LED Autolamps 285BR12S3 Slimline/Low Profile Centre High Level

12V Slimline Centre High Level Stop Lamp 16 LEDs, ECE/ADR Approved, 285mm, IP67.

Product Overview

The LED Autolamps 285BR12S3 is a 12V slimline centre high-level (high mount) stop lamp commonly known as a CHMSL (Centre High Mount Stop Lamp) or third brake light from the 285 Series. Designed to provide an additional, elevated brake light signal for improved rear-end collision avoidance on trailers, caravans, and commercial vehicles, the 285BR12S3 mounts centrally and at a higher position than the standard tail lamps for maximum visibility to following drivers.

Containing 16 LEDs drawing 0.24A at 13.8V through a clear lens, the 285BR12S3 measures 285mm x 25mm x 10mm with an 8.5cm cable. ECE approved (E97R02/S323559*00) and ADR CTA-060136 compliant for high-level brake lamp use, and IP67 rated. Installation is via surface mount remove end caps, fix to flat surface with screws supplied, then refit end caps per ADR 13/00 mounting instructions. Backed by LED Autolamps' 5-year warranty.

Key Specifications

• Function: Centre high-level stop lamp (CHMSL / third brake light)
• LED count: 16
• Lens: Clear
• Cable length: 8.5cm
• Current draw: 0.24A @ 13.8V
• Dimensions: 285mm x 25mm x 10mm
• Mount type: Surface mount remove end caps, fix with screws, refit caps
• Voltage: 12V only
• IP rating: IP67
• ECE compliance: E97R02/S323559*00
• ADR compliance: CTA-060136 (ADR 49/00 High Level Brake)
• Warranty: 5 years
• Packaging: Single unit
• Brand: LED Autolamps
• SKU: 285BR12S3

Features & Benefits

• Centre high-level stop lamp: Provides an additional, elevated brake light signal above the standard tail lamp level for improved visibility to following vehicles reducing rear-end collision risk
• 16 LEDs: 16 red LEDs through a clear lens deliver bright, consistent stop lamp output
• ECE and ADR approved: ECE E97R02/S323559*00 and ADR CTA-060136 confirm legal compliance for centre high-level brake lamp use on Australian road vehicles
• Slimline 285mm x 25mm x 10mm: Ultra-compact strip format for unobtrusive central rear mounting
• Concealed screw mount: Remove end caps, screw fix to flat surface, refit end caps for no visible fasteners
• IP67 weatherproof: Completely sealed against dust ingress and temporary water immersion
• 12V only: Direct 12V compatibility for trailers, caravans, and light commercial vehicles
• 5-year warranty: Backed by LED Autolamps' industry-standard 5-year warranty

Technical Specs

Compatible With

Suits 12V trailers, caravans, and vehicles requiring a centre high-level stop lamp including:

• Box trailers, car trailers, and boat trailers
• Caravans and camper trailers
• Light commercial vehicles
• Any vehicle or trailer requiring an additional central high-mount brake light

Frequently Asked Questions

What is a centre high-level stop lamp?

A centre high-level stop lamp (CHMSL) is an additional brake light positioned centrally and higher than the standard stop lamps commonly known as a third brake light. It provides improved brake signal visibility to following drivers, particularly in heavy traffic or adverse weather conditions.

Is this lamp ADR and ECE approved for Australian road use?

Yes the 285BR12S3 is ECE approved under E97R02/S323559*00 and ADR approved under CTA-060136 (ADR 49/00) for centre high-level brake lamp use on Australian road vehicles and trailers.

How many LEDs does this lamp have?

The 285BR12S3 contains 16 red LEDs through a clear lens, drawing 0.24A at 13.8V.

Is this lamp suitable for 24V systems?

No the 285BR12S3 is 12V only. Confirm your vehicle or trailer operates on a 12V system before purchasing.

What is the return policy for this product?

Return eligibility is subject to the retailer's policy. Contact the seller before ordering if you have any questions.
