Professional DSP-equipped marine amplification with advanced tuning capability — MVi 4-channel amplifier delivers 100 watts per channel with integrated digital signal processing and USB computer tuning for precision audio system optimization across Australian offshore vessels.

Product Overview

The JL Audio MVi 4-channel marine amplifier delivers professional-grade audio amplification with integrated digital signal processing featuring 100 watts RMS per channel at 2Ω impedance (75W @ 4Ω) and 200 watts bridged capability per pair for total 400-watt system power output. Designed with IPX2 water and dust ingress protection when mounted vertically with connections pointed downward, this Class-D amplifier features comprehensive DSP functionality including parametric equalization, time alignment, crossover control, and system tuning accessible via USB computer connectivity. Operating across 10-15V DC voltage range with advanced thermal management and compact chassis dimensions (285mm x 176mm x 52mm), the MVi enables professional installation in equipment compartments, helm consoles, or below-deck locations. Compatible with JL Audio MediaMaster source units, M3/M6/M7 marine speakers, marine subwoofers, and MVi-HUB communication bridge for networked multi-amplifier systems, this amplifier serves recreational boats, fishing vessels, and marine audio installations requiring four-speaker configuration or bi-amped two-speaker systems with three-year warranty coverage across Australian waters.

Features & Benefits

Integrated Digital Signal Processing: Comprehensive DSP functionality includes 8-band parametric EQ per channel, adjustable crossovers (high-pass/low-pass/band-pass), time alignment up to 10 milliseconds, phase control, and signal routing enabling precision acoustic tuning matching vessel-specific acoustics, speaker characteristics, and listening environment optimization impossible with analog amplifiers.

Four-Channel Versatility: 4-channel architecture delivers 100W x 4 RMS at 2Ω for powering four independent speakers, or bridge pairs to 200W x 2 @ 4Ω for bi-amped speaker systems or dedicated midbass/subwoofer applications, providing flexible system configurations from simple four-speaker stereo to complex bi-amplified installations with DSP optimization per channel.

USB Computer Tuning Interface: Included 6-foot USB A/B cable enables connection to Windows/Mac computers running JL Audio tuning software providing graphical interface for adjusting all DSP parameters, creating system presets, monitoring real-time signal levels, and storing custom configurations for professional system optimization and client demonstration capabilities.

IPX2 Environmental Protection: Water and dust ingress protection (when mounted vertically with connections downward) withstands marine spray, humidity, and environmental exposure common in equipment compartments and helm console installations, ensuring reliable operation in demanding saltwater conditions without requiring additional protective enclosures across Australian coastal environments.

High-Efficiency Class-D Topology: Advanced Class-D amplifier architecture delivers maximum power output while minimizing heat generation and electrical system strain, reducing current draw from vessel batteries (40A fuse rating) and enabling compact chassis design fitting tight installation spaces common in marine equipment compartments with superior thermal management.

MVi-HUB Network Compatibility: Optional MVi-HUB communication bridge enables networked multi-amplifier systems with centralized control, coordinated DSP processing, and system-wide configuration management across multiple MVi amplifiers for complex multi-zone marine audio installations requiring professional integration capabilities.

Technical Specs

Compatible With / Goes Well With

JL Audio Marine Speakers: M3 marine speakers (6.5", 7.7", 8.8" coaxials), M6 marine speakers (6.5", 7.7", 8.8" coaxials), M3/M6 enclosed tower speakers receiving 75-100W RMS per speaker across four channels for complete helm, cockpit, or tower speaker coverage.

JL Audio Marine Subwoofers: M3 marine subwoofers, M6 marine subwoofers (8" and 10"), M6 marine thin-line subwoofers, M7 marine subwoofers running in bridged mode (200W x 2 @ 4Ω) for dual subwoofer configurations or bi-amped speaker/subwoofer systems.

JL Audio Source Units: MediaMaster 105 marine stereo, MediaMaster 55 marine stereo, JL Audio marine receivers with preamp outputs providing high-voltage signal transmission for optimal noise rejection and amplifier matching.

MVi-HUB Communication Bridge: JLid communication and network bridge (MVi-HUB) enabling networked multi-amplifier systems with centralized control, coordinated DSP processing, and system-wide configuration management for complex installations.

Installation Accessories: Marine-grade amplifier wiring kits (4-gauge minimum), 40A fuses (AFS/AGU/MaxiFuse), marine distribution blocks, waterproof RCA cables, sealed wire connectors, laptop computer for DSP tuning and system optimization.

Frequently Asked Questions

What computer software is required to access the DSP tuning features? JL Audio provides free Windows and Mac compatible tuning software downloadable from their website. Connect the included USB cable between amplifier and computer to access comprehensive DSP controls including parametric EQ, crossovers, time alignment, and all system parameters through graphical user interface.

Can I use this amplifier to power both speakers and subwoofers simultaneously? Yes, the 4-channel configuration enables flexible system designs including: four full-range speakers (100W each), two speakers plus one subwoofer (channels 3+4 bridged for 200W sub), or bi-amped two-speaker system (midbass and highs on separate channels per side). DSP enables independent tuning for each application.

What does IPX2 rating mean and how should I mount the amplifier? IPX2 protection guards against water drops falling at angles up to 15 degrees from vertical when amplifier is mounted vertically with connections pointed downward. This configuration allows water drainage away from connections while protecting against dripping water and condensation in equipment compartments.

Do I need the MVi-HUB for basic operation or is it only for multi-amplifier systems? The MVi-HUB is optional and only required for networked multi-amplifier installations. Single MVi amplifiers operate independently with full DSP functionality via direct USB connection to computer for tuning. MVi-HUB adds centralized control and system-wide coordination for complex multi-zone systems.

How does the 4-channel compare to separate 2-channel amplifiers? The 4-channel MVi consolidates all amplification into single chassis reducing installation complexity, equipment costs, power/ground wiring, and space requirements. Integrated DSP enables coordinated tuning across all channels impossible with separate amplifiers, while maintaining identical per-channel power output and audio quality specifications.
