LED Autolamps 23450BLK 12V Awning Lamp Black 20cm Cable Blister Pack

12V Black Aluminium Awning Lamp 443mm, 36 LEDs, 3000K Warm White, IP67, Interior or Exterior.

Product Overview

The LED Autolamps 23450BLK is a 443mm slimline black aluminium awning lamp from the 23 Series purpose-built for caravan awnings, camper trailers, 4WD awning setups, and any interior or exterior application requiring a low-profile, warm white LED strip lamp. At just 23mm high and 24mm deep, the 23450BLK fits neatly above awning rails, door frames, and window surrounds where a compact yet effective light source is required.

With 36 LEDs delivering 165 Lux at 1 metre and a 3000K warm white colour temperature through a 60-degree light spread, the 23450BLK produces a broad, even swath of warm illumination suited to outdoor living areas, camp setups, and vehicle entry/exit lighting. The clear silicon lens and durable black aluminium housing ensure IP67-rated protection for both interior and exterior installations. Supplied with a 20cm cable and backed by LED Autolamps' 3-year warranty.

Key Specifications

• LED count: 36
• Colour temperature: 3000K warm white
• Light output: 165 Lux @ 1m
• Light spread: 60-degree
• Housing: Black durable aluminium
• Lens: Clear silicon
• Dimensions: 443mm x 23mm x 24mm
• Mount type: Surface mount end cap removable, screws provided
• Cable length: 20cm
• IP rating: IP67
• Input voltage: 12V only (not 24V compatible)
• Current draw: 0.74A @ 13.8V
• Warranty: 3 years
• Packaging: Blister pack single unit
• Brand: LED Autolamps
• SKU: 23450BLK

Features & Benefits

• 443mm slimline profile: At just 23mm high and 24mm deep, the 23450BLK installs neatly in tight spaces including above awning rails, door frames, caravan walls, and window surrounds
• 36 LEDs 165 Lux @ 1m: High LED count for the 443mm form factor, delivering 165 Lux at one metre for effective ambient and task lighting across awning and outdoor areas
• 3000K warm white: Warm white light output creates a comfortable, inviting ambiance for outdoor living and camp environments noticeably warmer and more relaxing than cool white alternatives
• 60-degree light spread: Directed 60-degree beam concentrates light output towards the target area below the lamp, maximising effective illumination for awning and step lighting applications
• Black durable aluminium housing: Lightweight, corrosion-resistant aluminium construction withstands outdoor and marine environments with a clean, modern black finish
• Clear silicon lens: Durable, UV-resistant silicon lens maintains clarity and light output over years of outdoor exposure
• IP67 weatherproof: Fully dust-proof and protected against temporary water immersion suitable for both interior and exterior use in all weather conditions
• Surface mount with removable end caps: End caps remove for flat surface mounting with screws, then refit for a clean, seamless finished appearance
• 20cm cable: Pre-wired with a 20cm lead for straightforward connection to a switched power supply
• 3-year warranty: Backed by LED Autolamps' 3-year product warranty

Technical Specs

Compatible With

Suits all 12V caravan, camper trailer, 4WD, and marine applications requiring low-profile warm white awning or scene lighting including:

• Caravan awning rails and walls
• Camper trailer awning setups
• 4WD canopy and roof tent annexe lighting
• Vehicle entry and step illumination
• Interior strip lighting (12V systems)
• Marine and boat interior/exterior lighting

Frequently Asked Questions

Is the 23450BLK suitable for outdoor use?

Yes the 23450BLK is rated IP67 and is suitable for both interior and exterior use, including caravan awning rails, outdoor living areas, and marine environments exposed to rain and moisture.

What is the difference between the 23450BLK and the 23260BLK?

The 23450BLK is 443mm long with 36 LEDs producing 165 Lux at 1 metre. The 23260BLK is the shorter 260mm version with 18 LEDs producing 80 Lux at 1 metre. Both share the same black aluminium housing, 3000K warm white output, 60-degree spread, and IP67 rating.

Is a switch included with this lamp?

No a switch is not included. The 23450BLK requires connection to a switched power supply. A suitable inline switch or switched circuit should be installed separately.

Can the cable be extended beyond the included 20cm lead?

Yes the 20cm cable can be extended using standard automotive cable. Ensure correct cable gauge for the 0.74A current draw and use waterproof connections if the extension is in an exposed location.

What is the return policy for this product?

Return eligibility is subject to the retailer's policy. Contact the seller before ordering if you have any questions about this product.
