Product features

ADR Approved 12V Stop/Tail/Indicator Lamp with Diamond Lens and White Background IP67

Product Overview

The LED Autolamps 150BAR is the single-lamp variant of the 150BAR2, sharing the same 150mm x 80mm x 24mm low-profile form factor with diamond pattern lens but with a white background finish rather than the standard black housing. The white background gives this variant a distinct appearance, making it a natural choice for caravans, white-panelled trailers, and builds where a lighter finish is preferred.

ADR road approved and rated IP67, designed for 12V electrical systems.

Features & Benefits

  • White background — distinctive finish suited to caravans, white-panelled trailers, and builds where a lighter lamp appearance is preferred
  • Diamond pattern lens — premium lens design that enhances the lamp's appearance and distributes light output across the face
  • Stop, tail, and indicator in one lamp — three rear lighting functions including built-in reflex reflector in a single low-profile unit
  • Low-profile 24mm depth — slim form factor for a clean surface-mount finish on trailer and caravan bodies
  • ADR road approved — meets Australian Design Rules for legal on-road use across stop, tail, and indicator functions
  • IP67 rated — fully sealed against dust and water immersion, built for exposed outdoor and transport environments
  • 12V only — designed for 12V trailer and vehicle electrical systems

Technical Specs

Specification Detail
SKU 150BAR
Lamp Type Stop / Tail / Indicator / Reflector
Voltage 12V
Dimensions 150mm x 80mm x 24mm
Lens Diamond pattern
Background White
Mounting Surface mount
Protection Rating IP67
Compliance ADR
Weight 0.5 kg

Compatible With / Goes Well With

  • Caravans and white-panelled trailers requiring a 12V rear combination lamp with a lighter finish
  • Trailer builds requiring ADR-approved stop/tail/indicator lighting
  • LED Autolamps 150BAR2 (same lamp in black, supplied as a 2-pack)
  • LED Autolamps wiring harnesses and trailer lighting accessories

Frequently Asked Questions

Is the 150BAR approved for road use in Australia?

Yes. The LED Autolamps 150BAR is ADR road approved, meeting Australian Design Rules requirements for legal on-road use across stop, tail, and indicator functions.

What makes the 150BAR different from the 150BAR2?

The 150BAR has a white background housing and is supplied as a single lamp, while the 150BAR2 has a black housing and is supplied as a 2-pack. Both share the same 150mm x 80mm x 24mm diamond lens form factor and ADR approval.

What is the diamond pattern lens?

The diamond pattern lens is a distinctive textured design that gives the lamp a premium appearance and helps distribute light output across the lens face.

What is the IP rating on the 150BAR?

The 150BAR is rated IP67, meaning it is fully sealed against dust and capable of withstanding water immersion — suitable for exposed trailer and caravan mounting.

Is the 150BAR compatible with 24V systems?

No. The 150BAR is a 12V-only lamp and is not rated for 24V applications.

Weight

0.5 kg
