Cable: Pre-wired
• Mount type: Surface mount clip-in lens
• IP rating: IP67
• Input voltage: 12–24V DC (multivolt)
• Current draw: 0.1A @ 13.8V
• Compliance: ADR CRN 34099, ADR 45/01
• Warranty: 5 years
• Packaging: Blister pack single unit
• Brand: LED Autolamps
• SKU: 35ARM

Features & Benefits

• Red and amber combined: Single unit provides both red and amber LED side marker output through a clear clip-in lens
• Chrome base bracket: Classic chrome bracket finish; the black bracket alternative is the 35ARMB
• Clip-in replaceable lens: Clear lens clips in and out without removing the bracket for fast maintenance
• 4 LEDs: Four LEDs deliver bright, consistent red and amber side marker output
• 28mm centre-to-centre mounting: Standard two-bolt spacing for straightforward surface installation
• ADR CRN 34099 and ADR 45/01: Dual ADR compliance for legal side marker use on Australian road vehicles
• IP67 waterproof: Completely sealed against dust and temporary water immersion
• 12V and 24V compatible: Multivolt operation suits passenger trailers, caravans, and 24V commercial trucks
• 5-year warranty: Backed by LED Autolamps' 5-year warranty

Technical Specs

Compatible With

Universal suits all 12V and 24V trailers, caravans, and commercial vehicles requiring red/amber ADR-compliant side markers including:

• Box trailers, car trailers, and boat trailers
• Caravans and camper trailers
• Light and heavy commercial trucks
• Agricultural and construction trailers

Frequently Asked Questions

What is the difference between the 35ARM and the 35ARMB?

The 35ARM has a chrome base bracket while the 35ARMB has a black base bracket. Both are otherwise identical in function, LED count, dimensions, and compliance. Choose based on your preferred bracket finish.

Is this lamp ADR approved for Australian road use?

Yes the 35ARM is ADR approved under CRN 34099 and ADR 45/01 for red/amber side marker use on Australian road vehicles and trailers.

What was wrong with the supplier title?

The supplier title "Stop/Tail Indicator With 18 Square LEDs" is a confirmed data entry error the 35ARM is a red/amber side marker with 4 LEDs, as confirmed by Automotive Superstore, Trailer Trailers, and all other verified sources. The incorrect title appears to have been copied from a different product. Recommend correcting the supplier title.

Can the lens be replaced without removing the bracket?

Yes the clip-in lens design allows lens replacement without removing the bracket from the mounting surface.

What is the return policy for this product?

Return eligibility is subject to the retailer's policy. Contact the seller before ordering if you have any questions.
