JVC CS-DR6932 6x9 Inch 3-Way Car Speakers 500W Peak 70W RMS Pair
JVC CS-DR6932 6x9 Inch 3-Way Car Speakers 500W Peak 70W RMS Pair
JVC CS-DR6932 6x9 Inch 3-Way Car Speakers 500W Peak 70W RMS Pair
JVC CS-DR6932 6x9 Inch 3-Way Car Speakers 500W Peak 70W RMS Pair
Click to open expanded view
JVC logo

JVC CS-DR6932 6x9 Inch 3-Way Car Speakers 500W Peak 70W RMS Pair

SKU: CSDR6932
Price
$139
Buy now, pay later
  • image
  • image
  • image

Shipping information

We offer fast and reliable shipping options to ensure that your order arrives in a timely manner. Our dedicated team works diligently to process and ship your items as quickly as possible.

Here are some key points to note about our shipping policy:

Standard Shipping

  • Frankies offers a $15.95 flat rate for Australia-wide shipping, no matter how many items you order. Some larger or heavier items may incur an additional fee, which will be communicated to you when your order is processed.
  • While we endeavour to dispatch all orders promptly, please be advised that due to the current national fuel shortages in Australia and the resulting pressure on logistics networks, order processing and dispatch may take up to 7 business days. We are not liable for delays caused by third-party freight carriers or fuel-related logistical disruptions. By placing an order, you acknowledge that delivery timeframes may be extended beyond our standard estimates during this period.

Estimated delivery times:

  • WA, NT, and TAS: currently experiencing longer shipping times
  • Holiday periods (e.g. Christmas): deliveries may be delayed due to increased freight volumes

Express Shipping

  • Express shipping is available and calculated based on your delivery location, as well as the size and weight of your order. To receive an accurate quote, please contact our Albion Park Rail store and request an "express shipping quote." Our team will promptly assist with pricing and availability. Payment for express shipping can be securely arranged over the phone.

Share this product

Share Post Pin E-mail

Product features

JVC CS-DR6932 6x9 Inch 3-Way Car Speakers 500W Peak 70W RMS 4 Ohm 88dB Pair

The JVC CS-DR6932 is a pair of 6x9-inch 3-way car speakers rated at 500W peak and 70W RMS per speaker, with a 4-ohm impedance and 88dB sensitivity. Frequency response is rated from 49Hz to 18kHz. Sold as a pair. 12-month warranty.

Product overview

The CS-DR6932 is a 6x9-inch 3-way coaxial speaker set suited to factory 6x9-inch speaker locations typically found in rear decks, doors, and rear quarter panels of sedans, hatchbacks, and wagons. The three-way design adds a dedicated midrange driver alongside the woofer and tweeter, extending the speaker's ability to reproduce the midrange frequency band with greater clarity than a standard 2-way coaxial. At 70W RMS per speaker, the CS-DR6932 is suited to both factory head unit power levels and aftermarket amplifier setups.

Contact us for full driver specifications and mounting dimensions before purchasing to confirm fitment for your vehicle.

Features and benefits

500W peak, 70W RMS per speaker: Power handling suited to factory head units and aftermarket amplifiers.

3-way speaker design: Dedicated woofer, midrange, and tweeter for improved frequency coverage and midrange clarity versus a 2-way coaxial design.

49Hz to 18kHz frequency response: Extended low-frequency reach for improved bass output in rear deck and door locations.

88dB sensitivity: Compatible with standard factory head unit power levels.

12-month warranty.

Technical specs

Specification Detail
SKU CS-DR6932
Brand JVC
Type 6x9-inch 3-way car speakers
Sold As Pair
Peak Input Power 500W per speaker
RMS Power 70W per speaker
Impedance 4 ohm
Sensitivity 88dB/W at 1m
Frequency Response 49Hz to 18kHz
Speaker Size 6x9 inch
Driver Configuration 3-way (woofer, midrange, tweeter)
Driver Specifications Contact us for full spec data
Mounting Dimensions Contact us for cutout and depth requirements
Warranty 12 months

Frequently asked questions

What is the cutout size and mounting depth of the CS-DR6932? Full mounting dimensions are not available in the current product data. Contact us for cutout dimensions and mounting depth specifications before purchasing to confirm fitment for your vehicle.

What is the difference between a 2-way and 3-way speaker? A 2-way speaker uses a woofer and a tweeter. A 3-way speaker adds a dedicated midrange driver, allowing the midrange frequency band to be reproduced by a driver optimised for that purpose rather than shared between the woofer and tweeter. This can result in improved vocal clarity and midrange detail.

What power handling does the CS-DR6932 require? The CS-DR6932 handles 70W RMS per speaker (500W peak). The 88dB sensitivity is compatible with factory head unit power levels and suits aftermarket amplifier setups.

Are these compatible with factory head units? Yes. The 4-ohm impedance and 88dB sensitivity are compatible with standard factory head unit outputs.

What is included in the box? Full accessories list is not available in the current product data. Contact us for complete kit contents before purchasing.
